Filter Board - Icom IC-7400 Service Manual

[CTRL UNIT]
REF ORDER
NO. NO.
C44 4030011340 S.CERAMIC
C45 4030011600 S.CERAMIC
C46 4030011600 S.CERAMIC
C47 4030009990 S.CERAMIC
C48 4030009990 S.CERAMIC
C49 4030006880 S.CERAMIC
C50 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C51 4030006860 S.CERAMIC
C52 4030006880 S.CERAMIC
C53 4030006880 S.CERAMIC
C54 4030006880 S.CERAMIC
C55 4030006860 S.CERAMIC
C56 4030006880 S.CERAMIC
C57 4030006880 S.CERAMIC
C58 4030006880 S.CERAMIC
C59 4030006880 S.CERAMIC
C60 4030006880 S.CERAMIC
C62 4030006880 S.CERAMIC
C63 4030007040 S.CERAMIC
C64 4030007120 S.CERAMIC
C65 4030007090 S.CERAMIC
C66 4030007120 S.CERAMIC
C67 4030007030 S.CERAMIC
C69 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C70 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C71 4030011600 S.CERAMIC
C72 4510006260 S.ELECTROLYTIC ECEV1AA471UP
C73 4030006880 S.CERAMIC
C74 4030006880 S.CERAMIC
C75 4030006880 S.CERAMIC
C76 4030006880 S.CERAMIC
C77 4030006880 S.CERAMIC
C78 4030006880 S.CERAMIC
C79 4030006880 S.CERAMIC
C80 4030006880 S.CERAMIC
C81 4030006880 S.CERAMIC
C82 4030006880 S.CERAMIC
C83 4030006880 S.CERAMIC
C84 4030006880 S.CERAMIC
C85 4030006880 S.CERAMIC
C86 4030006880 S.CERAMIC
C90 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C91 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C92 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C93 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C94 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C95 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C96 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C97 4510004440 S.ELECTROLYTIC ECEV1HA010SR
C98 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C99 4030007010 S.CERAMIC
C100 4030007110 S.CERAMIC
C101 4030006880 S.CERAMIC
C102 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C105 4030007070 S.CERAMIC
C107 4010005550 CERAMIC
C109 4030011600 S.CERAMIC
C110 4030011600 S.CERAMIC
C111 4030006880 S.CERAMIC
C112 4030006880 S.CERAMIC
C113 4030006880 S.CERAMIC
C114 4030006880 S.CERAMIC
C116 4030007020 S.CERAMIC
C117 4030007100 S.CERAMIC
C118 4030011600 S.CERAMIC
C203 4030006880 S.CERAMIC
C209 4030006900 S.CERAMIC
C210 4030006900 S.CERAMIC
C211 4010005520 CERAMIC
C212 4030007020 S.CERAMIC
C213 4030007050 S.CERAMIC
C214 4030006860 S.CERAMIC
C215 4030005040 S.CERAMIC
C216 4030011600 S.CERAMIC
RL1 6330001460 RELAY
RL2 6330001460 RELAY
RL3 6330001460 RELAY
RL4 6330000470 RELAY
DESCRIPTION
C1608 CH 1H 471J-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1E 104K-T-N
C1608 CH 1H 200J-T-A
C1608 CH 1H 200J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 180J-T-A
C1608 CH 1H 820J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 820J-T-A
C1608 CH 1H 150J-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 680J-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 330J-T-A
HM60SJ SL 040C 500V
C1608 JB 1E 104K-T-N
C1608 JB 1E 104K-T-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 120J-T-A
C1608 CH 1H 560J-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
HM60SJ SL 010C 500V
C1608 CH 1H 120J-T-A
C1608 CH 1H 220J-T-A
C1608 JB 1H 102K-T-A
C2012 CH 1H 271J-T-A
C1608 JB 1E 104K-T-N
FTR-F1CA012V
FTR-F1CA012V
FTR-F1CA012V
NR-HD (12V) AE5343
6 - 25
[CTRL UNIT]
REF ORDER
NO. NO.
CP7 6910009670 S.CHECK P
J1 6510007020 CONNECTOR
J3 6510007020 CONNECTOR
J4 6510007020 CONNECTOR
J7 6510022590 S.CONNECTOR
J8 6510022590 S.CONNECTOR
J10 6510003410 CONNECTOR
J11 6510003410 CONNECTOR
J14 6510018960 S.CONNECTOR
W3 7120000010 JUMPER
W4 7030003860 S.JUMPER
W11 7120000490 JUMPER
W12 7120000490 JUMPER
EP1 0910054413 PCB
EP2 6910000630 BEAD

[FILTER BOARD]

REF ORDER
NO. NO.
L1 6140003440 COIL
L2 6140003440 COIL
C1 4030004740 S.CERAMIC
C2 4030008960 S.CERAMIC
C5 4030004740 S.CERAMIC
C6 4030004740 S.CERAMIC
C7 4030008960 S.CERAMIC
C8 4030008960 S.CERAMIC
C9 4030008960 S.CERAMIC
C10 4030004740 S.CERAMIC
C12 4030008960 S.CERAMIC
C13 4030004740 S.CERAMIC
C15 4030008960 S.CERAMIC
C16 4030004740 S.CERAMIC
C18 4030008960 S.CERAMIC
C19 4030004740 S.CERAMIC
EP1 0910050014 PCB
EP2 6910011330 TERMINAL
EP3 6910011330 TERMINAL
EP4 6910011330 TERMINAL
EP5 6910011330 TERMINAL
DESCRIPTION
HK3-S-T
TMP-J01X-V6
TMP-J01X-V6
TMP-J01X-V6
22FMN-BMTTR-A-TBT
22FMN-BMTTR-A-TBT
B05B-EH-S
B05B-EH-S
B2B-PH-SM3-TB
JPW 02A
ERJ3GE JPW V
ERD25T0
ERD25T0
B 5702C
FSOH070RN
DESCRIPTION
LR-386
LR-386
C2012 JB 1H 472K-T-A
C2012 JB 1C 104K-T-A
C2012 JB 1H 472K-T-A
C2012 JB 1H 472K-T-A
C2012 JB 1C 104K-T-A
C2012 JB 1C 104K-T-A
C2012 JB 1C 104K-T-A
C2012 JB 1H 472K-T-A
C2012 JB 1C 104K-T-A
C2012 JB 1H 472K-T-A
C2012 JB 1C 104K-T-A
C2012 JB 1H 472K-T-A
C2012 JB 1C 104K-T-A
C2012 JB 1H 472K-T-A
B 5143D
OT-009 M3
OT-009 M3
OT-009 M3
OT-009 M3
S.=Surface mount
