Views of Projector Parts

Front-right View

I L
TEM ABEL
1.
IR receiver
2.
Lens
3.
Focus ring
4.
Zoom ring
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp
cool. Do not obstruct any of the ventilation openings.
D
ESCRIPTION
Receive IR signal from remote control
Projection Lens
Focuses the projected image
Enlarges the projected image
