NOTE
• Rapid charging is only an emergency measure. This method uses a large amount of
current to compensate the lost charge in a short time. However, the battery needs
to be fully charged in the ordinary method for a longer service life.

Fuses

• If a fuse blows, investigate the cause before replacing. Always replace a fuse
with the one of the correct rating.
Fuse Housing
3683M-0508-030E
Fuses
3683M-0508-040E
Maintenance
Charging
1. Remove battery from the machine.
2. Remove all filler plugs.
3. Follow the instructions in the battery
charger user's manual to charge the
battery.
4. When battery is fully charged, put filler plugs
back in place and install battery.
1. Open engine cover.
2. Open the lid of fuse housing.
3. Locate the blown fuse and replace it with a
new one of the correct rating.
4. Put the lid back in place.
5. Close engine cover.
NOTE
• Replacement Fuse: 40A (2pcs.)
-56-
