Model
B41XTCE-NG10
Fuel Type
Minimum Supply Pressure
5" W.C./C.E. (1.25 kPa)
Manifold Pressure - High
3.5" W.C./C.E. (0.87 kPa)
Manifold Pressure - Low
1.6" W.C./C.E. (0.40 kPa)
Orifice Size -Altitude 0-4500 ft.
Minimum Input
Altitude 0-4500 ft. (0-1372m)
Maximum Input
Altitude 0-4500 ft. (0-1372m)
Approved Venting Systems
Flex Vent Systems:
FPI AstroCap™ Flex Vent
Rigid Pipe Vent Systems:
Simpson Direct Vent Pro®
Selkirk Direct-Temp™
Metal-Fab® Sure Seal
ICC Excel Direct Vent
B41XTCE Gas Fireplace
B41XTCE-LP10
Natural Gas
Propane
11" W.C./C.E. (2.74 kPa)
10" W.C./C.E. (2.49 kPa)
6.4" W.C./C.E. (1.60 kPa)
#30 DMS
#49 DMS
30,000 BTU/h
29,500 BTU/h
(8.79 kW)
(8.65 kW)
42,500 BTU/h
37,500 BTU/h
(12.45 kW)
(10.99 kW)
Framing
Dimensions
M
N
O (Rear Vent)
O (Top Vent)
P
Q
R (Rear Vent)
R (Top Vent)
S (Rear Vent)
S (Top Vent)
T
U
V
W
** Important: Framing height requires consideration of the hearth depth.
Dimension N = N + the thickness of the installed hearth.
Non-combustible
Header
(steel stud
on edge)
N
L
M
Description
Framing Width
Framing Height
Framing Depth - Rear Vent
Framing Depth - Top Vent
Corner Facing Wall Width
Corner Facing Wall Width
Framed Chase Ceiling - Rear
Framed Chase Ceiling - Top
Vent Centerline Height - Rear
Vent Centerline Height - Top
Gas Connection Height
Gas Connection Inset
Gas Connection Width
Non-Combustible Top Height
R
Drywall
(or other
facing)
Non-Combustible
(steel stud) on edge
W
O
P
T
U
Q
Opening for gas
connection
B41XTCE
47-1/4"(1200mm)
49-1/2" (1257mm)
26-1/2" (673mm)
25-7/8" (657mm)
65-1/4" (1657mm)
91-11/16" (2329mm)
49-1/2" (1257mm)
54-1/2" (1384mm)
28-1/2" (724mm)
47-1/2" (1207mm) Rigid / Flex
1-1/2" (38mm)
5" (127mm)
3-1/4" (82mm)
13-1/2" (343mm)
Header
Non-Combustible Facing
11" (279mm)
dia. Hole through
wall Vent.
S
S
V

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B41XTCE and is the answer not in the manual?

Questions and answers

Summary of Contents for Regency Fireplace Products B41XTCE

  • Page 1: Framing Dimensions

    B41XTCE Gas Fireplace Model B41XTCE-NG10 B41XTCE-LP10 Fuel Type Natural Gas Propane Minimum Supply Pressure 5” W.C./C.E. (1.25 kPa) 11” W.C./C.E. (2.74 kPa) Manifold Pressure - High 3.5” W.C./C.E. (0.87 kPa) 10” W.C./C.E. (2.49 kPa) Manifold Pressure - Low 1.6” W.C./C.E. (0.40 kPa) 6.4”...
  • Page 2 B41XTCE Gas Fireplace CLEARANCES The clearances listed below are Minimum distances unless otherwise stated: A major cause of chimney related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this fireplace and vent system be installed only in accordance with these instructions.
  • Page 3: Mantel Clearances

    B41XTCE Gas Fireplace MANTEL CLEARANCES Mantel Clearances Due to the extreme heat this fireplace emits, the mantel clearances are critical. Combustible mantel clearances from top of front facing are shown in the diagram on the right. Combustible Note: A non-combustible mantel may be...
  • Page 4: Tile Finish

    B41XTCE Gas Fireplace FRAMING & FINISHING 1. Frame in the enclosure for the unit with framing material. Note: When constructing the framed opening, please ensure there is access to install the gas lines when the unit is installed. 2. For exterior walls, insulate the enclosure to the same degree as the rest of the house; apply vapour barrier and drywall, as per local installation codes.
  • Page 5 B41XTCE Gas Fireplace 7. Non-combustible material (ie. tile, slate, etc) may be brought up to the edge of the glass door of the unit. Minimum clearances must be adhered to, this will assure ease of glass door removal and access to the lower panel.
  • Page 6: Venting Arrangements For Horizontal Terminations

    B41XTCE Gas Fireplace VENTING ARRANGEMENTS FOR HORIZONTAL TERMINATIONS FLEX VENT OR RIGID PIPE 5" X 8" The diagrams show all allowable combinations of vent runs with 5" x 8" venting using the Regency direct vent system or rigid vent system.
  • Page 7: Venting Arrangements

    B41XTCE Gas Fireplace VENTING ARRANGEMENTS VENTING ARRANGEMENTS FOR HORIZONTAL TERMINATIONS FOR VERTICAL TERMINATIONS The shaded area in the diagram shows all allowable combinations of straight vertical and offset to vertical terminations, using two 90 elbows, with Rigid The diagram shows all allowable combinations of vertical runs with horizontal Pipe Venting Systems for Propane and Natural Gas.
