Micom Power Supply(5)
DESCRIPTION
MICOM Power is supplied 5V at Number 28 using VDD, Number 6 using Analog Reference of A/D Converter.
C9, C10 is Ripple filter.
28
MICOM
6
14
23
Vcc
5V
C10
100µF/16V
C9
104
