Summary of Contents for JVC UX-J99DVD
- Page 1 MICRO COMPONENT MD SYSTEM UX-J99DVD —Consists of CA-UXJ99DVD and SP-UXJ99DVD — CA-UXJ99DVD SP-UXJ99DVD INSTRUCTIONS GVT0123-002A [UB]...
- Page 2 CAUTION— button! Disconnect the mains plug to shut the power off completely (the STANDBY/ON lamp goes off). The does not disconnect the mains line. • When the unit is on standby, the STANDBY/ON lamp lights red. • When the unit is turned on, the STANDBY/ON lamp lights green.
- Page 3 Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm or more. 15 cm 1 cm 15 cm 10 cm UX-J99DVD Side view 15 cm 15 cm UX-J99DVD...
-
Page 4: About This Manual
Introduction We would like to thank you for purchasing one of our JVC products. Before operating this unit, read this manual carefully and thoroughly to obtain the best possible performance from your unit, and retain this manual About This Manual This manual is organized as follows: •... -
Page 5: Table Of Contents
Contents Location of the Buttons and Controls ... 3 Remote Control ... 3 Front Panel ... 4 Getting Started ... 6 Unpacking ... 6 Putting the Batteries into the Remote Control ... 6 Connecting Antennas ... 6 Connecting Speakers ... 7 Connecting a TV ... -
Page 6: Location Of The Buttons And Controls
Location of the Buttons and Controls Become familiar with the buttons and controls on your unit. Remote Control To open the cover of the remote control, push here, then slide downward. Remote Control See pages in parentheses for details. 1 FADE MUTING button (11) 2 VIRTUAL SURROUND button (31) 3 AHB PRO (Active Hyper Bass Pro) button (11) 4 DVD 8 (pause) button (17, 32, 35, 52) -
Page 7: Front Panel
f MENU button (20) g Multi control buttons • Cursor (2/3/5/∞) (10, 22, 26 – 33, 36) • ENTER button h ON SCREEN button (24 – 28, 30) j DIMMER button (12) k BASS/TREBLE button (12) l Number buttons • 1 – 10, 0 and +10 buttons •... -
Page 8: Location Of The Buttons And Controls
Location of the Buttons and Controls Display window on the front panel V C D V D 1 2 3 4 5 PROGRESSIVE GROUP Display window See pages in parentheses for details. 1 PROGRESSIVE indicator (12) 2 Disc operation indicators (17) •... -
Page 9: Getting Started
About the AUDIO-TV switch With the remote control supplied with this unit, you can also operate a JVC or other manufacturer’s TV. To operate this unit, set the AUDIO-TV switch to “AUDIO.” To operate a TV, set the AUDIO-TV switch to “TV.”... -
Page 10: Connecting Speakers
Getting Started (Continued) To connect an outdoor FM antenna Before connecting it, disconnect the supplied FM antenna. Outdoor FM antenna (not supplied) Coaxial cable (not supplied) A 75 Ω antenna with coaxial type connector (IEC or DIN45325) should be used. AM antenna ANTENNA Vinyl-covered wire... -
Page 11: Connecting A Tv
Connect your TV and this unit using the composite video cord (supplied), an S-video cord (not supplied) or component video cord (not supplied). • You can also connect a JVC’s TV through the AV COMPU LINK control system. (See page 84.) Component... -
Page 12: Connecting Other Equipment
Getting Started (Continued) To select the color system You need to select the color system setting of this unit to match to your TV. Set the NTSC/PAL switch on the rear correctly while in standby mode by referring to the table below. COMPONENT AUDIO ANTENNA... -
Page 13: Basic And Common Operations
Basic and Common Operations Setting the Clock Before operating the unit any further, first set the built-in clock. When you plug in the power cord, “0:00” starts flashing on the display. You can set the clock when the unit is either turned on or on standby (off). -
Page 14: Adjusting The Volume Level
Basic and Common Operations To turn off the unit automatically (Auto Standby) Using Auto Standby, the unit automatically turns itself off (on standby) if no operation is done for about 3 minutes except when playing back and when FM or AM is selected as the source. If an operation is done within this 3-minute period, Auto Standby is canceled temporarily even though no sound comes in. -
Page 15: Adjusting The Tone
To check the compatibility of your TV, contact your dealer. All JVC progressive TVs and High-Definition TVs are fully compatible with this system. * 525p and 480i indicate the number of scanning lines and scanning format of an image signal. -
Page 16: Listening To Fm And Am Broadcasts
