Ten-Key Board; Mode Board; Phone Board; Rit Board - Icom IC-7400 Service Manual

[PHONE BOARD]

REF ORDER
NO. NO.
L1 6200003950 S.COIL
L2 6200003950 S.COIL
R1 7030006240 S.RESISTOR
R2 7030006240 S.RESISTOR
R3 7030003440 S.RESISTOR
C1 4030006880 S.CERAMIC
C2 4030006880 S.CERAMIC
C3 4030006880 S.CERAMIC
J1 6450001890 CONNECTOR
J2 6450001790 CONNECTOR
J3 6510019970 S.CONNECTOR
EP1 0910054550 PCB

[MIC BOARD]

REF ORDER
NO. NO.
L1 6200003260 S.COIL
L3 6200003260 S.COIL
L4 6200003260 S.COIL
L6 6200003260 S.COIL
C1 4030006880 S.CERAMIC
C2 4030006880 S.CERAMIC
C3 4030006880 S.CERAMIC
C4 4030006880 S.CERAMIC
C5 4030006880 S.CERAMIC
C6 4030006880 S.CERAMIC
C7 4030007130 S.CERAMIC
J1 6510000190 CONNECTOR
J2 6510019970 S.CONNECTOR
EP1 0910054561 PCB

[MODE BOARD]

REF ORDER
NO. NO.
J1 6510019990 S.CONNECTOR
EP1 0910054570 PCB

[RIT BOARD]

REF ORDER
NO. NO.
J1 6510019970 S.CONNECTOR
S1 2250000340 ENCODER
EP1 0910054600 PCB
DESCRIPTION
HF50ACC 322513-T
HF50ACC 322513-T
ERJ12YJ181U (180 Ω)
ERJ12YJ181U (180 Ω)
ERJ3GEYJ 102 V (1 kΩ)
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
HLJ5305-01-4090
HLJ7000-01-3010
52808-1091
B 5691
DESCRIPTION
NL 322522T-101J
NL 322522T-101J
NL 322522T-101J
NL 322522T-101J
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 101J-T-A
FM214-8SS (P)
52808-1091
B 5692A
DESCRIPTION
52808-2291
B 5693
DESCRIPTION
52808-1091
EVQ-VCJF0324B
B 5696

[TEN-KEY BOARD]

REF ORDER
NO. NO.
R1 7030003540 S.RESISTOR
R2 7030003540 S.RESISTOR
R3 7030003540 S.RESISTOR
R4 7030003480 S.RESISTOR
R5 7030003480 S.RESISTOR
R6 7030003480 S.RESISTOR
R7 7030003520 S.RESISTOR
R8 7030003520 S.RESISTOR
R9 7030003520 S.RESISTOR
R10 7030003580 S.RESISTOR
R11 7030003580 S.RESISTOR
R12 7030003580 S.RESISTOR
R15 7030003540 S.RESISTOR
R16 7030003480 S.RESISTOR
R17 7030003520 S.RESISTOR
R18 7030003580 S.RESISTOR
R19 7030003540 S.RESISTOR
R20 7030003480 S.RESISTOR
R21 7030003520 S.RESISTOR
R22 7030003580 S.RESISTOR
R23 7030003540 S.RESISTOR
R24 7030003480 S.RESISTOR
R25 7030003520 S.RESISTOR
C1 4030011600 S.CERAMIC
C2 4030011600 S.CERAMIC
C3 4030011600 S.CERAMIC
C4 4030011600 S.CERAMIC
C5 4030011600 S.CERAMIC
C7 4030011600 S.CERAMIC
J1 6510019990 S.CONNECTOR
DS1 5040002360 S.LED
DS2 5040002220 S.LED
DS3 5040002360 S.LED
DS4 5040002220 S.LED
DS5 5040002220 S.LED
EP1 0910054580 PCB

[PBT BOARD]

REF ORDER
NO. NO.
R2 7030003560 S.RESISTOR
R3 7030003560 S.RESISTOR
R4 7030003560 S.RESISTOR
R5 7030003560 S.RESISTOR
R6 7030003560 S.RESISTOR
R7 7030003560 S.RESISTOR
J1 6510019970 S.CONNECTOR
S1 2250000440 ENCODER
S2 2250000410 ENCODER
EP1 0910054591 PCB
6 - 2
DESCRIPTION
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
C1608 JB 1E 104K-T-N
C1608 JB 1E 104K-T-N
C1608 JB 1E 104K-T-N
C1608 JB 1E 104K-T-N
C1608 JB 1E 104K-T-N
C1608 JB 1E 104K-T-N
52808-2291
CL-220HR-C-TU
CL-220YG-C-TU
CL-220HR-C-TU
CL-220YG-C-TU
CL-220YG-C-TU
B 5694
DESCRIPTION
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
52808-1091
TP90N00E20-22.5F-2494
TP90D96E20-30F-2178-1
B 5695A
S.=Surface mount
