LOCATION OF PARTS AND CONTROLS BAND BAND 20 21 22 23 (1-6) 1. POWER ON/OFF ( . FUNCTION SELECT BUTTON: BASS/TREBLE/BALANCE/FADER/TA SEEK/ MASK DPI/RETUNE/AUDIO DSP/LOUDNESS/ESP/BEEP/SEEK/STEREO/ LOCAL/VOL LAST 3. VOL UP/VOL DOWN FOR BASS/TREBLE/BALANCE/FADER/TA SEEK/ MASK DPI/RETUNE/AUDIO DSP/LOUDNESS/ESP/BEEP/SEEK/STEREO/ RESET LOCAL/VOL LAST 4.
ISO CONNECTOR RCA Jack Line Out: RCA Jack Line In: Red (right) White (left) Red (right) White (left) CONNECTOR A 4. MEMORY +1V 5. AUTO ANTENNA OUTPUT 7. +1V (TO IGNITION KEY) 8. GROUND Note: (connector A no. 7) must be connected by car ignition key in order to avoid that car battery becomes weak when the car will be not used for long period.
TO SUPPORT THE UNIT 1. UNIT . RELEASE CASE 3. DASH BOARD 4. HEX NUT 5. LOCK WASHER Dashboard 6. PLAIN WASHER 7. CAR BODY 8. REAR SUPPORT STRAP 9. TAPPING SCREW 10. M5 X 15 HEX BOLT Front panel Detaching and attaching the front panel The front panel of this unit can be detached in order to prevent the unit from being stolen.
1. POWER ON/OFF ( By pressing this key, the unit is on or off. This unit is turned on by pressing any key. 2,3.FUNCTION SELECT BUTTON: BASS/TREBLE/BALANCE/FADER / TA SEEK/MASK DPI/RETUNE/ AUDIO DSP/LOUDNESS/ESP/CD MULTI/BEEP/SEEK/STEREO/LOCAL Turning the VOL knob Right or Left (3), you can adjust VOL/BASS/TREB/BAL/FAD. To select other functions, press the VOL knob shortly until the desired functions is shown on the display.
2 sec. 2 sec. TA SEEK TA SEEK / TA ALARM TA SEEK MASK DPI RETUNE RETUNE L / RETUNE S 2 sec. 2 sec. DSP can be selected by TA SEEK TA SEEK / TA ALARM TA SEEK MASK DPI MASK DPI / MASK ALL 2 sec.
Page 7
2 sec. TA SEEK MASK DPI RETUNE LOUD VOL LAST/ADJUST BEEP SEEK STEREO LOCAL LOCAL/DX When press the VOL knob for more than seconds, it is activated as selecting mode of these function. 2 sec. TA SEEK MASK DPI RETUNE LOUD VOL LAST /...
8. DISPLAY (DISP) Press DISP button to switch between display informations such as radio frequencies, clock, track and other informations depending on the playing MODE. 9. MODE BUTTON (MODE) By pressing this key, user can select. RADIO, CD/MP3 PLAYER or AUX IN mode. 10.
21. REPEAT BUTTON ‘RPT’ When you press ‘RPT’ button ‘RPT ON’ indication is displayed. Play of the selected track will be continually repeated until the Track Repeat mode is cancelled by pressing ‘RPT’ button (1) ‘RPT’ disappears. 22.RANDOM BUTTON ‘RDM’ When you press ‘RDM’...
The materials are recyclable as mentioned in this marking. By recycling, material recycling or other forms of re- utilization of old appliances, you are making an important contribution to protect our environment. Please inquire at the community administration for the authorized disposal location. ALL RIGHTS RESERVED COPY RIGHT DENVER ELECTRONICS A/S 022281 www.denver-electronics.com...
