- Page 1 Quick Start Guide TWR-VF65GS10 For Vybrid Controller Solutions Based on ARM Cortex™-A5 and ® Cortex™-M4 Processors with the ARM DS-5™ Toolchain TOWER SYSTEM...
- Page 2 Module TWR-VF65GS10 Freescale Tower System The TWR-VF65GS10 module is a part of the Freescale Tower System, a modular development platform that enables rapid prototyping and tool re-use through reconfigurable hardware. Elevate your design to the next level and begin constructing your Tower System today.
- Page 3 TOWER SYSTEM Get to Know the TWR-VF65GS10 OpenSDA Device Battery Receptacle Mux for (VBAT) OpenSDA SPI/Vybrid Quad SPI Potentiometer Back Side of TWR-VF65GS10 Reset Configuration Module Line Drivers...
- Page 4 Quick Start Guide TWR-VF65GS10 Features • Vybrid VF61NS151CMK50 processor (dual-core ARM Cortex-A5 at 500 MHz + ARM Cortex-M4 at 167 MHz, 1.5 MB SRAM, dual Ethernet, dual USB, advanced security) • Kinetis K20DX128VFM5-based OpenSDA circuit • 1 Gb x 16 (128 MB) DDR3 in 96 FBGA package (Samsung) • 2 Gb x 16 (256 MB) NAND flash (Micron) • Two 128 MB (16 MB) quad I/O serial flash (Spansion) • Dual USB with on-chip PHY • Interfaces to TWR-LCD-RGB graphical LCD module • Four user-controlled status LEDs • Two mechanical push buttons for user input and one for reset • Potentiometer and MMA8451Q three-axis digital accelerometer • Micro SD card slot • Independent battery-operated power supply for real-time clock and tamper detection module...
-
Page 5: Configure The Hardware
Download Software Hardware and Tools • Assemble your Tower System per the Download installation software instructions found in the TWR-ELEV and documentation under module package, unless the board will “Jump Start Your Design” be used stand-alone. at freescale.com/TWR-VF65GS10. • Insert the dual-headed USB-A side of the provided USB cable into the PC and insert the micro-B end into the OpenSDA USB port (J3) on the TWR-VF65GS10 module. Allow the PC to automatically configure the USB drivers if needed. - Page 6 Locate and Install CDC Set up Serial Device Drivers Communication • The module will enumerate as a • A USB-to-serial bridge is supported composite “Mass Storage and Serial through the USB CDC functionality. CDC Device.” The drivers for the The serial port number is viewable CDC functionality can be found in the Device Manager (right click, on the enumerated drive (for example: My Computer>Properties>Device F:\TWR-VF65GS). Manager>Port Settings). This allows for serial communication between the • Go to that drive to find the CDC drivers Tower module and a terminal program and install them. running on the PC via the USB connection. • Setup a terminal program to use this COM port with the following settings: 115200 baud, eight data bits, no parity, one stop bit. Alternatively, you may use the TWR-SER or TWR-SER2 serial module for serial communication. See the TWR-VF65GS10 lab guide for more details.
-
Page 7: Start Debugging
TOWER SYSTEM Tilt the and transferred to Linux on the A5 core. You will also see Linux output on Board the OpenSDA serial connection set up • After the TWR-VF65GS10 module in Step 3. powers up, the U boot bootloader will Download the load the out-of-box demo from the Lab Guide SD card. The ARM Cortex-A5 core runs the Linux operating system and ® • Follow the TWR-VF65GS10 lab guide uses the Open SDA USB-to-serial at freescale.com/TWR-VF65GS10 bridge. The ARM Cortex-M4 core to further explore the features and runs the Freescale MQX™ operating capabilities of the out-of-box demo. system and uses the TWR-SER or... - Page 8 Quick Start Guide TWR-VF65GS10 Jumper Options The following is a list of all jumper options on the TWR-VF65GS10. The default installed jumper settings are shown in white text within the colored boxes. Jumper Option Setting Description VBAT Power Source, VBAT tied to main 3.3 V (VCC_3V3_MCU) Secure RTC, 32 kHz XOSC, Tamper and VBAT tied to coin cell Monitors VDD33 power to the MCU (P3V3 tied to VDD33 of device) MCU 3.3 V Supply VDD33 power to the MCU disconnected Pin 11 and 13 of JTAG connector floating JTAG 5 V Selection Pin 11 and 13 of JTAG connecter tied to 5 V EXT_WM0_TAMPER_IN tied to EXT_WM0_ TAMPER_OUT Tamper Loopback EXT_WM0_TAMPER_IN open; EXT_WM0_TAMPER_OUT open Connect MCU PTB9 pin to INT1 of MMA8451Q accelerometer Accelerometer Interrupt No accelerometer interrupt connection...
- Page 9 TOWER SYSTEM (continued from previous page) Jumper Option Setting Description Main Board 3.3 V Connect 3.3 V regulator output to P3V3 Filtered Supply Derived from Disconnect P3V3 from regulator output 5.0 V Supply P5V_ELEV tied to elevator sense Elevator 5 V Supply Disconnect P3V3 from regulator output 1-2 only Device, bus powered 2-3 only Device, self powered USB0 VBUS 1-2 and 3-4 Host Host 1-2 and 3-4 USB1 VBUS 1-2 only Device, self powered 2-3 only Device, bus powered...
- Page 10 Quick Start Guide TWR-VF65GS10 Jumper Settings (continued from previous page) Jumper Option Setting Description 12_345 Switch Settings Detail 00_xxx Boot from fuses Boot Configuration ON/INSTALLED-1, J22 10_000 Quad SPI boot OFF-0 Pins 1 to 10 SD card boot 10_110 8 10 7 9 10_001 NAND boot 01_xxx USB boot USB0 connected to Tower elevator...
- Page 11 TOWER SYSTEM (continued from previous page) Jumper Option Setting Description SCI1_RX connected to ELEV_UART1_RX SCI1_RX SCI1_RX connected to OpenSDA_UART_TX SCI2_RX connected to ELEV_UART1_RX SCI2_RX Select SCI2_RX connected to OpenSDA_UART_TX...
-
Page 12: Warranty
ARM Limited. Cortex-A5, Cortex-M4 and DS-5 are trademarks of ARM Limited. All other product or service names are the property of their respective owners. © 2013 Freescale Semiconductor, Inc. Doc Number: TWRVF65GS10QSG REV 2 Agile Number: 926-27442 Rev C...
