INSTALLATION & OPERATING
CAUTION:
03/04
INSTRUCTIONS
IB75 B-VENT GAS APPLIANCE
Note:
An arrow (Æ found
in the text signifies change
in content.
WARNING!
35048 Rev L
WARNING:
If the information in this manual
is not followed exactly, a fire or explosion may
result causing property damage, personal in-
jury or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— What to do if you smell gas
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
fire department.
— Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Heatilator IB75
Summary of Contents for Heatilator IB75
- Page 1 INSTALLATION & OPERATING INSTRUCTIONS IB75 B-VENT GAS APPLIANCE WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal in- jury or loss of life. — Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
-
Page 2: Table Of Contents
IB75 B-VENT GAS APPLIANCE Please retain this manual for future use. Table of Contents Design and Installation Considerations ........................3 Appliance Specifications ............................... 4 Location and Clearances .............................. 5 C. Framing ..................................6 D. Setting the Appliance ..............................6 Venting ..................................7 Utilities ................................... -
Page 3: Design And Installation Considerations
IB75 B-VENT GAS APPLIANCE Design and Installation Considerations When selecting a location for your B-Vent appliance, it is important to evaluate a number of considerations. Modern construction techniques can create conditions that may not allow your vent to draft properly. This may result in spillage from your B-Vent appliance, as well as cause other combustion appliances to operate incorrectly. -
Page 4: Appliance Specifications
1. U.S. and Canada Certification Note: Minimum and maximum clearances must be main- The IB75 Gas Appliance has been tested in accordance tained at all times. Illustrations throughout these instruc- with the standards tions reflect typical installations and are for design pur- , and has been listed by Underwriters Laboratories poses only. -
Page 5: Location And Clearances
CAUTION: Figure 1 illustrates a variety of ways the appliance may be located in a room. The IB75 may be installed directly on the floor or raised on a hearth. These appliances are certified for installation in a bedroom or bed/sitting room in the U.S. -
Page 6: Framing
IB75 B-VENT GAS APPLIANCE C. FRAMING Figure 3 shows typical framing of this appliance using combustible materials and the minimum mantel heights. All required clearances to combustibles must be adhered to. Figure 4 shows rough framing dimensions. CAUTION: CAUTION: WARNING! D. -
Page 7: Venting
IB75 B-VENT GAS APPLIANCE E. VENTING Note: This appliance requires an 8 in. B-vent for operation. Never down-size 1. Clearances WARNING - RISK OF FIRE! Vent clearances are per vent manufacturer’s specifications. 2. Vent Lengths Various venting configurations are shown in Figures 5 and 6 from which maximum vent runs can be determined. - Page 8 IB75 B-VENT GAS APPLIANCE 4. Chase/Termination Installation that the damper blade moves freely and does not scrape or bind on any of the damper components. Figure 8 and Table 1 specify minimum vent heights for While the appliance is in operation, visually check that various pitched roofs.
-
Page 9: Utilities
1000 feet above sea level. Check with the local gas utility for proper orifice size identification. The correct orifice is available from your Heatilator distributor. For Canada, appliances are certified for elevations from 0-4500 feet. When installing this appliance at an elevation between 0-4500 feet in Canada, the input rating does not need to be reduced. - Page 10 IB75 B-VENT GAS APPLIANCE WARNING! Note: This appliance and its manual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5 kPa). The appliance must be isolated from the gas supply piping system by closing its manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa).
- Page 11 IB75 B-VENT GAS APPLIANCE This appliance is equipped with an intermittent pilot control valve which operates on a 3 volt system. See wiring diagram, Figure 12. The appliance is supplied with a battery pack and a 3 volt AC transformer, which requires the installation of the supplied JK9 Junction Box Kit.
-
Page 12: Finishing
IB75 B-VENT GAS APPLIANCE G. FINISHING 1. Combustible Finishing Material Material made of or surfaced with wood, compressed paper, plant fibers, plastics, or any material capable of igniting and burning, whether flame proofed or not, plastered or unplastered (this includes drywall). - Page 13 IB75 B-VENT GAS APPLIANCE 2. Log Set Unwrap the top left log (shipped inside the valve compartment) and position it over the pins in the proper location. The log set should look similar to that on page 20. 3. Place the Lava Rock and Vermiculite Place lava rock on top of the control access panel, in front of, under and around burner.
-
Page 14: Lighting Instructions
IB75 B-VENT GAS APPLIANCE I. LIGHTING INSTRUCTIONS Intermittent Pilot Ignition FOR YOUR SAFETY READ BEFORE OPERATING WARNING! This appliance is equipped with an ignition device which automatically lights the pilot. try to light the pilot by hand. smell all around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor. -
Page 15: Seasonal Checklist
IB75 B-VENT GAS APPLIANCE J. SEASONAL CHECKLIST WARNING! CAUTION: Note: Installation and repair should be done by a qualified service person. The appliance should be inspected before use and at least annually by a qualified service person. More frequent cleaning may be required due to excessive lint from carpeting, bedding material, etc. -
Page 16: Start-Up Issues
IB75 B-VENT GAS APPLIANCE 2. Fuel Conversion Instructions Natural or propane gas conversions necessary to meet the application need to be made by a qualified technician using Hearth & Home Technologies specified and approved parts. In the event your appliance must be converted to use propane, you must use a Conversion Kit. -
Page 17: Maintenance Instructions
IB75 B-VENT GAS APPLIANCE L. MAINTENANCE INSTRUCTIONS 1. Clean the Burner and Control Compartment Keep the burner and control compartment clean by brushing and vacuuming at least once a year. Always turn off the wall switch (or remote control) and gas valve before cleaning. - Page 18 4. High Limit Safety Switch A limit switch has been installed on the IB75. This switch automatically turns off the appliance if it becomes too hot. If this happens, do not attempt to operate the appliance until it has been examined by a qualified service technician.
-
Page 19: Log Removal/Replacement
IB75 B-VENT GAS APPLIANCE M. LOG REMOVAL/REPLACEMENT Remove the lava rock from the appliance and save. The top log is placed over the pins in the back log. For removal of the front grate/log assembly remove two screws (one per side) from the hearth pan. See Figure 24. -
Page 20: Replacement Parts
IB75 B-VENT GAS APPLIANCE N. REPLACEMENT PARTS Replacement parts are available from your distributor/dealer. 35048 Rev L 03/04... - Page 21 IB75 B-VENT GAS APPLIANCE 03/04 35048 Rev L...
-
Page 22: Optional Components
IB75 B-VENT GAS APPLIANCE O. OPTIONAL COMPONENTS 35048 Rev L 03/04... -
Page 23: Index
IB75 B-VENT GAS APPLIANCE Index Air Kit Gas Codes 4 Nailing Flanges 6 Installation 9 Gas Conversion 16 Operation 16 Gas Conversions 10 Air Shutter 17 Gas Line Connection 9 Odor 2, 16 Air Shutter Adjustment 17 Gas Pressure 10... -
Page 24: Limited Lifetime Warranty
If the Heatilator Appliance is found to be defective in either material or workmanship within one year of the date of original installation, HHT will provide replacement parts at no charge and pay reasonable labor and freight costs, and is for the period of one year following the date of original installation of the Appliance.
