  • Page 1: Evaluation Board User Guide

    Simplifying System Integration 73S1210F Evaluation Board User Guide August 18, 2009 Rev. 1.2 UG_1210F_035...
  • Page 2 Keil is a trademark of ARM® Ltd. All other trademarks are the property of their respective owners. Teridian Semiconductor Corporation makes no warranty for the use of its products, other than expressly contained in the Company’s warranty detailed in the Teridian Semiconductor Corporation standard Terms and Conditions.

  • Page 3: Table Of Contents

    Figure 9: 73S1210F Evaluation Board Bottom View (Silkscreen) ............19 Figure 10: 73S1210F Evaluation Board Top Signal Layer ..............20 Figure 11: 73S1210F Evaluation Board Middle Layer 1 – Ground Plane ..........21 Figure 12: 73S1210F Evaluation Board Middle Layer 2 – Supply Plane ..........22 Figure 13: 73S1210F Evaluation Board Bottom Signal Layer ..............

  • Page 4: Introduction

    1 Introduction The Teridian Semiconductor Corporation (TSC) 73S1210F Evaluation Board is used to demonstrate the capabilities of the 73S1210F Smart Card Controller devices. It has been designed to operate either as a standalone or as a development platform. The 73S1210F Evaluation Board can be programmed to run any of the Teridian turnkey applications or a user-developed custom application.

  • Page 5: Evaluation Kit Contents

    2 line x 16 character LCD module • 6 x 5 Keypad • 1 LED Recommended Equipment and Test Tools The following equipment and tools (not provided) are recommended for use with the 73S1210F Evaluation Kit: • ® ® ®...

  • Page 6: Evaluation Board Setup

    The board is loaded by default with the PCCID application. It requires a PC to be connected through its serial port. When powered-up, the board is able to run with the PC Exerciser host application. Refer to the 73S1210F Evaluation Board Quick Start Guide to setup and run the PCCID application. Figure 2: 73S1210F Evaluation Board Basic Connections...

  • Page 7: Connecting The Evaluation Board With An Emulation Tool

    UG_1210F_035 73S1210F Evaluation Board User Guide Connecting the Evaluation Board with an Emulation Tool The 73S1210F Evaluation Board has been designed to operate with an In-Circuit-Emulator (ICE) from Signum Systems (model ADM-51). Figure 3 shows the connections between the ICE and the evaluation board.

  • Page 8: Loading User Code Into The Evaluation Board

    Loading Code with the In-Circuit Emulator If firmware exists in the 73S1210F flash memory, the memory must be erased before loading a new file into memory. In order to erase the flash memory, the RESET button in the emulator software must be...

  • Page 9: Figure 4: Emulator Window Showing Reset And Erase Buttons

    UG_1210F_035 73S1210F Evaluation Board User Guide RESET BUTTON ERASE BUTTON Figure 4: Emulator Window Showing RESET and ERASE Buttons Figure 5: Emulator Window Showing Erased Flash Memory and File Load Menu Rev. 1.2...

  • Page 10: Using The Pccid Application

    UG_1210F_035 3 Using the PCCID Application The PCCID firmware is pre-installed on the 73S1210F Evaluation Board. It requires a PC with the serial RS-232 port. When powered-up, the board is able to run the PCCID demonstration host application which allows: •...

  • Page 11: Evaluation Board Hardware Description

    73S1210F Evaluation Board User Guide 4 Evaluation Board Hardware Description Jumpers, Switches and Modules Table 2 describes the 73S1210F Evaluation Board jumpers, switches and modules. The Item # in Table 2 references Figure Table 2: Evaluation Board Jumper, Switch and Module Description...
  • Page 12 Indicates when the 73S1210F is turned on (VDD = 3.3 V). ON/OFF switch Switch used to turn on and off the 73S1210F. The switch is overridden when VBUS is applied (VDD is always on). When VDD is on and the switch is pressed, the...
  • Page 13 On board 73S8010R The board contains a built-in 73S8010R that is connected to the external smart card interface of the 73S1210F. This device can be disconnected from the 73S1210F if not used, by removing jumpers JP12 and JP21. J7,J8 Optional 73S80xxX...
  • Page 14 In normal use, a jumper must be inserted in this header to connect the LEDs to the LED pins of the 73S1210F. This jumper can be replaced by a µA / mA-meter to measure the actual current drawn by the LED output of the 73S1210F.

  • Page 15: Figure 6: 73S1210F Evaluation Board Jumper, Switch And Module Locations

    UG_1210F_035 73S1210F Evaluation Board User Guide Figure 6: 73S1210F Evaluation Board Jumper, Switch and Module Locations Rev. 1.2...

