Bellavista
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
919-388e
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
B36XTCE
®
Gas Fireplace
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
MODEL: B36XTCE-10
Medium DV Gas Fireplace
Bellavista
B36XTCE Video
www.regency-fire.com
07.23.18
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency Fireplace Products Bellavista B36XTCE-10
Summary of Contents for Regency Fireplace Products Bellavista B36XTCE-10
- Page 1 Owners & Bellavista B36XTCE ® Installation Manual Gas Fireplace MODEL: B36XTCE-10 Medium DV Gas Fireplace Bellavista B36XTCE Video www.regency-fire.com WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The Bellavista™ B36XTCE has been designed to ® provide you with all the warmth and charm of a wood fireplace at the flick of a switch. The Bellavista™ B36XTCE has been approved by Warnock Hersey/Intertek for both safety and efficiency.
- Page 3 MANUFACTURED MOBILE HOME REQUIREMENTS INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This Regency product has been tested and listed by Warnock Hersey as a Direct Vent Wall Furnace to the following standards: VENTED ® GAS FIREPLACE HEATERS ANSI Z21.88-2014 / CSA 2.33-2014 and GAS-FIRED APPLIANCES FOR USE AT HIGH ALTITUDES CAN / CGA 2.17-M91.
-
Page 4: Table Of Contents
table of contents Copy of Safety Decal .............5 Three (3) 90 Elbows (Rigid Pipe 4" x 6 - 5/8") ....37 MA Code - CO Detector ..........6 venting arrangements ..........38 Unit Dimensions ............7 With Co-linear Flex System .........38 Vertical Terminations ...........39 Installation Co-linear Flex System Into Masonry Fireplaces .39 Unit Installation with Horizontal Termination ....40... -
Page 5: Copy Of Safety Decal
Minimum Vent Clearances: Horizontal Top 2" (51mm) Horizontal Side 1-1/2" (38mm) Horizontal Bottom 1-1/2" (38mm) Vertical Vent 1-1/2" (38mm) safety decal This is a copy of the label that accompanies each Bellavista™ B36XTCE Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being improved. -
Page 6: Ma Code - Co Detector
requirements MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:... -
Page 7: Unit Dimensions
dimensions UNIT DIMENSIONS 33" (838mm) 40-5/8" (1032mm) 7-7/16" (188mm) 3-1/4" (79mm) 29-7/8" (759mm) 32-7/8" (759mm) ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. Bellavista ® B36XTCE-10 Gas Fireplace... -
Page 8: Important Message
installation IMPORTANT MESSAGE 3. See general construction and assembly in- YOUNG CHILDREN SHOULD BE CARE- structions. The appliance and vent should be SAVE THESE FULLY SUPERVISED WHEN THEY ARE enclosed. INSTRUCTIONS IN THE SAME AREA AS THE APPLI- 4. This appliance must be connected to the speci- ANCE. -
Page 9: Installation Checklist
installation INSTALLATION This includes: 4. This appliance is Listed for bedroom instal- CHECKLIST lations using the standard Remote (millivolt 1. Clocking the appliance to ensure the correct firing rate (rate noted on label 31,000 Btu/h thermostat system). Some areas may have 1. -
Page 10: Clearances
installation CLEARANCES The clearances listed below are Minimum distances unless otherwise stated: A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this fireplace and vent system be installed only in accordance with these instructions. WARNING Caution Requirements Fire hazard is an extreme risk... -
Page 11: Mantel Clearances
installation MANTEL CLEARANCES Due to the extreme heat this fireplace emits, the mantel clearances are critical. Combustible mantel clearances from top of front facing are shown in the Diagram on the right. Note: A non-combustible mantel may be installed at a lower height if the framing is made of metal studs covered with a non- combustible board. -
Page 12: Mantel Leg Clearances
installation MANTEL LEG CLEARANCES TopView Side opening of fireplace 3.5” 6.5" Allowable mantel leg projection. 12" NON- COMBUSTIBLE REQUIREMENTS: 40-5/8" [1032mm] 9-1/4" [235mm] Non combustible - supplied w/unit No Combustible 8-3/8" Materials in this Area [213mm] NO FACING OR FINISHING MATERIAL IN THIS AREA 4-1/8"... -
Page 13: Framing
installation FRAMING Framing Dimensions Description B36XTCE Framing rise from floor 0" Framing Width 41-1/4"(1048mm) Framing Height 46-3/4" (1213mm) O (Rear Vent) Framing Depth - Rear Vent 23-7/8" (606mm) O (Top Vent) Framing Depth - Top Vent 23-7/8" (606mm) P (Top Vent) Corner Facing Wall Width 53-1/4"... -
Page 14: Framing & Finishing
installation FRAMING & FINISHING 1. Frame in the enclosure for the unit with framing material. Note: When constructing the framed opening, please ensure there is access to install the gas lines when the unit is installed. 2. For exterior walls, insulate the enclosure to the same degree as the rest of the house; apply vapour barrier and drywall, as per local installation codes. (Do not insulate the fireplace itself.) WARNING: Failure to insulate and add vapor barriers to the inside of the exterior wall will result in operational and performance problems including, but not limited to: excessive condensation on glass doors, poor flame package, carbon, blue flames etc. - Page 15 installation 7. Non-combustible material (ie. tile, slate, etc) may be brought up to the edge of the glass door of the unit. Minimum clearances must be adhered to, this will assure ease of glass door removal and access to the lower panel. NOTE: Non-combustible finishing materials may be of any thickness desired.
