Filter Board - Icom IC-706MKIIG Service Manual

[PA UNIT]
REF ORDER
NO. NO.
C470 4030006860 S.CER C1608 JB 1H 102K-T
C471 4030009500 S.CER C1608 CH 1H 0R5B-T
C472 4030007030 S.CER C1608 CH 1H 150J-T
C476 4030006860 S.CER C1608 JB 1H 102K-T
C477 4030011600 S.CER C1608 JB 1E 104K-T
C478 4030011600 S.CER C1608 JB 1E 104K-T
C501 4030011600 S.CER C1608 JB 1E 104K-T
C502 4030006880 S.CER C1608 JB 1H 472K-T
C511 4030011600 S.CER C1608 JB 1E 104K-T
C521 4030006880 S.CER C1608 JB 1H 472K-T
C531 4030006880 S.CER C1608 JB 1H 472K-T
C552 4030006860 S.CER C1608 JB 1H 102K-T
C553 4030006860 S.CER C1608 JB 1H 102K-T
C571 4030006880 S.CER C1608 JB 1H 472K-T
C572 4030006880 S.CER C1608 JB 1H 472K-T
C573 4030011600 S.CER C1608 JB 1E 104K-T
C574 4030006880 S.CER C1608 JB 1H 472K-T
C575 4030011600 S.CER C1608 JB 1E 104K-T
C576 4510009270 S.ELE EEEHB1C220UR
C577 4030011600 S.CER C1608 JB 1E 104K-T
C578 4510004591 ELE 16 ME 470 HC
C579 4030011600 S.CER C1608 JB 1E 104K-T
C580 4030006860 S.CER C1608 JB 1H 102K-T
C581 4030006880 S.CER C1608 JB 1H 472K-T
C582 4030006860 S.CER C1608 JB 1H 102K-T
C583 4030006860 S.CER C1608 JB 1H 102K-T
C591 4030004760 S.CER C2012 JF 1H 104Z-T
C592 4030004740 S.CER C2012 JB 1H 472K-T
C593 4030011600 S.CER C1608 JB 1E 104K-T
C594 4030011600 S.CER C1608 JB 1E 104K-T
C601 4030006850 S.CER C1608 JB 1H 471K-T
C602 4030004740 S.CER C2012 JB 1H 472K-T
C603 4030004760 S.CER C2012 JF 1H 104Z-T
C604 4510004601 ELE 16 ME 1000 HC
C613 4030011600 S.CER C1608 JB 1E 104K-T
C621 4030011600 S.CER C1608 JB 1E 104K-T
C622 4030011600 S.CER C1608 JB 1E 104K-T
C623 4030011600 S.CER C1608 JB 1E 104K-T
C624 4030006880 S.CER C1608 JB 1H 472K-T
C626 4030006860 S.CER C1608 JB 1H 102K-T
C627 4030011600 S.CER C1608 JB 1E 104K-T
C632 4030011600 S.CER C1608 JB 1E 104K-T
C641 4030006880 S.CER C1608 JB 1H 472K-T
C651 4030006880 S.CER C1608 JB 1H 472K-T
C652 4030011600 S.CER C1608 JB 1E 104K-T
C661 4030011600 S.CER C1608 JB 1E 104K-T
C662 4030011600 S.CER C1608 JB 1E 104K-T
C663 4030011600 S.CER C1608 JB 1E 104K-T
C664 4030011600 S.CER C1608 JB 1E 104K-T
C665 4030011600 S.CER C1608 JB 1E 104K-T
C666 4030011600 S.CER C1608 JB 1E 104K-T
C669 4030011600 S.CER C1608 JB 1E 104K-T
C670 4030011600 S.CER C1608 JB 1E 104K-T
C672 4030006850 S.CER C1608 JB 1H 471K-T
C673 4030006850 S.CER C1608 JB 1H 471K-T
C674 4030006850 S.CER C1608 JB 1H 471K-T
C675 4030006850 S.CER C1608 JB 1H 471K-T
