Configuration Manual
Ascom d41 DECT Handset
4.8.1 Handset Replacement with WinPDM in DECT or IP-DECT System (release 3.1.x or
higher)
Note: The handset to be installed must not have any previous valid registrations. If it has a
valid registration, unsubscribe the handset or follow the instructions in
Replacement with WinPDM in DECT or IP-DECT System (release 3.0.x or lower)
1 Subscribe the new handset with the same extension number as the old handset. The
subscription procedure is described in User Manual, Ascom d41 DECT Handset,
TD 92582GB.
During the subscription procedure, the handset's User ID will automatically be set to
the same as the extension number. The User ID is used to identify the handset when
it is connected to PDM and will be visible in the Number column.
Tip: The User ID can be viewed by navigating to the menu:
Admin menu > Device info > User ID.
2 Insert the new handset into a desktop charger or rack charger connected to the PDM.
3 A dialogue window appears, asking the user to decide whether to use the Number
settings in PDM or the Number settings in the device. Select "PDM".
The handset will automatically be synchronized and all data and parameter settings
will be transferred to the new handset. The synchronization will take a while if the
Contacts in the original handset contains a large number of contacts.
4.8.2 Handset Replacement with WinPDM in DECT or IP-DECT System (release 3.0.x or
lower)
1 Insert the new handset into a desktop charger or rack charger connected to the PDM.
2 A dialogue window will be displayed. Select the option "Associate with number".
Follow the instructions and select the number of the old handset, see Installation and
Operation Manual, Portable Device Manager (PDM), Windows Version, TD 92325GB.
The handset will automatically be synchronized and all data and parameter settings
will be transferred to the new handset. The synchronization will take a while if the
Contacts in the original handset contains a large number of contacts.
3 Subscribe the new handset.
4.9 Brazil or other Latin America countries – DECT frequency configuration
Note: This chapter is only applicable if the handset is used in Brazil or other Latin
American countries.
In order to change the operating frequency band, the following preconditions must be
fulfilled:
• The frequency set to "Not initiated". This can be checked by entering the Admin
menu, see
Admin menu > Device info > Hardware.
Scroll down to "Frequency band".
• The handset must not have a DECT registration. If it already has, perform a Factory
reset, see
1 Enter the Admin Menu, see
21 December 2010/ Ver. E
6 Administration on page 24, follow the path:
4.5 Perform a Factory reset
6 Administration
on page 11.
on page 24.
TD 92641GB
4.8.2 Handset
on page 14.
14