-
Page 16: Unit Assembly Prior To Installation
installation UNIT ASSEMBLY PRIOR TO INSTALLATION The Top Nailing Support, the Side Nailing Strips, the 2 Top Standoffs and the Flue Collar must be correctly positioned and attached before the fireplace is moved into position. TOP STANDOFF ASSEMBLY STANDOFF SLOT LOCATION The top standoffs are shipped in a flat position and must be folded into shape and attached. -
Page 17: Conversion To Top Vent
installation CONVERSION TO TOP VENT Note: This conversion must be done prior to the unit being placed in position. The unit comes equipped as a rear vent unit. These instructions are to be used, only if the unit is going to be top vented. Top Collar Assembly Kit Exhaust Assembly Intake Cover Plate... - Page 18 installation 5. From the outside rear of the firebox, remove the intake collar assembly. Remove the 4 - 1/4" x 1/2" screws. See Diagram 5. Diagram 9 Exhaust Assembly Intake Collar Assembly 9. From the outside top of the firebox, install the intake collar assembly. Secure with 4 - 1/4"...
-
Page 19: Vent Restrictor, Baffle & Heat Deflector Installation
installation VENT RESTRICTOR, BAFFLE & HEAT DEFLECTOR INSTALLATION NOTE: THE VENT RESTRICTOR & BAFFLE MUST BE INSTALLED PRIOR TO OPTIONAL PANEL INSTALLATION. 1. Determine the venting configuration. 2. Remove top heat deflector and baffle plate (reverse of steps 5 & 6). 3. -
Page 20: Exterior Vent Termination Requirements
installation EXTERIOR VENT TERMINATION REQUIREMENTS Minimum Clearance Requirements Canada Clearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm) Clearance to window or door that may be opened 12"(30cm) 9" (23cm) Clearance to permanently closed window Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm) 24"(60cm) 24"(60cm) from the center line of the terminal (check with the local code) -
Page 21: Top Vent Reducer Installation-From 5" X 8" To 4" X 6-5/8" Venting
B36XTE/B36XTCE installation TOP VENT REDUCER INSTALLATION—FROM 5" X 8" TO 4" X 6-5/8" TOP VENT REDUCER INSTALLATION—FROM 5" X 8" TO 4' X 6-5/8" tooltip 1. Apply a bead of Millpack around the base of the inner vent collar. Slide the 2. -
Page 22: Direct Vent System (Flex)
installation VENTING DIRECT VENT SYSTEM (FLEX) HORIZONTAL TERMINATIONS ONLY These venting systems, in combination with the B36XTE Direct Vent Gas Fireplace, have been tested and listed as a direct vent heater system by Warnock Hersey. The location of the termination cap must conform to the requirements in the Vent Terminal Locations diagram in the "Exterior Vent Termination Locations"... -
Page 23: Vertical Termination 4"X6-7/8" Venting (Part #946-755)
installation VERTICAL TERMINATION 4" X 6-7/8" VENTING - VERTICAL FLEX VENT KIT (946-755) 1. Maintain the 1-½” clearance (air space) to combustibles when passing 11. Secure inner fl ex pipe to pipe adaptor by using Mill-Pac over the adaptor. through ceilings, walls, fl oors, enclosures, attic rafters or other nearby Slide the inner pipe over adaptor and secure with 3 screws. -
Page 24: Vertical Flue Extension Kit (Part #946-756)
installation VERTICAL FLUE EXTENSION KIT (PART #946-756) VERTICAL FLUE EXTENSION KIT (PART # 946-756) 20 foot Flex pipe Extension (Used in conjunction with the 946-755 Vertical Flex kit and 948-367/P flex 4" (100mm) inner pipe to flex adaptor). CEILING FIRESTOP/FIRESTOP SPACER 20ft. -
Page 25: Venting Cross Reference Chart
installation 4" X 6-5/8" RIGID PIPE CROSS REFERENCE CHART ONLY 4” X 6- ” RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not all Rigid Pipe components are available directly from FPI. Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: The listed manufacturers may have other lengths not shown on this chart, which would also be approved. - Page 26 installation Description Selkirk American Metal Security ICC Excel Olympia Simpson Metal-Fab™ Ventis DV* Direct Temp™ Products® Secure- Vent® Direct Direct Vent Pro ® Sure Seal Amerivent Direct Attic Insulation Shield 12” 46DVA-IS 4DAIS12 SV4RSA VDV-AIS04 N/A@ FPI Attic Insulation Shield 4DAIS12 TM-4AS - Cold Climates 36”...
