[FILTER BOARD]

REF ORDER
NO. NO.
RL15 6330001570 RELAY
RL16 6330001570 RELAY
RL17 6330000780 RELAY
J3 6510018570 CONNECTOR
J4 6510007020 CONNECTOR
W12 6910001030 JUMPER
W13 6910001030 JUMPER
W14 6910001030 JUMPER
W19 7120000010 JUMPER
W20 6910001030 JUMPER
W21 6910001030 JUMPER
W29 7120000380 JUMPER
W30 7120000010 JUMPER
WS1 8970022020 M.OTHER
EP1 0910045057 PCB
[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6510000370 CONNECTOR
F1 5220000210 HOLDER
F2 5220000210 HOLDER
F3 5210000090 FUSE
F4 5210000090 FUSE
W3 8900005700 CABLE
W4 8900005770 CABLE
W5 8900005780 CABLE
WS1 8970022010 M.OTHER
WS2 8600034560 M.OTHER
EP5 6910000340 SHEET
EP9 6910000310 M.OTHER
DESCRIPTION
AJS1315
AJS1315
AGP 2013
16FE-BT-M
TMP-J01X-V6
IPS-1041-4
IPS-1041-4
IPS-1041-4
JPW 02A
IPS-1041-4
IPS-1041-4
JPW 01 R-01
JPW 02A
SX1632 1.5D COAXIAL (2)/FI
B 4251G
DESCRIPTION
MR-DS
FH-052S
FH-052S
FGB 30A
FGB 30A
OPC-569
OPC-564
OPC-565
SX1632 1.5D COAXIAL (1)/PA
SX1632 P4602×4603PA
P101 KD
B312D
[TERMINAL BOARD]
REF ORDER
NO. NO.
C1 4510005980 ELECTROLYTIC
C2 4010006900 CERAMIC
C3 4010006890 CERAMIC
C4 4010006890 CERAMIC
C5 4010006900 CERAMIC
C6 4010006900 CERAMIC
J1 6510010020 CONNECTOR
F1 5220000110 HOLDER
F2 5210000060 FUSE
WS1 8970022051 M.OTHER
WS2 8970022060 M.OTHER
WS3 8970023240 M.OTHER
EP1 0910044565 PCB
EP3 6510018330 TERMINAL
EP4 6510018330 TERMINAL
EP5 6910000630 BEAD
EP6 6910000630 BEAD
EP7 6510013860 TERMINAL
EP8 6510013860 TERMINAL
[ALARM BOARD]—Marine version only
REF ORDER
NO. NO.
IC5001 1130007800 S.IC
Q5001 1530002690 S.TRANSISTOR
X5001 6060000150 S.CERAMIC
R5001 7030003620 S.RESISTOR
R5002 7030003640 S.RESISTOR
R5003 7030003440 S.RESISTOR
R5004 7030003640 S.RESISTOR
R5005 7030003440 S.RESISTOR
R5006 7030003680 S.RESISTOR
R5007 7030003710 S.RESISTOR
R5008 7030003440 S.RESISTOR
R5009 7030003440 S.RESISTOR
R5010 7030003640 S.RESISTOR
C5001 4550006140 S.TANTALUM
C5002 4550006210 S.TANTALUM
C5004 4030006880 S.CERAMIC
C5005 4030007090 S.CERAMIC
C5006 4030007090 S.CERAMIC
C5007 4030006860 S.CERAMIC
C5008 4030006850 S.CERAMIC
J5001 6510018160 S.CONNECTOR
J5002 6510018170 S.CONNECTOR
EP5001 0910045601 PCB
5 - 21
DESCRIPTION
16 MV 4700 HC
HE80SJ YB 472K 50V
HE60SJ YB 222K 50V
HE60SJ YB 222K 50V
HE80SJ YB 472K 50V
HE80SJ YB 472K 50V
RTB-1.5-2F
TFH-S30
FGB 5A
SX1632 J READ SET-1 (4)/TE
SX1632 J BOARD SET (2)/TE
SX1632 LEAD (1)/TE
B 4421E
F4053A
F4053A
FSOH070RN
FSOH070RN
FV2-S3.3
FV2-S3.3
DESCRIPTION
S-7116AF-TF
2SC4116-GR (TE85R)
CSAC3.58MGC300CD
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 184 V (180 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ECST1EY474R
ECST1CX106R
C1608 JB 1H 472K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 471K-T-A
4-175643-0
4-175643-4
B 4368A
S.=Surface mount
