Freescale Semiconductor QorIQ TWR-LS1021A OOBE Demo Quick Start Manual

Freescale Semiconductor
Quick Start
QorIQ TWR-LS1021A OOBE Demo
Quick Start

1 Introduction

The new TWR-LS1021A-PB development board is the most
feature rich and high performance Tower system module
offered by Freescale. This board enables compatibility and
interoperability with other tower expansion modules. It
provides an easily accessible and interchangeable suite of
capabilities and features to support rapid prototyping and
software development. The TWR-LS1021A-PB board is
engineered to enable a wide range of applications, from IoT
Gateways to industrial controllers, Secure Access Points, and
asset management systems. The module offers a high level of
integration, excellent balance of performance-to-power, and
robust capability delivered by the QorIQ LS1021A
communications processor (which offers dual ARM Cortex-
A7 cores running at up to 1 GHz delivering over 5,000
Coremarks of performance at a typical power level of under 3
watts). This platform also provides a comprehensive level of
security, which includes secure boot, Trust Architecture, and
tamper detection, in both standby and active-power modes.
This document describes how you can run the out-of-box-
experience (OOBE) demo program, which shows the wireless
networking, graphics, and audio playing functionalities of the
TWR-LS1021A-PB board.
The access point features demo on LS1021A TWR platform is
illustrated in the figure below.
© 2015 Freescale Semiconductor, Inc.
Document Number: TWR-LS1021A_Demo_QS
Contents
1 Introduction................................................................1
2 TWR-LS1021A OOBE demo features. .................... 2
3 Hardware requirements................. ............................3
3.1 Kit contents.......................... .......................... 3
4 Preparing the system for the demo......... ...................4
4.1 Preparing SD card for demo......... ..................4
4.2 Configuring the board.....................................4
5 Setting up TWR-LS1021A-PB board..... .................. 4
6 Running the demos.................................................... 8
6.1 Wireless hotspot................... .......................... 8
6.2 Slideshow mode.................... .........................9
A Preparing SD card for demo................. .................. 10
B Configuring the TWR-LS1021A board. ................. 11
Rev. 0, 12/2015
