- Page 1 Quick Start Guide TWR-PXD20 32-bit Power Architecture MCU for ® Quality Industrial Display Solutions TOWER SYSTEM...
- Page 2 Connector TWR-PXD20 Freescale Tower System The TWR-PXD20 module is part of the Freescale Tower System portfolio, a modular development platform that enables rapid prototyping and tool re-use through reconfigurable hardware. The TWR-PXD10 can be used with a broad selection of Tower System peripheral modules, including the new TWR-LCD-...
- Page 3 TOWER SYSTEM TWR-PXD20 Features • MPXD2020VLU125 MCU (up to 125 MHz 32-bit e200z4d dual Issue core, five-stage pipeline, 4K I-Cache, OpenVG 2D graphics accelerator, dual graphics LCD module, 1 MB on-chip graphics SRAM, up to 1 MB on-chip flash with flash controller and video input unit) • Interfaces to the new TWR-LCD-RGB Tower System peripheral module (accepts RGB data directly from the PXD20 LCD controller) • MC9S08JM60 open source JTAG (OSJTAG) circuit • Embedded Serial-to-USB converter using OSJTAG interface • Two Spansion S25FL064P 64 MB QSPI memory • General-purpose TWRPI socket (Tower plug-in module) • On-board CAN transceiver • On-board RS485 half duplex transceiver • Two RGB LEDs for user interface • ADV7180 video decoder for video input capabilities • Two push buttons for user interface • Potentiometer for ADC testing...
- Page 4 “secondary” elevator. 3. Insert the TWR-PXD20 board into the Follow the primary and secondary elevator board. On-Screen Menu The “primary” and “secondary” cards for each module are indicated along the The demo is using the Open VG 2D card edges.
- Page 5 TOWER SYSTEM Additional Software and Tools • MQX™ RTOS • Swell software PEG graphical user interface (GUI) • Green Hills Software MULTI IDE • Serial bootloader utility • CodeWarrior V10.x Eclipse Development Studio • OSJTAG virtual serial port using USB • Rapid application initialization and documentation tool (RAppID) • FreeMASTER run-time debugging tool...
- Page 6 Quick Start Guide TWR-PXD20 Jumper Options The following is a list of all jumper options. The default installed jumper settings are shown in white text within the blue boxes. General Jumper Configuration Jumper Function Enable/Disable RGD LED 1 Enable/Disable potentiometer Enable/Disable RGD LED 2 Enable/Disable SW1 Enable/Disable user LED 4...
- Page 7 TOWER SYSTEM UART Configuration (continued) Jumper Position Function UART1 RX is connected to OSJTAG UART1 RX is connected to UART1_RX on primary elevator UART1 TX is connected to OSJTAG UART1 TX is connected to UART1_TX on primary elevator Boot Assistance Module Configuration Jumper Position Function...
-
Page 8: Warranty
Visit freescale.com/TWR-PXD20 for the latest information on the TWR-PXD20 module, including: • Board database: Schematics, layout and BOM • User manual • Quick start guide • Software BSPs and CodeWarrior • Demos and tutorial • Fact sheet Support Visit freescale.com/support for a list of phone numbers within your region. Warranty Visit freescale.com/warranty for complete warranty information. For more information, visit freescale.com/Tower Join the online Tower community at towergeeks.org Freescale, the Freescale logo and CodeWarrior are trademarks of Freescale semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. The Power... - Page 9 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Freescale Semiconductor TWR-PXD20...
