C3X LINK
DLP™ VIDEO
PROJECTOR
RS-232C
CONTROL

SPECIFICATIONS

Document Revision 1.1 (16 December 2005)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DLP Video Projector C3X Link and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sim2 DLP Video Projector C3X Link

Summary of Contents for Sim2 DLP Video Projector C3X Link

  • Page 1: Specifications

    C3X LINK DLP™ VIDEO PROJECTOR RS-232C CONTROL SPECIFICATIONS Document Revision 1.1 (16 December 2005)

  • Page 2: Table Of Contents

    Table of Contents 1. INTRODUCTION 2. CONNECTION 3. COMMUNICATION PROTOCOL EADER AYLOAD 4. COMMANDS EMOTE ONTROL ODES PERATION ODES ODES 5. EXAMPLES 6. WARNINGS Revision History: Revision Date 16 December 2005 5 December 2005 Software Version 2.48.62 CL or higher 2.48.60 CL or higher SIM2 C3X LINK RS-232C CONTROL SPECIFICATIONS...

  • Page 3: Introduction

    1. Introduction This document describes the communication and data formats used to control SIM2 C3X LINK projector via RS-232C port. 2. Connection Switch off the Personal Computer the Projector before connecting RS 232C cable. Use a standard serial cable with 9 pin female to the Personal Computer and 9 pin male to the Projector: pin 2 connects to pin2, pin 3 to pin 3 and pin 5 to pin 5.

  • Page 4: Communication Protocol

    3. Communication Protocol The communication protocol is packet oriented. Packets consists of Header and Payload. There are two types of packets: Event and Operation. The packet header size is fixed (7 bytes), while the packet payload type and content varies based on the type of packet: Event payload size is 6 bytes, while Operation payload size is 25 bytes.

  • Page 5: Commands

    4. Commands Remote Control Key Codes The following commands send simulated Remote Control input to SIM2 C3X LINK projector. Remote Control Keycodes: STAND BY CURSOR UP CURSOR LEFT CURSOR RIGHT CURSOR DOWN MENU LEFT MENU RIGHT FREEZE MEMORY INFO AUTO ASPECT NORMAL ASPECT ANAMORPHIC ASPECT LETTERBOX...

  • Page 6: Direct Access Codes

    ASPECT USER 1 ASPECT USER 2 ASPECT USER 3 Direct access codes Zoom Focus Goto Brightness Goto Contrast Goto Color Goto Tint When the unit is in Standby state, this command switches on the unit and the last source memorised prior to switch off is automatically selected.

  • Page 7: Operation Codes

    Operation Codes The following codes provide direct access to SIM2 C3X LINK User Interface operations not accessible via a single Remote Control command. Operation Codes: Operation Action INCREMENT BRIGHTNESS DECREMENT INCREMENT CONTRAST DECREMENT INCREMENT COLOR DECREMENT INCREMENT TINT DECREMENT INCREMENT SHARPNESS (Video) DECREMENT INCREMENT...
  • Page 8 SET 04 SET 05 SET 06 SET 07 SET 08 SET 09 SET 10 SET 11 SET 12 SET 13 SET 14 SET 15 SET 16 SET 17 COLOR SET 18 TEMPERATURE SET 19 SET 20 SET 21 SET 22 SET 23 SET 24 SET 25...
  • Page 9 SET 33 SET 34 COLOR TEMPERATURE SET 35 SET 36 SET ST1 SET EN1 SET EN2 SET EN3 GAMMA SET EN4 SET EN5 SET GR1 SET GR2 SET USER INCREMENT FREQUENCY DECREMENT INCREMENT PHASE DECREMENT INCREMENT Y/C DELAY DECREMENT INCREMENT MAGNIFICATION DECREMENT INCREMENT...
  • Page 10 SET 200 SET 210 SET 220 LAMP POWER SET 230 SET 240 SET 250 SET ENGLISH SET ITALIANO SET FRANCAIS LANGUAGE SET DEUTSCH SET ESPANOL SET PORTUGUES INCREMENT OSD POSITION HORIZONTAL DECREMENT INCREMENT OSD POSITION VERTICAL DECREMENT SET YCrCb AutoSync SET YCrCb 15kHz INPUT 5 SET YCrCb 32kHz...
  • Page 11 SET YCrCb AutoSync SET YCrCb 15kHz INPUT 7 SET YCrCb 32kHz (COMP RGB 3) / SIGNAL TYPE SET RGB AutoSync SET RGB 15kHz SET RGB 32kHz SET YCrCb AutoSync SET YCrCb 15kHz INPUT 8 SET YCrCb 32kHz (COMP RGB 4) / SIGNAL TYPE SET RGB AutoSync SET RGB 15kHz...

  • Page 12: Get Codes

    Get Codes Get Commands may be used to get the current value of projector parameters. The response to a correct Get Command consists of 33 byte packet, where Byte Number 11 contains the Validation Code (01) and bytes Number 17 and Number 18 the requested value (the least-significant byte of the value being sent first).
  • Page 13 Returned value is indeterminate when the unit is in No Signal state. Returned value may be different from the value displayed on the OSD, as in the latter, the values have been normalized to the 0-100 range. Returned value is valid only when Video, S-Video, RGBS 15 kHz, YPrPb 15 kHz or YPrPb 32 kHz signals are displayed.

  • Page 14: Examples

    5. Examples 1. Send the simulated "SWITCH ON FROM STAND-BY" Remote Control keycode. Remote Control allows Switching on from Stand-by via the key "0". Send the code relative to key "0": BEEF020600A7F79E0100000000. The projector switches on and the last source memorised prior to switch off is automatically selected. The projector returns the response code: 06 (Acknowledged with no error).
