Icom IC-7400 Service Manual page 58

MAIN and RF units
(Top view)
J700 (M)
J740 (M)
J760 (M)
J782 (M) MP200 (M)
MP1901 (RF)
J780 (M)
MP1903 (RF)
J781 (M)
MP282 (RF)
MP281 (RF)
RF UNIT
J401 (RF)
MP181 (RF)
MP212 (RF)
MP211 (RF)
MP35 (C)
MP72
(C)
DSP UNIT
MP213 (RF)
MP1207 (RF)
MP1 (DSP)
MP2 (DSP)
MP3 (DSP)
MP75 (C)
MP71 (C)
MP16 (C)
MP51 (C)
MP1204 (RF)
MP52 (C)
MP53 (C)
MP77 (C)
MAIN UNIT
MP1802 (RF)
MP1102 (RF)
MP1101 (RF)
MP1801 (RF)
MP1302 (RF)
MP1602 (RF)
MP1303 (RF)
MP1604 (RF)
MP1601 (RF) MP1301 (RF)
MP1203 (RF)
MP1202 (RF)
MP1201 (RF)
MP1403 (RF)
MP1402 (RF)
MP1404 (RF)
MP1401 (RF)
MP1502 (RF)
MP1501 (RF)
MP124 (RF)
MP125 (RF)
MP122 (RF)
MP121 (RF)
MP791 (M)
MF1 (TU)
MAIN UNIT
(Bottom view)
MP15 (C)
RF UNIT
(Bottom view)
MP214 (RF)
MP2 (RF)
MP251 (RF)
MP126 (RF)
MP1603 (RF)
MP1 (RF)
MP123 (RF)
MP301 (RF)
MP1205 (RF)
MP74 (C)
MP19 (C)
CTRL UNIT
MP1 (CT)
MP4 (CT)
MP20 (C)
MP5 (C)
MP1 (TU)
MP4 (TU) MP3 (TU)
MP6 (TU)
MP2 (TU)
MP7 (TU)
MP5 (TU)
MP8 (TU)
MF2 (TU)
MP22 (C)
MP63 (C)
MF1 (C)
MP27 (C)
MP8 (C)
MP50 (C)
MP2 (CT)
MP66 (C)
MP67 (C)
MP9 (TU)
MP18 (C)
VARISTOR-B
BOARD
VARISTOR-D
BOARD
MP41
MP7
(C)
(PA)
VARISTOR-A
BOARD
MP10 (C)
MP2
(PA)
VARISTOR-C
TUNER
BOARD
UNIT
MP25 (C)
PA UNIT
MP64 (C)
SP1 (C) MP34 (C)
EP4 (C)
MP23 (C)
MP9 (C)
J5 (C)
EP3 (C)
MP65 (C)
DRV BOARD
J6 (C)
MP24 (C)
J7 (C)
MP40 (C)
MP39 (C)
MP59 (C)
Unit abbreviations
MP1 (C)
7 - 3
MP21 (C)
MP4 (C)
MP42 (C)
MP43 (C)
FILTER
UNIT
MP17 (C)
MP17
(C)
MP56 (C)
MP58
(C)
MP55
(C)
MP6 (PA)
MP26 (C)
MP3 (PA)
MP4 (PA)
MP32 (C)
(C) : CHASSIS PARTS
(M) : MAIN UNIT
(PA) : PA UNIT
(CT) : CTRL UNIT
(TU) : TUNER UNIT
(RF) : RF UNIT
(DSP) : DSP UNIT