Listening to FM and AM Broadcasts Setting the AM Tuner Interval Spacing Some countries AM channel intervals are set to 9 kHz apart, and some countries use 10 kHz apart. When shipped, the built-in AM tuner is set to 9 kHz spacing. You can change the channel interval to 9 kHz or 10 kHz spacing. -
Page 17: Presetting Stations
Presetting Stations You can preset 30 FM and 15 AM stations manually. In some cases, test frequencies have been already stored for the tuner since the factory examined the tuner preset function before shipment. This is not a malfunction. You can preset the stations you want into memory by following the presetting method. -
Page 18: Playing Back Discs On The 5-Dvd Changer
Playing Back Discs on the 5-DVD Changer indicates types of disc available for the operation. (Unavailable disc types are shown in halftone color.) • For MP3 and JPEG disc playback, see pages 35 and 36. (For how to make a program using MP3 discs is explained in this section.) Disc Information Playable disc types This unit has been designed to play back the following discs: DVD... - Page 19 Disc structure DVD VIDEO consists of “titles,” and each title may be divided into some “chapters.” For example, if a DVD VIDEO contains some movies, each movie may have its own title number and it may be further divided into some chapters. In a DVD VIDEO Karaoke, each song may have its own title number, but it may not be further divided into chapters.
-
Page 20: Loading Discs
Playing Back Discs on the 5-DVD Changer Loading Discs On the unit ONLY: Press one of the disc eject buttons (DISC10 – DISC50) for the disc tray you want to load a disc onto. The unit automatically turns on and the selected disc tray comes out if it is unlocked. -
Page 21: Start Continuous Play While A Source Other Than "Disc" Is Selected
To resume play, press DVD 3 ( or #¥8 DVD on the unit) again. To stop during play, press 7. To remove discs, press the corresponding disc eject buttons (DISC10 – DISC50) on the unit. • Disc playback sequence in the 5-DVD changer When 5 discs are loaded on the disc trays*, they are played in the following sequence (when Repeat Play is not activated): Ex.: When playback starts from the DISC2 tray:... - Page 22 Playing Back Discs on the 5-DVD Changer To go to a particular title, group, chapter or track directly using the number buttons On the remote control ONLY: For DVD VIDEO • Pressing the number buttons before playback allows you to start playing with the title number you want.
-
Page 23: Playing Back By Using The Disc Menu
Playing Back by Using the Disc Menu Some DVDs are recorded with their own menus which show their contents. SVCDs or VCDs with the Playback Control (PBC) function also have their own menus, such as lists of songs. You can play back the discs by using these menus. -
Page 24: Programing The Track Playing Order-Program Play
Playing Back Discs on the 5-DVD Changer Programing the Track Playing Order —Program Play You can arrange the order in which the chapters or tracks play before you start playing. You can program up to 99 steps. • Program Play may not be able to use with JPEG discs and some DVDs. -
Page 25: Playing At Random-Random Play
To check the programed contents On the TV screen: & Before or after playback Press PLAY/FM MODE. & During playback Press 7. (On the remote control) The programed contents appear on the TV. To erase the play mode screen, press PLAY/FM MODE again. PROGRAM Disc Group/Title... -
Page 26: Repeating Playback-Repeat Play
Playing Back Discs on the 5-DVD Changer To exit from Random Play On the remote control ONLY: Before or after play, press PLAY/FM MODE once or twice so that the unit enters another play mode (Continuous Play or Program Play). The RANDOM indicator goes off. -
Page 27: Advanced Disc Operations
Advanced Disc Operations This section explains advanced disc operations by using the remote control. For MP3 and JPEG playback, see pages 35 and 36. • See also “Basic Disc Operations” on pages 18 and 19. • indicates types of disc available for the operation. -
Page 28: Operation Through The On-Screen Bar
Advanced Disc Operations On-screen guide icons • During disc playback, the following guide icons may appear for a while on the TV: appears at the beginning of a scene containing multi- angle views. appears at the beginning of a scene containing multi- audio languages. - Page 29 7 Repeating Playback You can repeat playback of the current title or chapter (for DVD VIDEO), group or track (for DVD AUDIO) or track (for SVCD/ VCD/CD). • You can also repeat playback of a desired portion (A-B Repeat). To repeat a current title, group, chapter, or all tracks &...
