Summary of Contents for Denver CAD-451
- Page 1 CAD-451 BLUETOOTH OPEN A/PS DISP COMPACT DIGITAL AUDIO 1 PAU 2 INT 3 RPT 4 RDM INSTRUCTION MANUAL CAR STEREO CD/CDR/CDRW/MP3 PLAYER WITH PLL FM STEREO RADIO USB / SD / MMC CARD INPUT BLUETOOTH FUNCTION FLIP DOWN/DETACHABLE FRONT PANEL...
-
Page 2: Location Of Parts And Controls
LOCATION OF PARTS AND CONTROLS OPEN A/PS DISP COMPACT DIGITAL AUDIO 1 PAU 2 INT 3 RPT 4 RDM (1-6) 1. POWER ON/OFF ( 2. FUNCTION SELECT BUTTON: BASS/TREBLE/BALANCE/ FADER / TA SEEK/MASK DPI/RETUNE/AUDIO DSP/ ENTER POWER MODE LOUDNESS/ESP/CD MULTI/BEEP/SEEK/STEREO/LOCAL (SEL) TUNE/SEEK 3. -
Page 3: Iso Connector
ISO CONNECTOR RCA Jack Line Out: RCA Jack Line In: : Red (right) : Red (right) : White (left) : White (left) CONNECTOR A 4. MEMORY +12V 5. AUTO ANTENNA OUTPUT 7. +12V (TO IGNITION KEY) 8. GROUND Note: (connector A no. 7) must be connected by car ignition key in order to avoid that car battery becomes weak when the car will be not used for long period. -
Page 4: To Support The Unit
1. UNIT TO SUPPORT THE UNIT 2. RELEASE CASE 3. DASH BOARD 4. HEX NUT 5. LOCK WASHER Dashboard 6. PLAIN WASHER 7. CAR BODY 8. REAR SUPPORT STRAP 9. TAPPING SCREW 10. M5 X 15 HEX BOLT Detaching and attaching the front panel The front panel of this unit can be detached in order to prevent the unit from being stolen. -
Page 5: Ta Seek/Ta Alarm
1. POWER ON/OFF (PWR) By pressing this key, the unit is on and off. This unit is turned on by pressing any key. 2,3.FUNCTION SELECT BUTTON: BASS/TREBLE/BALANCE/FADER / TA SEEK/MASK DPI/RETUNE/ AUDIO DSP/LOUDNESS/ESP/CD MULTI/BEEP/SEEK/STEREO/LOCAL (SEL) Turning the VOL knob Right or Left (3), you can adjust VOL/BASS/TREB/BAL/FAD. To select other functions, press the SEL (2) button shortly until the desired functions is shown on the display. - Page 6 LOUDNESS CONTROLS (2) When press the SEL button for more than 2 seconds, it is activated as selecting mode of these function. 2 sec. TA SEEK MASK DPI RETUNE LOUD ON/OFF LOUD ON/OFF mode is selected by . The bass and treble response will be boosted. ESP MODE (2) When press the SEL button for more than 2 seconds, it is activated as 12 sec.
-
Page 7: Preset Stations
“Local” position in areas with strong signals to let radio stop at only strong stations during manual tuning (LOC appears). Press to Distant position in areas with weak signals to listen to all stations. 4. PRESET STATIONS (1,2,3,4,5,6) (A) RADIO MODE: When pressed short, these keys select a preset station directly. - Page 8 CD/MP3 PLAYER MODE CDP ---- FREQ ---- CLOCK ---- NO PTY Each display time is several seconds, and come back to 1’st position after several seconds. Notes: • CT = clock time • FREQ = frequency • CDP = CD Player 9.
-
Page 9: Random Button
22. RANDOM BUTTON When this button is pressed, ‘RDM ON’ indication is displayed and each track of the disc are played in random instead of normal progression. To cancel RANDOM mode, press ‘RANDOM’ button (22) again. 23, 24. 10 TRACK UP/DOWN SELECT: (In case of MP3 files) M5: 10 Track down / M6: 10 Track up HOW TO SELECT MP3 FILES 1. -
Page 10: Technical Specifications
The materials are recyclable as mentioned in this marking. By recycling, material recycling or other forms of re- utilization of old appliances, you are making an important contribution to protect our environment. Please inquire at the community administration for the authorized disposal location. ALL RIGHTS RESERVED COPY RIGHT DENVER ELECTRONICS A/S www.denver-electronics.com...
