- Page 1 DocuWide 6035/6055 Preface DocuWide 6035/6055 Features Copy Print Scan (Via network) Scan (Via USB) Paper Jams Loading Media Replaceing Consumables Troubleshooting...
- Page 2 Preface Thank you for selecting the DocuWide 6035/6055 (hereafter referred to as the "machine"). This guide explains how to operate the machine and the precautions that must be followed during operation. To get the most out of the machine and to use it effectively, be sure to read this guide before use.
-
Page 3: Powering Off
Power On / Off Powering On ● Power Breaker Press the power switch to the [ | ] position Preface If the power does not come on, check if the power breaker (main power switch) is switched to [ | ]. Powering Off ●... - Page 4 DocuWide 6035/6055 Features ● DocuWide 6035/6055 allows you to copy, print, and scan. DocuWide Print 6035/6055 Features Scan Mailbox Copy Using the touch panel, you can copy easily at the same and various other magnifications. User Guide P.49...
- Page 5 This feature allows you to check the various print settings, such as checking the image size machine status and job status from the DocuWide 6035/6055 while printing, to effectively use the DocuWide 6035/ computer via a web browser. (P.15) Features 6055. (P.10) ●...
-
Page 6: Programming
Copy Making a copy the same size as the document ● You can easily copy, simply by loading the document. Standard size Document Non-standard size Document Media Media Select [Copy]. Menu Language Copy Copy Scan Setup Menu Stored Programming Basic Image More Confirm selecting [100.0%] for... -
Page 7: Using The Numeric Keypad
Fitting the image to a fixed copy size ● By selecting the desired copy size, you can easily make copies with scaling. Various sized documents Media Document Media Select [Copy]. Menu Language Copy Scan Setup Menu Stored Programming Copy Basic Image More Auto R/E... -
Page 8: Numeric Keypad
Copying Multiple Documents [Collation] ● When copying multiple documents, collated output is available. [Uncollated] [Collated] Document A,B,C Document A,B,C Display the [Collation] screen for Menu Copy. Language Copy (1) Select [Copy]. (2) Select the [More Features] tab on the [Copy] screen. Basic Image More... -
Page 9: Background Suppression
Applies a stamp when copying. Use this feature when copying characters on the edge of You can specify Black or Gray as the stamp color. the document or making punch holes. User Guide (P.92) User Guide (P.85) Fuji Xerox 2008/08/08... - Page 10 Print Printing Using the Printer Driver ● The Printer Driver must be installed on the computer using the provided CD-ROM. Select [Print] from the application's [File] menu. Select [FX DocuWide 6055/6035] from Print the [Name] menu. Select the print settings, and click [OK].
- Page 11 Printing the Long Images Select [Print] from the application's [File] menu. (1) Select [FX DocuWide 6055/6035] from the [Name] menu. (2) Click [Properties]. Specify settings long documents. (1) Select the desired size from the [Paper Size] menu. (2) Select the media cut method from [Synchronized Cut]. (3) Click [OK].
-
Page 12: Refer To User Guide P
Secure Print (1) Specifying Secure Print from your Computer ● You can temporarily store data specified for printing on the machine, and then print it by operation on the machine. ● When using the accounting function, you can use Private Charge Print. Refer to User Guide P.149. - Page 13 Secure Print (2) Selecting Secure Print from the Machine Press the <Job Status> button. Copy from Transmitting Memory Copy Scan Menu Power Saver Job in memory Job Status Clear All Interrupt Stop Machine Status Start Log In/Out Retrieve the Secure Print document. Completed SecurePrint Close...
- Page 14 ● You can print using BT-PlotAssistant (optional) besides the printer driver. ● BT-PlotAssistant must be installed on the computer. For the installation method, refer to the BT-PlotAssistant User Guide. Click [Start] > [Program] > [Fuji Xerox] > [BT-PlotAssistant] > [BT- PlotAssistant] on the computer.
- Page 15 Checking the Machine Status and Job Status ● CentreWare Internet Services is a service with which you can confirm the print status and the machine status from a computer via a Web browser. Also, you can register mailboxes and retrieve documents scanned. (p.20) Start up the browser (1) Enter the device IP address in the browser address field.