- Page 30 Advanced Disc Operations To repeat a desired portion—A-B Repeat You can repeat playback of a desired portion by specifying the beginning (point A) and the ending (point B). • A-B Repeat cannot be used on some DVDs. • You cannot use A-B Repeat during Program and Random Play or while a disc is not playing.
- Page 31 Use the number buttons (0 – 9) to enter the time. You can specify the time in hours/ minutes/seconds for DVD VIDEO/DVD AUDIO, and in minutes/seconds for SVCD/VCD/CD. Ex.: To play back from a point of 1 (hours): 02 (minutes): 49 (seconds) from the beginning for DVD VIDEO/DVD AUDIO.
-
Page 32: Selecting The Audio Language
Advanced Disc Operations Selecting the Audio Language When a DVD contains audio languages (sound track), you can select the language (sound track) to listen to. icon appears at the beginning of playback when the current scene has plural audio languages. •... -
Page 33: Selecting A View Angle
Selecting a View Angle While playing back a DVD containing multi-view angles, you can view the same scene from different angles. icon appears at the beginning of playback when the current scene has multi-view angles. • You can also select the angle using the on-screen bar. See page 24 for details. -
Page 34: Creating A Realistic Sound Field
Advanced Disc Operations Creating a Realistic Sound Field With supplied two speakers, you can enjoy multi-channel surround sound. • This function only works for software containing more than 3-channel surround. & During playback Press VIRTUAL SURROUND. (On the remote control) The SURROUND indicator lights up on the display. -
Page 35: Special Picture Playback
Special Picture Playback This unit provides special picture playback functions including still picture, frame-by-frame, slow-motion, and zoom. 7 Still picture and frame-by-frame playback & During playback Press 8 once. Still picture appears—Still picture playback. Press 8 repeatedly. • Each time you press the button, the still picture advances frame by frame—Frame-by-frame playback. -
Page 36: Changing The Vfp Setting
Advanced Disc Operations Changing the VFP Setting The VFP (Video Fine Processor) function enables you to adjust the picture based on the picture tone, or personal preference. • There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 1 again. -
Page 37: Playing Back A Bonus Group
Playing Back a Bonus Group Some DVD AUDIOs have a special group called “bonus group” whose contents are not open to the public. The bonus group is always assigned to the last group of a disc (for example, if a disc contains 4 groups including a bonus group, “group 4”... -
Page 38: Mp3/Jpeg Disc Playback
Advanced Disc Operations MP3/JPEG Disc Playback This unit can play back MP3/JPEG files on a CD-R or CD-RW. We call a disc containing MP3 files “MP3 disc” and a disc containing JPEG files “JPEG disc” in this instruction. • For details about other discs (DVD, SVCD, VCD, CD) playback, see pages 17 to 34. -
Page 39: Operations Through The Mp3/Jpeg Control Screens
Operations through the MP3/JPEG CONTROL Screens You can search for and play the desired files in a group through the MP3/JPEG CONTROL screens shown on TV. MP3/JPEG CONTROL screen Ex.: When the current disc is an MP3 disc. Current Current group number/Total group number group MP3 CONTROL Time : 00:00:14... -
Page 40: Playing Back An Md
Playing Back an MD Playing Back the Entire MD —Normal Play Insert an MD into the MD loading slot. The MD is pulled in automatically. • If the current playing source is not “MD,” press MD 7 before going to the next step. MD loading slot CAUTION: During Power Save (see page 10), do not insert an... - Page 41 To go to another track Press ¢ or 4 repeatedly. (On the remote control) (On the unit) • ¢: Skips to the beginning of the next or succeeding tracks. • 4: Goes back to the beginning of the current or previous tracks.