- Page 27 installation 5" X 8" RIGID PIPE CROSS REFERENCE CHART ONLY 5” X 8” RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not all Rigid Pipe components are available directly from FPI. Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: The listed manufacturers may have other lengths not shown on this chart, which would also be approved.
- Page 28 installation Description Selkirk ICC Excel Olympia Simpson Metal-Fab™ Ventis DV* Direct Temp™ Direct ® Direct Vent Pro Sure Seal Attic Insulation Shield 12” 58DVA-IS VDV-AIS05 N/A from FPI Basic Horizontal Termination Kit (A ) 5DT-HKA TM-5HTK VDV-KW05 Horizontal Termination Kit (B) 58DVA-KHA 5DT-HKB TM-5HTK...
-
Page 29: Venting Arrangements For Horizontal Terminations
installation VENTING ARRANGEMENTS FOR HORIZONTAL TERMINATIONS FLEX VENT OR RIGID PIPE 5" X 8" The Diagrams show all allowable combinations of vent runs with 5" x 8" venting using the Regency direct vent system or rigid vent system. A vent guard should be used whenever the termination is lower than the specified minimum or as per local codes. For horizontal terminations the Regency Direct Vent Flex System may be used for installations with a maximum continuous vent maximum horizontal length of 3ft (0.9m). -
Page 30: Horizontal Terminations
installation HORIZONTAL TERMINATIONS FLEX VENT 5" X 8" These venting systems, in combination with the B36XTCE Direct Vent Gas Fireplace, has been tested and listed as a direct vent heater system by Intertek. The location of the termination cap must conform to the requirements in the Vent Terminal Locations Diagram in "Exterior Vent Termination Locations"... -
Page 31: Rigid Pipe 5" X 8
installation HORIZONTAL TERMINATIONS RIGID PIPE 5" X 8" Vinyl Siding Standoff (Optional) Horizontal Termination Wall Thimble Pipe Length 90 Elbow Rigid Pipe Adaptor Pipe Length Rigid Pipe Adaptor Horizontal Termination Top Vent - No Vertical Rise • When venting with a 90° elbow directly off the unit, must use 5"... -
Page 32: Astrocap Xl & Rigid Rear Vent Kit For Corner Installations
installation B36X/XT HORIZONTAL TERMINATIONS ASTROCAP XL & RIGID REAR VENT KIT FOR CORNER INSTALLATIONS HORIZONTAL 5” X 8” RIGID REAR VENT KIT RIGID PIPE 5" X 8" FOR CORNER INSTALLA TIONS Designed for a minimum vent confi guration when using a rear vent application with a horizontal termination in a corner installation. -
Page 33: Venting Arrangements For Horizontal Terminations
installation VENTING ARRANGEMENTS FOR HORIZONTAL TERMINATIONS RIGID PIPE 4" X 6-5/8" (MUST USE REDUCER & RIGID PIPE ADAPTOR (PARTS # 946-606 & 770-994) The diagram shows all allowable combinations of vertical runs with horizontal terminations, using one 90 (two 45 elbows equal one 90 elbow). -
Page 34: Horizontal Or Vertical Terminations
The Regency AstroCap and Regency Riser Vent terminal are certified for installations using Regency venting systems as well as any specific chimney systems listed in this manual. AstroCap is a proprietary trademark of Regency Fireplace Products. 34 | Bellavista ®... -
Page 35: Horizontal Terminations
installation HORIZONTAL TERMINATIONS TWO (2) 90 ELBOWS (RIGID PIPE 4" X 6 - 5/8") One 90 elbow = Two 45 elbows. Option H + H1 W i t h t h e s e o p t i o n s , maximum total pipe length 0' Min. -
Page 36: Venting Arrangements For Vertical Terminations
installation VENTING ARRANGEMENTS FOR VERTICAL TERMINATIONS RIGID PIPE 4" X 6-5/8" (MUST USE REDUCER PART # 946-606 & 770-994 RIGID PIPE ADAPTOR) elbows, with Rigid The shaded area in the Diagram shows all allowable combinations of straight vertical and offset to vertical terminations, using two 90 Pipe Venting Systems for Propane and Natural Gas. -
Page 37: Vertical Terminations
installation VERTICAL TERMINATIONS THREE (3) 90 ELBOWS (RIGID PIPE 4" X 6 - 5/8") One 90 elbow = Two 45 elbows. Option H + H1 V + V1 With these options, max. 0' Min. 2' Max. 2' Min. total pipe length is 30 feet 1' Min. -
