Icom IC-7400 Service Manual page 56

SECTION 7
[FRONT UNIT]
REF. NO. ORDER NO.
EP1 0880000950 Sensor EX-2500 #01
EP2 6450001230 Plate HLJ0999-01-480
EP3 6450001230 Plate HLJ0999-01-480
MP1 8210018280 2072 front panel (A)-1
8210018270 2072 front panel (B)-1
MP2 8010017293 2072 sub chassis-3
MP3 8310052470 2072 window plate (A)
MP4 8930056340 2072 ten key (A)
MP5 8930056260 2072 mode key (A)
MP6 8930056270 2072 P-key (A)
MP7 8930045430 2072 T-A key
MP8 8930045440 2072 N-A key
MP9 8930045450 2072 S-L key
MP10 8930045460 2072 4-key
MP11 8610011120 Knob N273 (C)
MP12 8610010260 Knob N252
MP13 8610010620 Knob N253 (A)
MP14 8610010650 Knob N268 assembly
MP17 8930027470 1296 brake pad
MP19 8930041060 1876 brake plate
MP25 8820000770 1296 screw
Screw PH BT M3 × 8 NI-ZU
MP26 8810008660
Screw PH BT M3 × 8 NI-ZU
MP27 8810008660
Screw FH BT M2 × 5 NI-ZU
MP28 8810009180
Screw FH BT M2 × 5 NI-ZU
MP29 8810009180
Screw FH BT M2 × 5 NI-ZU
MP30 8810009180
Screw FH BT M2 × 5 NI-ZU
MP31 8810009180
Screw FH BT M2 × 5 NI-ZU
MP32 8810009180
Screw FH BT M2 × 5 NI-ZU
MP33 8810009180
Screw FH BT M2 × 5 NI-ZU
MP34 8810009180
Screw PH BT M3 × 18 NI-ZU
MP35 8810009390
MP36 8930007840 Sheet K
MP37 8930047080 Sponge (FR)
MP38 8930047060 Sponge (FS)
Sheet (AA) TC-500TK (15 × 40)
MP39 8930056530
MP40 8610011130 Knob N273 (D)
MP41 8610010730 Knob N252 (A)
[S-LOGIC BOARD]
REF. NO. ORDER NO.
R1 7210002890 Variable resister RV-308
R4 7210002890 Variable resister RV-308
MP1 8510001081 Shield case (A)-1
MP2 8510001101 Shield case (A)-1 cover
MP3 8510005980 724 shield case
MP4 8510005990 724 shield case cover
[PHONE BOARD]
REF. NO. ORDER NO.
J1 6450001890 Connector HLJ5305-01-4090
J2 6450001790 Connector HLJ7000-01-3010
MECHANICAL PARTS
DESCRIPTION QTY.
1
1
1
[7400] 1
[746PRO] 1
1
1
1
1
1
1
1
1
1
2
2
2
1
1
1
1
5
2
2
5
1
2
2
2
3
1
4
1
1
1
1
1
DESCRIPTION QTY.
1
1
1
1
1
1
DESCRIPTION QTY.
1
1
[MIC BOARD]
REF. NO. ORDER NO.
J1 6510000190 Connector FM214-8SS (P)
[PBT BOARD]
REF. NO. ORDER NO.
S1 2250000440 Switch TP90N00E20-22.5F-2494
S2 2250000410 Switch TP90D96E20-30F-2178-1
[RIT BOARD]
REF. NO. ORDER NO.
S1 2250000340 Switch EVQ-VCJF0324B
[DISPLAY BOARD]
REF. NO. ORDER NO.
DS1001 5030002150 DLC-83006S4GT
DS1002 5080000420 HMB S 3 A1W 70N/AZ ASSY
EP1 8930046361 SRCN-2072-SP-N-W-1
MP1 8930045491 2072 LCD holder-1
MP2 8210015251 2072 reflector-1
MP3 8930046520 2072 LCD filter
MP4 8930046790 Sheet BT
[UNPACKING]
REF. NO. ORDER NO.
F1 5210000090 Fuse FGB 30A
F2 5210000060 Fuse FGB 5A
W1 8900006490 DC power cable OPC-025 D
MC1 7700000540 Hand microphone HM-36
Screw abbreviations BT: Self-tapping PH: Pan head
FH: Flat head
7 - 1
DESCRIPTION QTY.
1
DESCRIPTION QTY.
1
1
DESCRIPTION QTY.
1
DESCRIPTION QTY.
1
1
2
1
1
1
2
DESCRIPTION QTY.
2
1
1
1
NI-ZU: Nickel-zinc