-
Page 42: Programing The Track Playing Order-Program Play
Playing Back an MD Programing the Track Playing Order —Program Play You can arrange the order in which the tracks play before you start playing. You can program up to 32 tracks. • There is a time limit in doing the following steps. If the setting is canceled before you finish, start from step 3 again. -
Page 43: Playing At Random-Random Play
Playing at Random—Random Play The tracks of the loaded MD will be played at random. • Random Play ends when all the tracks are played once (when Repeat Play is not activated). • To use Repeat Play (see page 41) with Random Play, press REPEAT during or before Random Play. -
Page 44: Repeating Tracks-Repeat Play
Playing Back an MD To go to another track in the same group, press ¢ or 4 repeatedly. • ¢: Skips to the beginning of the next or succeeding tracks in the same group. • 4: Goes back to the beginning of the current or previous tracks in the same group. - Page 45 (2)Press the character entry button for a character you want to enter. Ex.: • To enter an “A” or “a,” press ABC once. To enter a “B” or “b,” press ABC twice. To enter a “C” or “c,” press ABC three times. •...
-
Page 46: Playing Back A Tape
Playing Back a Tape Playing Back a Tape You can play back type I tapes. Insert a cassette into the cassette loading slot with the exposed part of the tape facing left. • When the unit is turned on, the TAPE indicator appears on the display. -
Page 47: Listening To External Equipment
Listening to External Equipment Listening to External Equipment You can listen to external equipment connected to the AUX jacks and OPTICAL DIGITAL IN terminal on the rear of the unit. • First make sure that the external equipment is properly connected as follows (see also “Connecting Other Equipment”... -
Page 48: Recording On An Md
Recording on an MD Before You Start Recording on an MD • It may be unlawful to record or play back copyrighted material without the consent of the copyright owner. • When you record onto partially recorded MD, its contents are not erased or overwritten. The recording starts from the point following the last recorded track of the MD. -
Page 49: Setting Md Recording Modes
Stereo Long-Hour Recording (MDLP) This unit allows for 2 times or 4 times long-hour recording without losing stereo sound. With this feature, songs (tracks) can be recorded on a single MD using different recording length modes—SP: Standard Play, LP2: 2 Times Long Play, LP4: 4 Times Long Play. Signifies standard-hour stereo recording. -
Page 50: Recording Discs Onto An Md -Disc-Md Synchronized Recording
Recording on an MD Recording discs onto an MD —Disc-MD Synchronized Recording Using the disc synchronized recording method, you can start and stop disc play and MD recording at the same time. Load discs into the 5-DVD changer. • If the current playing source is not “DISC,” press DVD 3 (or #¥8 DVD on the unit), then 7 before going to the next step. -
Page 51: Recording Other Sources Onto An Md
To record a single track during play or pause While playing back or pausing a track you want to record, press MD REC. (On the remote control) The playback of the track is stopped, and the same track starts playing from the beginning again. This time, the MD recorder starts recording the track. - Page 52 Recording on an MD On the remote control ONLY: Press TR. MARK SELECT to select track mark entry mode. • Each time you press the button, entry mode changes as follows: MANUAL MARK TIME AUTO MARK AUTO MARK MANUAL MARK* Separates tracks manually by adding track marks at the places where you want.
