Heatilator I100 Owner's Manual
Wood burning fireplace
Hide thumbs
Also See for I100:
- Owner's manual (52 pages) ,
- Installation manual (45 pages) ,
- Brochure & specs (2 pages)
Table of Contents
Advertisement
Quick Links
Models:
I100
Wood Burning Fireplace
•
Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfi re. Overfi ring will void your
warranty.
• Comply with all minimum clearances to
combustibles as specifi ed. Failure to
comply may cause house fi re.
Installation and service of this fi replace
should be performed by qualifi ed personnel.
Hearth & Home Technologies suggests NFI
certifi ed or factory-trained professionals, or
technicians supervised by an
NFI certifi ed professional.
NOTICE
DO NOT DISCARD THIS MANUAL
•
Read, understand
and follow these
instructions for safe
i n s t a l l a t i o n a n d
operation.
Heatilator • I100 • 35144 • Rev AE 1/11
Owner's Manual
Installation and Operation
•
Leave this manual with
party responsible for
use and operation.
WARNING
Hot screen/mesh and glass doors will cause burns.
•
DO NOT touch screen/mesh or glass doors until
cooled
•
NEVER allow children to touch screen/mesh or glass
doors
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fi replace.
•
Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other
fl ammable materials.
•
Keep clothing, furniture, draperies and other
fl ammable materials away.
WARNING
Fire Risk
•
For use with solid wood fuel or decorative
gas appliance only.
•
DO NOT install unvented gas logs.
HOT SURFACES!
Screen/mesh, glass doors
and other surfaces are hot
during operation AND cool
down.
1