Page 38: Venting Arrangements
installation VENTING ARRANGEMENTS WITH CO-LINEAR FLEX SYSTEM Masonry chimneys may take various contours which the flexible liner will accommodate. However, THE APPLIANCE MUST NOT BE keep the flexible liner as straight as possible, avoid unnecessary bending. CONNECTED TO A CHIMNEY FLUE SERVING A SEPARATE SOLID FUEL The Air Intake pipe must be attached to the inlet air collar of the termination cap. -
Page 39: Vertical Terminations
installation VERTICAL TERMINATIONS CO-LINEAR FLEX SYSTEM INTO MASONRY FIREPLACES FOR BOTH RESIDENTIAL & MANUFACTURED HOMES The shaded area in the Diagrams show the allowable vertical terminations. Bellavista ® B36XTCE-10 Gas Fireplace... -
Page 40: Unit Installation With Horizontal Termination
installation UNIT INSTALLATION WITH 5) Assemble the desired combination of pipe 7) Ensure that the pipe clearances to and elbows to the appliance adaptor and combustible materials are maintained HORIZONTAL twist-lock for a solid connection. (Diagram 3). Install the termination cap. TERMINATION 4"... -
Page 41: Unit Installation With Horizontal Termination
installation UNIT INSTALLATION WITH NOTE: Horizontal sections must be ASTROCAPXL supported at intervals not ex- HORIZONTAL DIMENSIONS (946-623/P) ceeding 3 feet (0.9 meter). (Flame TERMINATION picture and performance will be 5" X 8" VENTING affected by sags in the liner). (Flex Vent Systems) 4) Separate the 2 halves of the wall thimble and Minimum Vent Clearances... -
Page 42: Unit Installation With Vertical Termination
installation 4) Assemble the desired lengths of pipe and elbows. Ensure that all pipes and elbow con- UNIT INSTALLATION WITH nections are in the fully twist-locked position and sealed. VERTICAL TERMINATION 4" X 6-5/8" VENTING (Rigid Vent Systems) Diagram 4 MUST USE REDUCER #946-606 AND RIGID PIPE ADAPTOR Roof Pitch... -
Page 43: Pilot Adjustment
installation PILOT ADJUSTMENT GAS PIPE PRESSURE TESTING B36XTCE -NG10 System Data Periodically check the pilot flames. Correct The appliance must be isolated from the gas For 0 to 4500 feet altitude flame pattern has two strong blue flames: supply piping system by closing its individual Burner Inlet Orifice Sizes: 1 flowing around the flame sensor and 1 manual shut-off valve during any pressure... -
Page 44: Conversion From Ng To Lp
installation B36XTCE/ B36XTE CONVERSION KIT #578-972 FROM NG TO LP for B36XTCE using SIT 885 NOVA Gas Valve THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 6. Remove the pilot shield by removing 2 9. -
Page 45: Brick Panel Installation
B36X/XT installation BRICK PANEL INSTALLATION BRICK PANEL INSTALLATION Dangerous operating conditions may occur if the panels are broken. Handle with care. DO NOT FORCE INTO POSITION. 1) Unwrap the Brick Panels from the protective wrapping. 2) Ensure that the logs are not in the unit. Top Panel Back Panel Left Panel... -
Page 46: Optional Black Enamel Panel Installation
B36X / XT installation OPTIONAL BLACK ENAMEL PANEL INSTALLATION BLACK ENAMEL PANEL INSTALLATION Black Enamel Panels • Black Enamel panels must be inspected for scratches and dimples prior to installation. All claims to be recorded at this time. Claims for damage after installation will not receive consideration. •... -
Page 47: Log Set Installation
installation B36XT LOG SET INSTALLATION LOG SET INSTALLATION Installation of Optional Panels must be completed before installing the log set. Read the instructions below carefully and refer to the images. If the 2) Spread vermiculite along the base of the fi rebox. logs are broken do not use the unit until they are replaced. - Page 48 B36XT installation 6) Position Log D with the fl at side toward Log E. 5) Place Log A on the front right side of the burner. Position the notch Fit Log D into right peg on Log E. on the bottom right side of the log into the right side of the grate. Slide Log A back towards Log E until the fl...