-
Page 53: Recording On A Tape
Recording on a Tape Before You Start Recording on a Tape • It may be unlawful to record or play back copyrighted material without the consent of the copyright owner. • The recording level is automatically set correctly, so it is not affected by the volume level. Thus, during recording you can adjust the sound you are actually listening to without affecting the recording level. -
Page 54: Recording Onto A Tape
Recording on a Tape Recording onto a Tape You can use only type I tapes for recording. Prepare the source to record from. To record from a disc: (1) Load discs into the 5-DVD changer. • If the current playing source is not “DISC,” press DVD 3 (or #¥8 DVD on the unit), then 7 before going to the next step. -
Page 55: Recording Disc Onto A Tape -Disc-Tape Synchronized Recording
To record a single track of a disc (DVD AUDIO/SVCD/VCD/ MP3/CD)/MD during play On the remote control ONLY: While playing back a track of a disc or MD you want to record, press TAPE REC. The playback of the track is stopped, and the same track starts playing from the beginning again. -
Page 56: Recording Discs Onto An Md And A Tape -Disc Synchronized Recording
Recording on a Tape Recording Discs onto an MD and a Tape —Disc Synchronized Recording With this recording method, you can start and stop disc play, MD and tape recordings at the same time. Load discs into the 5-DVD changer. •... -
Page 57: Editing An Md
Editing an MD Guidance—MD Group Functions To add to the conventional MD Editing functions (called the track editing functions in this manual), MD Group functions help you to classify the tracks by making groups on your MD. Classifying the tracks on an MD MDLP enables you to record more tracks on a single MD than usual. -
Page 58: Introducing Group Editing Functions
Editing an MD (Continued) Introducing Group Editing Functions The groups and tracks can be edited in many ways (Group editing functions and Track editing functions). From this page to page 62, the group editing functions are explained. For details on the track editing functions, see pages 63 to 67. Forming a group (FORM GR): Page 56 This function forms a series of tracks or a single track into a new group. -
Page 59: Forming A Group-Form Gr
In the following examples of group editing, the process is explained from the very first—that is, inserting a disc. You can also edit an MD during playback (in Normal Play). Forming a Group—FORM GR This function allows you to form a group from a series of tracks which do not belong to the other groups. -
Page 60: Adding A Track To A Group-Entry Gr
Editing an MD (Continued) Adding a Track to a Group—ENTRY GR This function allows you to enter a track into a group. The track will be added as the last track in the selected group. The track numbers will be renumbered. •... -
Page 61: Dividing A Group-Divide Gr
Dividing a Group—DIVIDE GR This function allows you to divide one group into two separate groups. You cannot divide the group containing only a single track. When the original group has a title, two separate groups are reassigned the same title as the original group. Once a new group is divided, the other groups are renumbered. -
Page 62: Joining Two Groups-Join Gr
Editing an MD (Continued) Joining Two Groups—JOIN GR This function allows you to join two adjacent groups into a single group. When the groups have their own titles, the title of the preceding group is reassigned to the newly joined group. Once two groups are joined, the other groups are renumbered. -
Page 63: Moving A Group-Move Gr
Moving a Group—MOVE GR This function allows you to move a group. Once a group is moved, the tracks and the other groups are renumbered. • To stop any time during the editing process below before step 8 , press GROUP TITLE EDIT. Insert an MD you want to edit into the MD loading slot. -
Page 64: Ungrouping Tracks-Ungroup
Editing an MD (Continued) Ungrouping Tracks—UNGROUP This function allows you to dissolve a group. You cannot erase the tracks using this function. Once tracks are ungrouped, the other groups are renumbered. • To stop any time during the editing process below before step 6 , press GROUP TITLE EDIT. -
Page 65: Erasing Tracks In A Group-Erase Gr
Erasing Tracks in a Group—ERASE GR This function allows you to erase a group together with tracks in the group. You cannot resume the tracks in the erased group. Once a group is erased, the other tracks and groups are renumbered. •... -
Page 66: Introducing Track Editing Functions
Editing an MD (Continued) Introducing Track Editing Functions The groups and tracks can be edited in many ways (Group editing functions and Track editing functions). From this page to page 67, the track editing functions are explained. For details on the group editing functions, see pages 55 to 62. Dividing a track (DIVIDE): Page 64 This function divides a track by adding a track mark(s) in the desired point(s) in the middle or where you want to search for... -
Page 67: Dividing A Track-Divide
In the following examples of track editing, the process is explained from the very first—that is, inserting a disc. You can also edit an MD during playback (in Normal Play). Dividing a Track—DIVIDE This function allows you to divide one track into two separate tracks. -
Page 68: Joining Two Tracks-Join
Editing an MD (Continued) Joining Two Tracks—JOIN This function allows you to join two adjacent tracks into one track. When the tracks have their own titles, the title of the preceding track is reassigned to the newly joined track. Once two tracks are joined, the other tracks and/or the groups are renumbered. -
Page 69: Moving A Track-Move
Moving a Track—MOVE This function allows you to move a track to the position you prefer. It is useful to change the order of the tracks as you like. Once a track is moved, the tracks and/or the groups are renumbered. •... -
Page 70: Erasing Tracks-Erase
Editing an MD (Continued) Erasing Tracks—ERASE This function allows you to erase unwanted tracks. You cannot resume the erased tracks. Once tracks are erased, the other tracks and/or groups are renumbered. You can erase up to 15 tracks at a time. •... -
Page 71: Assigning Titles To An Md
Assigning Titles to an MD You can assign a name to each MD, to each group and to each track using alphabetic characters (uppercase and lowercase), symbols and numerals. Once a title is assigned, it is displayed for your confirmation. •... - Page 72 Editing an MD (Continued) Enter characters. (1) Press DISP/CHARA to select the character set you want. • Each time you press the button, the character set changes as follows: Capital letters & Symbols Numerals (2) Press the character entry button for a character you want to enter.
