Reset(6)
DESCRIPTION
Voltage less than about 4.2V put in Micom Terminal of Number 6 and then Micom reset. Reset IC detect
Power ON and Voltage greater than 4.2V, and then send Reset Signal.
4.2V
DELAY TIME
FOR POWER ON
H
L
POWER
ON
MICOM
3
5V
R1
5.6K
3
7042
+ C11
2
1µF/50
24
5V
1
RESET IC
Vcc (+5V)
RESET
t
t
