Installation
Mounting the Camera (Continued)
Mounting the Camera using the Electrical Box
1 Remove the dome cover and inner dome (A page 13)
2 Mount the camera unit to the electrical box
Mount the camera unit to the electrical box using the mounting hole (2 locations)
with the M4 screw (2 pieces).
Memo The screws are not provided.
3 The procedures for the following are the same as that for normal
camera mounting.
- Connecting the cable (A page 15)
- Process after connection (A page 16)
- Adjusting images (A page 23)
- Mounting the dome cover (A page 17)
22
M4 Screw
.
.
4 Inch square
electrical box