- Page 49 B36XT installation 8) Place the lava rocks on the front of the burner tray in the places shown in the photo. Separate platinum embers and place on the front of the burner tray in and around the lava rocks. Avoid stacking platinum embers. Platinum embers may be placed over burner ports.
-
Page 50: Aeration Adjustment
installation AERATION ADJUSTMENT The burner aeration is factory set but may need adjusting due to either the local gas supply or altitude. Open the air shutter for a blue flame or close for a more yellow flame. air shutter is tightly closed. Minimum Air Shutter Opening: Note: Any damage due to carboning 1/4"... -
Page 51: Installing The Optional Fan
B36XTCE / B36XTE installation FAN INSTALLATION INSTALLING THE OPTIONAL FAN Important: 120 Volt AC power is needed for the 7. Plug in the fan power cord to the Fan Con- 5. Slide the thermodisc/cover assembly into blower. The receptacle box will be installed on the bracket clip on the underside of the trol Module into the outlet marked “Fan”. -
Page 52: Wiring Diagram With Optional Fan
installation WIRING DIAGRAM WITH OPTIONAL FAN SureFire™ Switch Caution: Ensure that the wires do not touch any hot surfaces and are away from sharp edges. CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. 52 | Bellavista ®... -
Page 53: Optional Wall Thermostat Installation
installation OPTIONAL WALL THERMOSTAT INSTALLATION A wall thermostat may be installed if desired. 4) Connect the other thermostat lead to male connector disconnected from Step1using a female spade connector - see picture below. Recommended: The Wall Thermostat should be mounted beside the Re- mote/Unit Receiver which comes standard with the appliance. -
Page 54: Optional Accent Light Installation
installation OPTIONAL ACCENT LIGHT INSTALLATION OPTIONAL LIGHT INSTALLATION B36XT/B36XTE Accent Light Kit # 576-959 7) When light assembly has been fully seated - secure in place with 2 screws that were removed from the Light Assembly -includes cable tie/ gasket. cover plate 910-997 Halogen Bulb... - Page 55 installation 14) Install the halogen bulb supplied with the kit. 11) After the wiring has been connected, secure green ground wire to ground lug as shown below. Important: Use caution - do not touch the bulb during installation. Use the plastic packaging as a protective Ground lug is located on the lower left corner inside the covering while installing the bulb.
- Page 56 installation BULB REPLACEMENT 17) Reinstall the logs. 18) Reinstall mesh guard and glass door. 1) Follow steps 1- 4 from previous page. 19) Plug the light assembly into the receptacle located on the 2) Remove 2 screws to remove light diffuser plus gasket. bottom left side of the unit.