- Page 73 You can assign titles during play or recording • During play: Entering a track title The MD recorder repeats playback of the current track until you press ENTER in step 6 . When you press ENTER, the next track will be played.
-
Page 74: Using The Timers
Using the Timers There are three timers available—Recording Timer, Daily Timer and Sleep Timer. • Before using these timers, make sure the built-in clock is set correctly (see page 10). • When using the tuner as the source, preset stations in advance (see page 14). - Page 75 Select the device to record onto. (1) Press cursor 3/2 repeatedly to select the device. MD REC TAPE REC (2) Press SET. (3) When you select “MD REC,” select the recording length mode (see page 46) by pressing cursor 3/2, then press SET again.
-
Page 76: Using Daily Timer
Using the Timers Using Daily Timer With Daily Timer, you can wake up to your favorite music or radio program. • You can set Daily Timer whether the unit is turned on or off (on standby). • To correct a mis-entry any time during the setting process, press CANCEL. - Page 77 Adjust the volume level. (1) Press cursor 3/2 repeatedly to adjust the volume level. • You can adjust the volume level to “– –” or within the range of 0 (silent) to 40 (maximum). • When you select “VOLUME – –,” the volume is set to the volume level when you turn off the unit.
-
Page 78: Using Sleep Timer
Using the Timers Using Sleep Timer With Sleep Timer, you can fall asleep to your favorite music. • You can set Sleep Timer only when the unit is turned on. How Sleep Timer actually works The unit automatically turns off after the specified time length passes. -
Page 79: Initial Setting Using Choice Menu
Initial Setting Using Choice Menu You can adjust the initial settings through the choice menu on the You can use the choice menu only when the selected source is disc player and its playback is not started. Before operating... • Turn on your TV and select the correct input mode on the TV. •... -
Page 80: Operating Procedure
Initial Setting Using Choice Menu Operating Procedure Make sure that the disc player is selected for the source. Ex.: When setting MP3/JPEG. On the remote control ONLY: Press CHOICE. The LANGUAGE menu appears on the TV. LANGUAGE MENU LANGUAGE ENGLISH AUDIO LANGUAGE ENGLISH SUBTITLE... - Page 81 : shows the initial setting in the following tables. 7 Language selection menu—LANGUAGE LANGUAGE MENU LANGUAGE ENGLISH AUDIO LANGUAGE ENGLISH SUBTITLE ENGLISH ON SCREEN LANGUAGE ENGLISH • MENU LANGUAGE Some discs have multiple menu languages. Select one of the languages or language codes from AA to ZU (see “Language Code List”...
- Page 82 Select to activate this function. Select to deactivate it. • AV COMPU LINK MODE When connecting this unit to a JVC’s TV with the AV COMPU LINK remote control system, select the proper setting. Select one of the following settings:...
-
Page 83: Restricting The Access Level-Parental Lock
Restricting the Access Level—Parental Lock You can restrict playback of DVD VIDEO containing violent scenes and those unsuitable for your family members. Nobody can play such a disc unless this function is canceled. • You can set the Parental Lock only while a disc is not playing. •... - Page 84 Initial Setting Using Choice Menu 7 Changing the Parental Lock setting Press CHOICE, then press cursor 3/2 to display the OTHERS menu. Press cursor ∞/5 repeatedly to select (highlight) “PARENTAL LOCK,” then press ENTER. The PARENTAL LOCK submenu appears on the TV. •...