  • Page 16: Test Points

    USB – N/A USB is not available and TP22 is not populated with the 73S1210F. TP24 VBUS – N/A USB is not available and TP24 is not populated with the 73S1210F. TP25 Smart Card Header for measurement of the card signals, close to the card connectors.

  • Page 17: Schematic

    Place R11, R14, R18, SHDNB R19, R20, R21, R22 MAX3237CAI and R23 close to U6 22pF SY M1 22pF 22pF 22pF 22pF Logo PROTO TY PE AREA MOUNT HOLES FOR STAND OFFS TERIDIAN LOGO Figure 7: 73S1210F Evaluation Board Electrical Schematic Rev. 1.2...

  • Page 18: Pcb Layouts

    73S1210F Evaluation Board User Guide UG_1210F_035 PCB Layouts Figure 8: 73S1210F Evaluation Board Top View (Silkscreen) Rev. 1.2...

  • Page 19: Figure 9: 73S1210F Evaluation Board Bottom View (Silkscreen)

    UG_1210F_035 73S1210F Evaluation Board User Guide Figure 9: 73S1210F Evaluation Board Bottom View (Silkscreen) Rev. 1.2...

  • Page 20: Figure 10: 73S1210F Evaluation Board Top Signal Layer

    73S1210F Evaluation Board User Guide UG_1210F_035 Figure 10: 73S1210F Evaluation Board Top Signal Layer Rev. 1.2...

  • Page 21: Figure 11: 73S1210F Evaluation Board Middle Layer 1 - Ground Plane

    UG_1210F_035 73S1210F Evaluation Board User Guide Figure 11: 73S1210F Evaluation Board Middle Layer 1 – Ground Plane Rev. 1.2...

  • Page 22: Figure 12: 73S1210F Evaluation Board Middle Layer 2 - Supply Plane

    73S1210F Evaluation Board User Guide UG_1210F_035 Figure 12: 73S1210F Evaluation Board Middle Layer 2 – Supply Plane Rev. 1.2...

  • Page 23: Figure 13: 73S1210F Evaluation Board Bottom Signal Layer

    UG_1210F_035 73S1210F Evaluation Board User Guide Figure 13: 73S1210F Evaluation Board Bottom Signal Layer Rev. 1.2...

  • Page 24: Bill Of Materials

    73S1210F Evaluation Board User Guide UG_1210F_035 Bill of Materials Table 4 provides the bill of materials for the 73S1210F Evaluation Board schematic provided in Figure Table 4: 73S1210F Evaluation Board Bill of Materials Digi-key Part Item Qty. Reference Part PCB Footprint...
  • Page 25 UG_1210F_035 73S1210F Evaluation Board User Guide Digi-key Part Item Qty. Reference Part PCB Footprint Part Number Manufacturer Number Bourns 10 KΩ 3266W 3266W-103-ND 3266W-1-103 Panasonic R1,R6 P0.0GCT-ND ERJ-3GEY0R00V 680 Ω Panasonic R7,R9,R35 P680GCT-ND ERJ-3GEYJ681V 10 Ω Panasonic P10GCT-ND ERJ-3GEYJ100V Panasonic R10, R24, R25, R26 10 kΩ...

  • Page 26: Schematic Information

    Figure 14: External Components for RESET 4.6.2 Oscillator The 73S1210F contains a single oscillator for the primary system clock. The system clock should use a 12 MHz crystal to provide the proper system clock rates for the serial and smart card interfaces. The system oscillator requires a 1 MΩ...

  • Page 27: Lcd

    The 73S1210F does not contain an on-chip LCD controller. However, an LCD module (with built-in controller) can be used with the 73S1210F via use of specific USR (GPIO) pins. The LCD API libraries support up to a 2 line/16 character display.

  • Page 28: Smart Card Interface

    10 µF and a 0.1 µF capacitor are connected to provide proper decoupling for this input. • The PRES input on the 73S1210F contains a very weak pull down resistor. As a result, an additional external pull down resistor is recommended to prevent any system noise from triggering a false card event.

  • Page 29: Ordering Information

    73S1210F Evaluation Board Quick Start Guide TSC Flash Programmer Model TFP2 User's Manual 7 Contact Information For more information about Teridian Semiconductor products or to check the availability of the 73S1210F contact us at: 6440 Oak Canyon Road Suite 100...

  • Page 30: Revision History

    73S1210F Evaluation Board User Guide UG_1210F_035 Revision History Revision Date Description January 3, 2007 Document Creation. February 12, 2007 Changed 5.1 V zener diode part number and value of limiting resistor R27. August 18, 2009 Updated BOM parts to remove bad or obsolete part numbers.
