AXE100 CX
Instruction Manual
®
HMXE0818 Axe 100
HMXE0828 Axe 100
CX RTF
CX Tx-R
Advertisement
Table of Contents
Related Manuals for Heli-Max AXE100CX
Summary of Contents for Heli-Max AXE100CX
-
Page 1: Instruction Manual
The instruction manual, warranties and other associated documentation are subject to change without notice. Hobbico assumes no responsibility for inadvertent errors in this manual. Heli-Max products are to be used by ages 14 and over. HMXE0818 Axe 100 CX RTF ©... -
Page 2: Technical Support
INTRODUCTION INTRODUCTION Thank you for purchasing the Heli-Max AXE 100 CX Helicopter. We are certain you will get many hours of enjoyment out of this model. If you should have any questions or concerns please feel free to contact us at: helihotline@hobbico.com. -
Page 3: Warranty
In no case shall Heli-Max’s liability exceed the original cost of the purchased kit. Further, Heli-Max reserves the right to change or modify this warranty without notice. In that Heli-Max has no control over the final assembly or material used for final assembly, no liability shall be assumed nor accepted for any damage resulting from the use by the user of the final user-assembled product. -
Page 4: Specifications
CONTENTS AXE100 CX RTF AXE100 CX RTF AXE 100 CX Helicopter TX 410 4-Channel SLT Transmitter Heli-Max 150mAh LiPo Battery pack (1) USB Charger Small Phillips screwdriver AA Batteries (4, not included in the Tx-R version.) SPECIFICATIONS Rotor Diameter: 190mm (7.48") Empty Weight: 28.2g (.995 oz) -
Page 5: Operational Warnings
® OPERATIONAL WARNINGS OPERATIONAL WARNINGS ● Failure to follow these safety precautions may result in injury to yourself and others. ● Your AXE 100 CX should not be considered a toy. It should be treated as a working model that functions much like a full-size helicopter. Keep your face and body as well as all spectators away from the rotating blades whenever the battery is connected. -
Page 6: Battery Charging
® BATTERY CHARGING BATTERY CHARGING ● Please read and understand the following regarding the usage of LiPo batteries. ● Through the use of the included LiPo battery you have assumed all risk and responsibility regarding a LiPo battery and its use. ●... - Page 7 WARNING!! The charger supplied with the Heli-Max AXE 100 CX helicopter contains protective circuitry. If you experience any diffi culties while charging the battery, please disconnect the battery from the charger and unplug the charger from the power source. Allow the battery and charger to rest for two hours as this will allow the charge protection circuit to reset.
-
Page 8: Dual Rates
DUAL RATES The transmitter has a dual rate function. This feature toggles between a flight mode that reduces the model’s range of motion to make the AXE 100 CX easer to fly and one that allows the full range of motion so the AXE 100 CX can fly in a more aggressive manner. -
Page 9: Servo Reversing
SERVO REVERSING This transmitter uses the Tactic SLT protocol and can be used with other SLT receivers. In those applications, it may be necessary to reverse the servo travel direction as follows: With the transmitter OFF, push and “hold” the rudder trim button to the right and the throttle trim button down. - Page 10 , JR , Spectrum or other compatible system, you can fly your Heli-Max AXE 100 CX with a familiar transmitter. Any other SLT compatible aircraft transmitters like the Tactic TTX402/TTX403 can also be used with the 100 CX. The following setup guides for Futaba, Spektrum, and Tactic systems should work for most transmitters that are currently available.
-
Page 11: Preflight Procedures
® PREFLIGHT PROCEDURES PREFLIGHT PROCEDURES Electric motors are very dangerous. Do not work on the model while the fl ight battery is plugged in as interference may cause the main rotor blades to spin, possibly causing injury. ● Examine the model for any loose screws and damaged parts. Make sure that the linkage and the rotor blades are not loose. -
Page 12: Basic Maneuvers
LANDING Level the helicopter into a steady hover and slowly decrease power until the helicopter settles onto the ground. You might notice as the helicopter is ready to touch down it moves around a little. This is normal as the helicopter enters ground effect. -
Page 13: Maintenance
® MAINTENANCE MAINTENANCE We will describe a few simple repairs that you can do to your helicopter. We will list the steps needed to remove the part with the understanding that to reassemble, one just follows the steps in the reverse order. NOTE: It’s a good idea to use a small tray with a magnet below it to help secure the small screws. -
Page 14: Removing The Landing Gear
pull the blades apart. When installing the rotor blades, please keep in mind that the lower set rotates clockwise and the upper set rotates counter-clockwise. REMOVING THE LANDING GEAR The landing gear has two pegs that hold it onto the helicopter frame. Gently pull down to remove the landing gear. -
Page 15: Replacing Motors
REMOVING THE MAIN SHAFTS The inner rotor shaft can be removed after the lower main gear is loose. If this part is to be replaced, the upper rotor blade and flybar will have to be removed and transferred to the new rotor shaft. Before the outer rotor shaft can be removed, the links from the servos need to be removed from the swashplate. -
Page 16: Replacement Parts
® REPLACEMENT PARTS REPLACEMENT PARTS 1 HMXE2301 Flybar 12 HMXE2313 Motor Set 2 HMXE2302 Flybar Pin 13 HMXE2314 Bearing Set 3 HMXE2303 Inner Shaft 14 HMXM2055 E-Board 4 HMXE2304 Outer Shaft 15 HMXE2315 O-Ring Set 5 HMXE2306 Rotor Blade Set 16 HMXE2316 Main Gear Set 6 HMXE2307 Rotor Hub... - Page 18 Notes:...
- Page 19 Notes:...