- Page 85 Country/Area codes list for Parental Lock Andorra United Arab Emirates Afghanistan Antigua and Barbuda Anguilla Albania Armenia Netherlands Antilles Angola Antarctica Argentina American Samoa Austria Australia Aruba Azerbaijan Bosnia and Herzegovina Barbados Bangladesh Belgium Burkina Faso Bulgaria Bahrain Burundi Benin Bermuda Brunei Darussalam Bolivia...
-
Page 86: Operating Other Manufacturers' Tv
Operating Other Manufacturers’ TV Changing the Preset Signal Codes To operate JVC or other manufacturers’ TV using this remote control: • Aim the remote control directly at the remote sensor on each equipment. • Refer also to the manuals supplied with your equipment. -
Page 87: Using Av Compu Link Control System
Using AV COMPU LINK Control System The AV COMPU LINK control system allows you to use JVC’s TV with simple operations. To use AV COMPU LINK control system, you need to connect this unit and a TV through the AV COMPU LINK terminals. -
Page 88: Glossary
Glossary Aspect ratio The ratio of horizontal and vertical sizes of a displayed image. The horizontal vs. vertical ratio of conventional TVs is 4:3 and that of wide-screen TVs is 16:9. Component video signal A video signal system where elements necessary for reproducing image signal comprised of the three primary colors of light are transmitted via separate signal lines. -
Page 89: Maintenance
Maintenance To get the best performance of the unit, keep your discs, tapes and mechanism clean. General Notes In general, you will have the best performance by keeping your discs, tapes and the mechanism clean. • Store discs and tapes in their cases, and keep them in cabinets or on shelves. -
Page 90: Additional Information
Additional Information MD Disc Types There are two types of MDs: Premastered (prerecorded) and Recordable (blank). Premastered MDs Premastered MDs, which have been recorded at music studio, can be played back like regular CDs. On an MD of this type, data is recorded as the presence or absence of tiny pits. -
Page 91: Scms (Serial Copy Management System)
SCMS (Serial Copy Management System) The MD recorder integrated to this unit uses the Serial Copy Management System which allows only first-generation digital copies to be made of premastered software (like CDs or prerecorded MDs). 1st Generation ABCDE FG MD limitations The MD records data in an original format that differs from that of conventional cassette tapes or DATs. -
Page 92: Output Signals Through The Dvd Optical Digital Out Terminal
Additional Information Output Signals through the DVD OPTICAL DIGITAL OUT Terminal Output signals differ according to the “DIGITAL AUDIO OUTPUT” setting. (See page 79.) DIGITAL AUDIO OUTPUT Playback disc DVD VIDEO with 48 kHz, 16/20/24 bit Linear PCM with 96 kHz, Linear PCM with Dolby Digital with DTS Digital Surround DVD AUDIO... - Page 93 For MD: Message BLANK DISC CANNOT ENTRY! CANNOT FORM! CANNOT GROUP! CANNOT JOIN CANNOT LISTEN CANNOT REC PBC PLAY CANNOT REC x1 ONLY CANNOT TITLE DISC FULL DISC PROTECTED EMERGENCY STOP GROUP FULL GROUP TRACK LOAD ERROR MD NO DISC NON AUDIO CAN NOT COPY PLAY BACK...
-
Page 94: Troubleshooting
Troubleshooting If you are having a problem with your unit, check this list for a possible solution before calling for service. If you cannot solve the problem from the hints given here, or the unit has been physically damaged, call a qualified person, such as your dealer, for service. -
Page 95: Specifications
Specifications Amplifier Section—CA-UXJ99DVD Output Power (IEC 268-3): 30 W (15 W + 15 W) at 4 Ω (10% THD) 40 W (20 W + 20 W) at 4 Ω (MAX) Analog input: AUX: Sensitivity/Impedance (at 1 kHz) 400 mV/47 kΩ (at “Input LEVEL 1”) 200 mV/47 kΩ... - Page 96 VICTOR COMPANY OF JAPAN, LIMITED EN, CS © 2003 VICTOR COMPANY OF JAPAN, LIMITED 1203AIMMDWJEM...