C676 4030011600 S.CER C1608 JB 1E 104K-T
C677 4030011600 S.CER C1608 JB 1E 104K-T
C678 4030011600 S.CER C1608 JB 1E 104K-T
C679 4030011600 S.CER C1608 JB 1E 104K-T
C680 4030011600 S.CER C1608 JB 1E 104K-T
C681 4030011600 S.CER C1608 JB 1E 104K-T
C682 4030011600 S.CER C1608 JB 1E 104K-T
C683 4030011600 S.CER C1608 JB 1E 104K-T
C684 4030011600 S.CER C1608 JB 1E 104K-T
C685 4030006860 S.CER C1608 JB 1H 102K-T
C686 4030006860 S.CER C1608 JB 1H 102K-T
C687 4030006860 S.CER C1608 JB 1H 102K-T
C688 4030006860 S.CER C1608 JB 1H 102K-T
C689 4030006860 S.CER C1608 JB 1H 102K-T
C690 4030007170 S.CER C1608 CH 1H 221J-T
C691 4030007170 S.CER C1608 CH 1H 221J-T
C692 4030006860 S.CER C1608 JB 1H 102K-T
C693 4030006860 S.CER C1608 JB 1H 102K-T
C694 4030006850 S.CER C1608 JB 1H 471K-T
C695 4030006850 S.CER C1608 JB 1H 471K-T
C696 4030010750 S.CER C1608 CH 1H 201J-T
C697 4030007090 S.CER C1608 CH 1H 470J-T
C702 4030007170 S.CER C1608 CH 1H 221J-T
C711 4030010750 S.CER C1608 CH 1H 201J-T
C712 4030006860 S.CER C1608 JB 1H 102K-T
C716 4030007090 S.CER C1608 CH 1H 470J-T
C717 4030007170 S.CER C1608 CH 1H 221J-T
C718 4030007090 S.CER C1608 CH 1H 470J-T
RL591 6330001550 RLY JV-12-KT
CP573 6910009670 S.CHK HK3-S-T
CP574 6910009670 S.CHK HK3-S-T
J160 6510021531 CNR IMSA-9230B-1-04Z024-PT1
DESCRIPTION
[ESP], [ITR], [ITR-1], [CHN], [CHN-01] only
[ESP], [ITR], [ITR-1], [CHN], [CHN-01] only
[ESP], [ITR], [ITR-1], [CHN], [CHN-01] only
[ESP], [ITR], [ITR-1], [CHN], [CHN-01] only
[ESP], [ITR], [ITR-1], [CHN], [CHN-01] only
[ESP], [ITR], [ITR-1], [CHN], [CHN-01] only
[ESP], [ITR], [ITR-1], [CHN], [CHN-01] only
[ESP], [ITR], [ITR-1], [CHN], [CHN-01] only
[ESP], [ITR], [CHN], [CHN-01] only
[PA UNIT]
REF ORDER
NO. NO.
J161 6510021531 CNR
J172 6510007020 CNR
J210 6510021531 CNR
J211 6510021531 CNR
J270 6510017150 CNR
J571 6510018961 S.CNR B2B-PH-SM4-TB (LF) (SN)
J621 6510019981 S.CNR 52808-1671 (1690)
J641 6450000140 CNR
J661 6510020081 S.CNR 52808-2071 (2090)
F591 5210000131 FUS
F592 5220000230 HOL
F593 5220000230 HOL
W185 7030009300 S.RES ERJ1WY0R00U
W186 7030009300 S.RES ERJ1WY0R00U
W235 7030000010 S.RES MCR10EZHJ JPW (000)
W300 7030008240 S.RES ERJ12Y0R00U
W301 7030008240 S.RES ERJ12Y0R00U
W316 7030003860 S.RES ERJ3GE JPW V
W320 7030003860 S.RES ERJ3GE JPW V
W361 9056200020 WIR
W462 7030003860 S.RES ERJ3GE JPW V
W572 7030003860 S.RES ERJ3GE JPW V
EP121 9040901901 TUB
EP174 9018970370 TUB

[FILTER BOARD]

REF ORDER
NO. NO.
