b. Y/C
connectors, you will need an 'S-Video to dual BNC' adapter. Attach the Y
(luma) connector of your device to the second analog BNC connector row
(labeled Pb). Attach the C (chroma) connector to the third analog connector
(labeled Pr).
c. Composite - Attach the device's connector to the first (top) analog connector.
2. Connect 3Play's audio outputs:
a. Analog audio – Connect external audio devices to the connectors in the AUDIO
OUT section.
Note that there are two rows of connectors; Connectors numbered 1a and so-
on provide Output A sound, while 2a etc. are assigned to Output B. These two
output sections are configured and controlled separately in the Replay Desktop.
3P
B, depending on 3Play's current Output Mode.
b. 3P
1cd in the AES section (below the analog audio outputs) section to connect
downstream AES/EBU (AES3) audio devices.
(A separate digital audio connection is not necessary for SDI output with
embedded audio.)
Hint: 3Play's SDI and analog output sections can be used simultaneously. For example, you could
use the Component output to view your program on a local analog video monitor at the same
time as you use the HD-SDI connection to supply broadcast equipment.

3.5.4 SUPPLEMENTAL VIDEO OUTPUTS

Additional dedicated video outputs make it possible to connect other devices to 3Play™ for a
variety of purposes, including program output for IMAG (Image Magnification) installations or
flexible monitoring for the convenience of the operator.
Page | 24
–
If your S-Video equipment and cabling has the usual 4-pin mini-DIN
™ 820 Aux (Row 3) – carries the same audio as either Output A or Output
LAY
™ 820 Digital audio – Use the two BNC connectors identified as 1ab and
LAY