- Page 57 installation LINE VOLTAGE WIRING TO RECEPTACLE IN UNIT TO MAKE OUTLETS INDEPENDENT OF EACH OTHER Scheme - 1 Using Wall Switch only to turn lights ON/OFF. Ground Optional Lights Break Tab on Black (hot) side Clamp Connector Ground (Copper) 120 V (60 HZ) power Black (Hot) into receptacle White (Neutral)
-
Page 58: Safety Screen Removal / Installation
installation SAFETY SCREEN REMOVAL / INSTALLATION 1. To remove the safety screen, grasp safety screen on both sides from the 2. When hooks are clear of the bracket–tilt mesh frame out slightly from the bottom. Lift up and out slightly to release from bottom magnets and to release bottom and manoeuvre mesh out. -
Page 59: Flush Glass Door Installation
installation FLUSH GLASS DOOR INSTALLATION 1) Line up slots on flush glass door with tabs in firebox. Hook slots on to tabs and lower door slowly (See Diagram 1). Tabs in Firebox Diagram 1 2) Lower the flush door, then hook the 2 adjustable tension latches - close the latches to secure the flush door (See Diagram 2). Adjustable Tension Latch location Diagram 2... -
Page 60: Operating Instructions
operating instructions OPERATING NORMAL OPERATING INSTRUCTIONS SOUNDS OF GAS APPLIANCES 1) Read and understand these instructions It is possible that you will hear some sounds from before operating this appliance. your gas appliance. This is perfectly normal due to the fact that there are various gauges and types 2) Check to see that all wiring is correct and of steel used within your appliance. -
Page 61: Lighting Procedure
operating instructions LIGHTING PROCEDURE IMPORTANT: The remote control system supplied with this appliance has several options for starting/operating the appliance using the power button 3. After approximately 4 seconds the spark ignition system will spark for 60 and ON/OFF key on the hand held transmitter. seconds to light the main burner. -
Page 62: Copy Of Lighting Plate Instructions
operating instructions COPY OF LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 63: Maintenance Instructions
maintenance GLASS REPLACEMENT MAINTENANCE INSTRUCTIONS of caps, pipe, and fittings. It may be caused by having excessive lateral runs, too many In the event that you break your glass by impact, elbows, and exterior portions of the system 1. Always turn off the gas valve before cleaning. purchase your replacement from an authorized being exposed to cold weather. -
Page 64: Removing Valve
maintenance REMOVING VALVE 8. Disconnect the inlet gas line. 9. Disconnect the EV1, EV2, and ground wires 1. Shut off the gas and electrical supply. from the valve - as shown below. 2. Remove the mesh barrier. 3. Open the flush door and remove the door. 4. -
Page 65: Main Assembly
parts list MAIN ASSEMBLY Part # Description Part # Description 576-084F Top Insulation Plate 578-917 Fan Assembly 576-099 Top Insulation 910-215/P Fan Motor (120 Volts) 556-524 Flue Collar Outer Assembly 911-030 Fan Control Module 556-095 Flue Collar Gasket 911-159 Power Cord (120 Volts) 556-097 Exhaust Gasket 910-142... - Page 66 parts list MAIN ASSEMBLY 66 | Bellavista ® B36XTCE-10 Gas Fireplace...
-
Page 67: Burner Assembly
parts list BURNER ASSEMBLY Part # Description Part # Description 576-077 Rear Log Tray 576-574E/P Valve Assembly - NG 576-576E/P Valve Assembly - LP 576-525 B36XTCE Burner Assembly 576-057 B36XTCE Grate Assembly 10) 911-006 Pilot Assembly - NG 911-007 Pilot Assembly - LP 904-644 Orifice # 35 NG 911-012... -
Page 68: Warranty
warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U.S., Inc. (for U.S. customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. The items covered by this limited warranty and the period of such coverage is set forth in the table below. - Page 69 warranty At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty. All warranty claims must be submitted by the dealer servicing the claim, including a copy of the Bill of Sale (proof of purchase by you).
- Page 70 warranty Limitations of Liability: The original purchaser’s exclusive remedy under this warranty, and FPI’s sole obligation under this warranty, express or implied, in contract or in tort, shall be limited to replacement, repair, or refund, as outlined above. IN NO EVENT WILL FPI BE LIABLE UNDER THIS WARRANTY FOR ANY INCIDENTAL OR CONSEQUENTIAL COMMERCIAL DAMAGES OR DAMAGES TO PROPERTY.
- Page 71 warranty Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 73 notes Bellavista ® B36XTCE-10 Gas Fireplace...
- Page 74 notes 74 | Bellavista ® B36XTCE-10 Gas Fireplace...
- Page 76 Bellavista B36XTCE Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency®, Bellavista®, Surefire™, and AstroCap™ are trademarks of FPI Fireplace Products International Ltd. © Copyright 2018, FPI Fireplace Products International Ltd. All rights reserved. Printed in Canada...
