Clicking a tab labeled Cameras 1-x at left near the top of the screen reveals a group of video
preview windows, each representing one input. These previews (often referred to as ISO, or
Isolation monitors) display live video sources that are currently connected and configured.
Hint: Depending on your selections when creating the session, the sources displayed may or may
not be captured to disk when you enable recording. See Section 10.1 for details.
3P ™ 820 Tabs labeled Cameras 1-4 and Cameras 1-6 are very similar, but display
LAY
correspondingly fewer (and thus larger) monitors. These alternatives are convenient for use
when a production does not require the use of the full complement of inputs. The Recorded
Cameras tab shows only those sources configured for capture, and can be at once useful and
space-saving.

9.1.1 TITLEBAR FEATURES

Several useful features are located in the titlebar of each Input Monitor.
Figure 91
When you move your mouse pointer over an Input Monitor, the Configure button (gear) in the
titlebar brightens. Click this button to open the Input Configuration panel for that input (see
Section 7.2). Among other things, you can supply a custom name for the input in this panel; it
also holds Proc Amp and Audio settings.
