Daewoo DWC-121R Service Manual page 32

NO CODE
19 3106800300 ASS'Y CONDENSOR
19-1 3108504300 SEAL COND TOP
20 3101202800 CLIP FAN
21 3101802600 PAN BLOWER
22 3101404100 COVER MOTOR
23 3104202000 PANEL HOUSING
24 3102000500 FIXTURE RUBBER
24-1 3100000010 BUSHING GUIDE
25 3108004920 MOTOR FAN
3108005020 MOTOR FAN
3108006000 MOTOR FAN
3108005110 MOTOR FAN
3108006100 MOTOR FAN
3108005220 MOTOR FAN
3108006200 MOTOR FAN
26 7007501211 SCREW HEX
27 3101802700 FAN PROPELLER
28 3102201100 WINDOW KIT FRAME(L)
29 3102201000 WINDOW KIT FRAME(R)
30 3100604200 PLATE WINDOW TOP
31 3100801400 CABINET ASSY
32 3100604300 BRACKET WINDOW LOWER
33 3100604500 BRACKET SILL
34 3106600600 SCROLL LOWER
35 3103700100 LEVER VENT
36 3103700100 WASHER VENT
37 3104600100 RING VENT
38 3106700400 CAM
39 7141300611 SCREW TAPPING
40 3104302300 PCB MAIN AS
41 3104302400 PCB FRONT AS
42 3102708900 HARNESS COIL SENSOR
43 3101300300 POWER CORD
3103001600 POWER CORD
3101300600 POWER CORD
44 3109503100 CAPACITOR
3109503110 CAPACITOR
3109503200 CAPACITOR
3109503210 CAPACITOR
3109505100 CAPACITOR
COMPONENTS Q'TY
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
4
1
1
1
1
1
2
2
1
1
1
1
1
4
1
1
1
1
1
1
1
1
1
1
1
SPECIFICATION
3R2C, Ø7
F-US
SK-5
ABS
EPS
SGCC T1.0
NBR
NBR
DAEWOO MOTOR (AM 12DWD10)
DAEWOO MOTOR (AM 12DWD12)
OBM2502U1
DAEWOO MOTOR (A9525CA070)
OBM2501P2
DAEWOO MOTOR (AM 12DWD11)
OBM2503U1
5x12 MFZN
ABS+GF20%
HIPS
HIPS
SGCC T1.2
SGCC T0.8
SGCC T0.8
SGCC T1.6
EPS
PP
PP
NBR
POM
PAN 3x6
-
-
-
KKP-30B,13A 125V
WS-001I 250V 13A
KKP-4819R 250V 10A
12/40µF,370VAC
12/40µF,370VAC
5/25µF,370VAC
5/25µF,370VAC
5/35µF,400VAC
31
REMARK
DWC-121R(ONLY)
DWA-121R, 122R(ONLY)
DWA-121R, 122R(ONLY)
DWB-121R,122R,123R(ONLY)
DWB-121R,122R,123R(ONLY)
DWA-150R,151R(ONLY)
DWA-150R,151R(ONLY)
DWC-121R(ONLY)
DWA-121R,122R,150R,151R(ONLY)
DWB-121R, 122R,123R(ONLY)
DWC-121R(ONLY)
DWC-121R(ONLY)
DWA-121R,122R(ONLY)
DWA-121R,122R(ONLY)
DWB-121R,123R(ONLY)
