Denver CAD-490 Instruction Manual

Car stereo cd/cdr/cdrw/mp3/wma player with pll fm stereo radio rds usb / sd / mmc card input flip down/detachable front panel

Advertisement

CAD-490
PWR
RELEASE
EJ
MD
PTY
A/PS
SCN
PAU
INT
RPT
RDM
TUNE/TRACK
1
2
4
5
DISP
3
6
TA
AF
BAND

INSTRUCTION MANUAL

CAR STEREO CD/CDR/CDRW/MP3/WMA PLAYER
WITH PLL FM STEREO RADIO
RDS
USB / SD / MMC CARD INPUT
FLIP DOWN/DETACHABLE FRONT PANEL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAD-490 and is the answer not in the manual?

Questions and answers

Summary of Contents for Denver CAD-490

  • Page 1: Instruction Manual

    CAD-490 RELEASE A/PS TUNE/TRACK DISP BAND INSTRUCTION MANUAL CAR STEREO CD/CDR/CDRW/MP3/WMA PLAYER WITH PLL FM STEREO RADIO USB / SD / MMC CARD INPUT FLIP DOWN/DETACHABLE FRONT PANEL...
  • Page 2: Location Of Parts And Controls

    LOCATION OF PARTS AND CONTROLS RELEASE A/PS TUNE/TRACK DISP BAND (1-6) 1. POWER ON/OFF ( 2. FUNCTION SELECT BUTTON: BASS/TREBLE/BALANCE/FADER / TA SEEK/MASK DPI/RETUNE/AUDIO DSP/LOUDNESS/ESP/CD MULTI/BEEP/SEEK/STEREO/LOCAL 3. VOL UP/VOL DOWN FOR BASS/TREBLE/BALANCE/FADER / TA SEEK/MASK DPI/ RETUNE/AUDIO DSP/LOUDNESS/ESP/CD MULTI/BEEP/SEEK/STEREO/LOCAL 4. PRESET STATIONS (1,2,3,4,5,6) 5.
  • Page 3: Iso Connector

    ISO CONNECTOR RCA Jack Line Out: RCA Jack Line In: : Red (right) : Red (right) : White (left) : White (left) CONNECTOR A 4. MEMORY +12V 5. AUTO ANTENNA OUTPUT 7. +12V (TO IGNITION KEY) 8. GROUND Note: (connector A no. 7) must be connected by car ignition key in order to avoid that car battery becomes weak when the car will be not used for long period.
  • Page 4: To Support The Unit

    1. UNIT TO SUPPORT THE UNIT 2. RELEASE CASE 3. DASH BOARD 4. HEX NUT 5. LOCK WASHER Dashboard 6. PLAIN WASHER 7. CAR BODY 8. REAR SUPPORT STRAP 9. TAPPING SCREW 10. M5 X 15 HEX BOLT Front panel Detaching and attaching the front panel The front panel of this unit can be detached in order to prevent the unit from being stolen.
  • Page 5: Power On/Off

    1. POWER ON/OFF ( By pressing this key, the unit is on and off. This unit is turned on by pressing any key. 2,3. FUNCTION SELECT BUTTON: BASS/TREBLE/BALANCE/FADER / TA SEEK/MASK DPI/RETUNE/ AUDIO DSP/LOUDNESS/ESP/CD MULTI/BEEP/SEEK/STEREO/LOCAL Turning the VOL knob Right or Left (3), you can adjust VOL/BASS/TREB/BAL/FAD. To select other functions, press the VOL knob shortly until the desired functions is shown on the display.
  • Page 6: Beep Mode

    LOUDNESS CONTROLS (2) When press the SEL button for more than 2 seconds, it is activated as selecting mode of these function. 2 sec. TA SEEK MASK DPI RETUNE LOUD ON/OFF LOUD ON/OFF mode is selected by . The bass and treble response will be boosted. ESP MODE (2) When press the SEL button for more than 2 seconds, it is activated as 12 sec.
  • Page 7: Display (Disp)

    “Local” position in areas with strong signals to let radio stop at only strong stations during manual tuning (LOC appears). Press to Distant position in areas with weak signals to listen to all stations. 4. PRESET STATIONS (1,2,3,4,5,6) (A) RADIO MODE: When pressed short, these keys select a preset station directly.
  • Page 8 11. AUTOMATIC OR MANUAL TUNING (FREQ UP OR FREQ DOWN (A) RADIO MODE When pressed short, these keys are operated as MANUAL tuning mode. When pressed longer than 1 sec., they are operated as SEEK tuning mode. (B) CD/MP3/WMA PLAYER MODE When pressed short, they are operated as TRACK UP or TRACK DOWN mode.
  • Page 9: How To Select Mp3/Wma Files

    HOW TO SELECT MP3/WMA FILES 1. Searching Track: • Press “A/PS”, then searching track is activated. • Press “VOL”, then the first digit is blinking. • With “VOL / VOL ” knob, select first digit you want. • Press “VOL”, then the first digit is fixed and second digit is blinking. •...
  • Page 10: Technical Specifications

    The materials are recyclable as mentioned in this marking. By recycling, material recycling or other forms of re-utilization of old appliances, you are making an important contribution to protect our environment. Please inquire at the community administration for the authorized disposal location. ALL RIGHTS RESERVED COPY RIGHT DENVER ELECTRONICS A/S 022680 www.denver-electronics.com...