IC1 1110002700 S.IC
Q1 1590000680 S.TR
Q2 1530002060 S.TR
Q3 1530002060 S.TR
Q4 1530002060 S.TR
Q5 1530002060 S.TR
Q6 1530002060 S.TR
Q7 1530002060 S.TR
Q8 1530002060 S.TR
Q9 1530003091 S.TR
Q10 1530002060 S.TR
Q11 1540000451 S.TR
Q12 1590001870 S.TR
D1 1750000301 S.DIO
D2 1750000301 S.DIO
D3 1750000301 S.DIO
D4 1750000301 S.DIO
D5 1750000301 S.DIO
D6 1750000301 S.DIO
D7 1750000301 S.DIO
D8 1750000301 S.DIO
D9 1790000980 S.DIO
D10 1790000980 S.DIO
D23 1750000301 S.DIO
D24 1160000050 S.DIO
D25 1750000641 S.DIO
D26 1790001250 S.DIO
L1 6110001560 COL
L2 6110001630 COL
L5 6110003570 COL
L6 6110003570 COL
L7 6110003550 COL
L10 6140001800 COL
L11 6140001800 COL
L14 6140003450 COL
L15 6140003540 COL
L16 6140003460 COL
L18 6140002560 COL
L19 6140002560 COL
L22 6110002920 COL
L23 6110003580 COL
L26 6140001800 COL
L27 6140001780 COL
L30 6140002570 COL
L31 6140002580 COL
L33 6140003490 COL
L34 6200002041 S.COL NLV25T-101J
L35 6200003950 S.COL HF50ACC 322513-T
L36 6200002041 S.COL NLV25T-101J
L37 6200002041 S.COL NLV25T-101J
L39 6200003950 S.COL HF50ACC 322513-T
L41 6200003950 S.COL HF50ACC 322513-T
L42 6200003950 S.COL HF50ACC 322513-T
L43 6200003950 S.COL HF50ACC 322513-T
L44 6200002041 S.COL NLV25T-101J
5 - 17
DESCRIPTION
IMSA-9230B-1-04Z024-PT1
TMP-J01X-V6
IMSA-9230B-1-04Z024-PT1
IMSA-9230B-1-04Z024-PT1
TMP-S01X-C1
HSJ0807-01-010
FGB 4A PBF (FGB0 125V)
S-N5054
S-N5054
except [USA], [USA-1], [EUR], [EUR-1]
except [USA], [USA-1], [EUR], [EUR-1]
73/98/012/X98/X98 except [EUR], [FRA], [USA]
IRRAX 0.7 (d) L=12 mm
20 L=25MM
DESCRIPTION
NJM2904M-TE1
DTC114EUA T106
2SC4081 T106 R
2SC4081 T106 R
2SC4081 T106 R
2SC4081 T106 R
2SC4081 T106 R
2SC4081 T106 R
2SC4081 T106 R
2SC4213-B (TE85R,F)
2SC4081 T106 R
2SD1623T-TD-E
DTA114EE TL
1SS302 (TE85R,F)
1SS302 (TE85R,F)
1SS302 (TE85R,F)
1SS302 (TE85R,F)
1SS302 (TE85R,F)
1SS302 (TE85R,F)
1SS302 (TE85R,F)
1SS302 (TE85R,F)
MA742 (TX)
MA742 (TX)
1SS302 (TE85R,F)
DAP202U T106
1SV312 (TE85L,F)
MA2S111-(TX)
LA-236
LA-246
LA-550
LA-550
LA-547 (LA-214A)
LR-216 (T50-2)
LR-216 (T50-2)
LR-387 (T50-10) except [USA], [USA-1]
LR-396 except [USA], [USA-1], [EUR], [EUR-1]
LR-388 (T50-10)
except [USA], [USA-1], [EUR], [EUR-1]
LR-293 (T50-10)
LR-293 (T50-10)
LA-481
LA-551
LR-216 (T50-2)
LR-214 (T50-2)
LR-294 (T50-2)
LR-295 (T50-2)
LR-391 (TR10X5X5 3A6)
S.=Surface mount
