Denver CAD-350 Instruction Manual

Car stereo cd/cdr/cdrw/mp3 player with pll fm stereo radio rds detachable front panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

LOCATION OF PARTS AND CONTROLS
1
2
3
9
10
1. POWER ON/OFF (PWR)
2. FUNCTION SELECT BUTTON: BASS/TREBLE/BALANCE/FADER/TA SEEK/
MASK DPI/RETUNE/AUDIO DSP/LOUDNESS/ESP/BEEP/SEEK/STEREO/
LOCAL/VOL LAST (SEL)
3. VOL UP/VOL DOWN FOR BASS/TREBLE/BALANCE/FADER/TA SEEK/
MASK DPI/RETUNE/AUDIO DSP/LOUDNESS/ESP/BEEP/SEEK/STEREO/
LOCAL/VOL LAST (+/-)
4. PRESET STATIONS (1,2,3,4,5,6)
5. 'AF' function (ALTERNATIVE FREQUENCIES)
6. 'TA' function (TRAFFIC ANNOUNCEMENT)
7. 'PTY' function (PROGRAM TYPE)
8. DISPLAY (DISP)
9. MODE BUTTON (MD)
10. BAND (BND)
11. AUTOMATIC OR MANUAL TUNING (FREQ UP
12. AUTO SEEK SEARCH TUNING (A/PS)
13. 'SCAN' AUTOMATIC TUNING CONTROL (SCAN)
14. PANEL RELEASE BUTTON (
15. LCD DISPLAY
16. CD EJECT BUTTON (
17. CD SLOT
17
A/PS
13
12
)
15
4
(1-6)
)
E1
8
16
7
6
5
OR FREQ DOWN
14
11
)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAD-350 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Denver CAD-350

Summary of Contents for Denver CAD-350

  • Page 1 LOCATION OF PARTS AND CONTROLS A/PS (1-6) 1. POWER ON/OFF (PWR) 2. FUNCTION SELECT BUTTON: BASS/TREBLE/BALANCE/FADER/TA SEEK/ MASK DPI/RETUNE/AUDIO DSP/LOUDNESS/ESP/BEEP/SEEK/STEREO/ LOCAL/VOL LAST (SEL) 3. VOL UP/VOL DOWN FOR BASS/TREBLE/BALANCE/FADER/TA SEEK/ MASK DPI/RETUNE/AUDIO DSP/LOUDNESS/ESP/BEEP/SEEK/STEREO/ LOCAL/VOL LAST (+/-) 4. PRESET STATIONS (1,2,3,4,5,6) 5.

  • Page 2: Iso Connector

    ISO CONNECTOR RCA Jack Line Out: RCA Jack Line In: : Red (right) : Red (right) : White (left) : White (left) CONNECTOR A 4. MEMORY +12V 5. AUTO ANTENNA OUTPUT 7. +12V (TO IGNITION KEY) 8. GROUND Note: (connector A no. 7) must be connected by car ignition key in order to avoid that car battery becomes weak when the car will be not used for long period.

  • Page 3: To Support The Unit

    1. UNIT TO SUPPORT THE UNIT 2. RELEASE CASE 3. DASH BOARD 4. HEX NUT 5. LOCK WASHER Dashboard 6. PLAIN WASHER 7. CAR BODY 8. REAR SUPPORT STRAP 9. TAPPING SCREW 10. M5 X 15 HEX BOLT Detaching and attaching the front panel Front panel The front panel of this unit can be detached in order to prevent the unit from being stolen.
  • Page 4 1. POWER ON/OFF (PWR) By pressing this key, the unit is on and off. This unit is turned on by pressing any key. 2. FUNCTION SELECT BUTTON: BASS/TREBLE/BALANCE/FADER / TA SEEK/MASK DPI/ RETUNE/AUDIO DSP/LOUDNESS/ESP/BEEP/SEEK/STEREO/LOCAL/VOL LAST (SEL) When pressed short, it is activated as selecting mode of electric volume. VOL ---- BASS ---- TREB ---- BAL ---- FADER ---- VOL TA SEEK/TA ALARM When press the SEL button for more than 2 seconds, it is activated as selecting mode of...

  • Page 5: Beep Mode

    ESP MODE (2) When press the SEL button for more than 2 seconds, it is activated as 12 sec. or 45 sec. of ESP mode can be selected. 2 sec. TA SEEK MASK DPI RETUNE LOUD ESP12 / ESP 45 BEEP MODE When press the SEL button for more than 2 seconds, it is activated as selecting mode of these function.

  • Page 6: Using The Rds Function

    VOL LAST: The volume level which user adjust lately is selected whenever power is ON and OFF. VOL ADJ: The initial volume level (user can adjust) is selected whenever power is ON and 3. VOL UP/VOL DOWN FOR BASS/TREBLE/BALANCE/FADER (+/–) By pressing these key, you can adjust VOL/BASS/TREB/BAL/FAD and select the mode of TA SEEK/MASK DPI/RETUNE/AUDIO DSP/LOUDNESS/ESP/BEEP/SEEK/STEREO/LOCAL/ VOL LAST.
  • Page 7 7. 'PTY' function (PROGRAM TYPE) PTY MUSIC ---- PTY SPEECH ---- PTY OFF While selecting PTY type, its selection is implemented by preset buttons as described in preset key. When PTY is selected, the radio starts to search corresponding PTY information, and stops if the corresponding PTY information is detected.
  • Page 8 CD/MP3 CONTROL LOCATION OF PARTS A/PS 11. TRACK/SEARCH BUTTON FORWARD AND REVERSE TRACK SEARCH (or changing songs) Press the SKIP button ( ) during play to go to the desired track(song)..REVERSE ..FORWARD Press and hold the SKIP button ( ) during play to scan the disc at high speed.

  • Page 9: Technical Specifications

    The materials are recyclable as mentioned in this marking. By recycling, material recycling or other forms of re- utilization of old appliances, you are making an important contribution to protect our environment. Please inquire at the community administration for the authorized disposal location. ALL RIGHTS RESERVED COPY RIGHT DENVER ELECTRONICS A/S www.denver-electronics.com...

  • Page 10: Instruction Manual

    CAD-350 A/PS INSTRUCTION MANUAL CAR STEREO CD/CDR/CDRW/MP3 PLAYER WITH PLL FM STEREO RADIO DETACHABLE FRONT PANEL...