-
Page 16: User Guide (P
Scan (Via network) ● Store the scanned document to a mailbox, and import it to your computer. Scan Install software and scan DocuWide Utilities CD-ROM Scan data Wide Format Scan Service DocuWide Utilities CD-ROM TWAIN-compliant Mailbox application Scanner driver Start Web browser and scan CentreWare Internet Services ●... - Page 17 ● This section describes the preparation for scanning with Wide Format Scan Service. Scan (Via network) Click [Start] > [Program] > [Fuji Xerox] > [Wide Format Scan Service] > [Wide Format Scan Service]. From [New] of the [File] menu, select [Mailbox].
- Page 18 Scan (1) Select the Mailbox, and Scan the Document Select [Scan]. Menu Language Copy Scan Setup Menu Stored Programming Select a Save in location (Mailbox) to store the scanned documents. Save in: Not Entered Mailbox Select the mailbox. Basic Image More (1) Select [Mailbox] on the [Scan] screen.
-
Page 19: Import The Documents
Stop Press to stop scanning. Scan (2)-1 Import Using Wide Format Scan Service Click [Start] > [Program] > [Fuji Xerox] > [Wide Format Scan Service] > [Wide Format Scan Service]. Import the documents. (1) Select the mailbox where the scanned documents are stored. - Page 20 If not changing the scanner, skip this step. Open a mailbox. (1) Select [Acquire] from the [File] menu. (2) Click [DocuWide 6035/6055], and then click [Next]. (3) Select the mailbox form [Mailbox List], and then enter a password into the [Password] field. Click [Next].
- Page 21 Scan (2)-3 Retrieving Documents with PC (CentreWare Internet Services) ● This section describes the procedure for importing documents from a machine mailbox to your computer using CentreWare Internet Services. CentreWare Internet Services allows you to import the mailbox-stored documents in the machine to your computer without using any application software.
- Page 22 Scan (Via USB) ● You can scan directly to computers connected to the machine via USB. Scan Install software and scan Scan data TWAIN-compliant USB TWAIN driver application Memory DW-Scan III Service (Option) Color Copy Assistant for DocuWide (Option) Color Copy Assistant Pro for DocuWide (Option) ●...
-
Page 23: Start Scanning
This section describes the procedure to import the scanned document to your computer using DocuWorks. For information about DocuWorks, refer to the DocuWorks online help. Click [Start] > [Program] > [Fuji Xerox] > [DocuWorks] > [DocuWorks Desk]. Select a scanner. -
Page 24: Paper Jams
Paper Jams Confirm the location of the paper jam according to the message displayed on the User Guide P.187 touch screen. Paper Jam Open the upper unit. Remove the jammed media. Release locking lever to unlock and close the upper unit. xxx-xxx Paper Jam Document Jam... - Page 25 Paper Jams In manual feed table Pull the media forward and remove it. Mis-setting of roll, discharging failure Open the roll tray and then rewind the roll Insert the lead edge of the roll tray under the paper. roller by turning the roll paper. In the area from roll tray to developer area Paper Jams...
-
Page 26: Loading Media
Loading Media ● When the following message appears on the touch screen, load the media. Install Media - Roll 3 ● It would be advisable to use paper/vellum/film Supply media. See the designated label recommended by our company on the machine. for instructions. - Page 27 Rotate the roll media until the lead edge is securely inserted into the bottom of the roller. The roll media is automatically loaded, and stops. Press the cutter button to trim the lead edge of roll media. Remove the piece of paper that was trimmed.
- Page 28 Media Settings ● Ensure to set the media settings when initially loading media in the machine or when changing the type or size series of the media. The media types for each media weight are as follows. Bond Vellum Film Light Xcellent80 : 80g/m Premium : 75g/m...
-
Page 29: Replacing Consumables
Replacing Consumables ● When the following message appears on the touch screen, load toner or replace the waste toner bottle. Replace Waste Toner Bottle Load Toner 1. Open the upper area Add toner. of the machine. ● Product code 2. Open the machine left See the outside of cartridge cover and follow the label package for instructions. - Page 30 Tap the bottom of the toner bottle repeatedly until all toner empties into the toner cartridge of the machine. Slide the lever to the right, and align it to the position (1). Remove the toner bottle (2). Close the toner cartridge panel cover, and lower the document cover into its original position.
-
Page 31: Troubleshooting
Refer to User Guide (P.35) side diameter of roll media is smaller than 100mm). DocuWide 6035/6055 Quick Guide Trouble shooting Fuji Xerox Co., Ltd. DE3987E2-1 (Edition 1) September 2008 Copyright 2008 by Fuji Xerox Co., Ltd. - Page 32 September 2008 Edition 1 604E34280 DE3987E2-1...
