[PA UNIT]
REF ORDER
NO. NO.
C676 4030011600 S.CERAMIC
C677 4030011600 S.CERAMIC
C678 4030011600 S.CERAMIC
C679 4030011600 S.CERAMIC
C680 4030011600 S.CERAMIC
C681 4030011600 S.CERAMIC
C682 4030011600 S.CERAMIC
C683 4030011600 S.CERAMIC
C684 4030011600 S.CERAMIC
C685 4030006860 S.CERAMIC
C686 4030006860 S.CERAMIC
C687 4030006860 S.CERAMIC
C688 4030006860 S.CERAMIC
C689 4030006860 S.CERAMIC
C690 4030006860 S.CERAMIC
C691 4030006860 S.CERAMIC
C692 4030006860 S.CERAMIC
RL591 6330001550 RELAY
CP573 6910009670 S.CHECK P
CP574 6910009670 S.CHECK P
J160 6510021530 CONNECTOR
J161 6510021530 CONNECTOR
J172 6510007020 CONNECTOR
J210 6510021530 CONNECTOR
J211 6510021530 CONNECTOR
J270 6510017150 CONNECTOR
J571 6510018960 S.CONNECTOR
J621 6510019980 S.CONNECTOR
J641 6450000140 CONNECTOR
J661 6510020080 S.CONNECTOR
F591 5210000130 FUSE
F592 5220000230 HOLDER
F593 5220000230 HOLDER
W235 7030000010 S.JUMPER
W300 7030008240 S.JUMPER
W301 7030008240 S.JUMPER
W316 7030003860 S.JUMPER
W320 7030003860 S.JUMPER
W361 7120000470 JUMPER
W409 7030000010 S.JUMPER
W462 7030003860 S.JUMPER
W572 7030003860 S.JUMPER
WS1 8970023310 M.OTHER
WS2 8970022462 M.OTHER
WS3 8970023271 M.OTHER
WS4 8600036490 M.OTHER
WS6 8600036470 M.OTHER
WS7 8600034701 M.OTHER
WS8 8970023340 M.OTHER
EP1 0910050976 PCB
EP174 9018970370 TUBE
DESCRIPTION
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
JV-12-KT
HK3-S-T
HK3-S-T
IMSA-9230B-1-04Z024-T
IMSA-9230B-1-04Z024-T
TMP-J01X-V6
IMSA-9230B-1-04Z024-T
IMSA-9230B-1-04Z024-T
TMP-S01X-C1
B2B-PH-SM3-TB
52808-1690
HSJ0807-01-010
52808-2090
FGB 4A
S-N5054 #01
S-N5054 #01
MCR10EZHJ JPW (000)
ERJ12YJ0R00H
ERJ12YJ0R00H
ERJ3GE JPW V
ERJ3GE JPW V
ERDS2T0
MCR10EZHJ JPW (000)
ERJ3GE JPW V
ERJ3GE JPW V
SX2177 1.5D COAXIAL (2)/PA
SX1897 J BOARD SET-2 (1)/PA
SX2177 SPECIAL WIRE (1)/PA
SX2177 P601PA
SX2177 J611 612PA
SX2177 P651 J651PA
SX2177 J LEAD SET (1)/PA
B 5211F
TUBE 20(d) L=25 mm

[FILTER BOARD]

REF ORDER
NO. NO.
IC1 1110002700 S.IC
Q1 1590000680 S.TRANSISTOR
Q2 1530002060 S.TRANSISTOR
Q3 1530002060 S.TRANSISTOR
Q4 1530002060 S.TRANSISTOR
Q5 1530002060 S.TRANSISTOR
Q6 1530002060 S.TRANSISTOR
Q7 1530002060 S.TRANSISTOR
Q8 1530002060 S.TRANSISTOR
Q9 1530003090 S.TRANSISTOR
Q10 1530002060 S.TRANSISTOR
Q11 1540000450 S.TRANSISTOR
Q12 1590001870 S.TRANSISTOR
D1 1750000300 S.DIODE
D2 1750000300 S.DIODE
D3 1750000300 S.DIODE
D4 1750000300 S.DIODE
D5 1750000300 S.DIODE
D6 1750000300 S.DIODE
D7 1750000300 S.DIODE
D8 1750000300 S.DIODE
D9 1790001210 S.DIODE
D10 1790001210 S.DIODE
D23 1750000300 S.DIODE
D24 1160000050 S.DIODE
D25 1750000640 S.DIODE
D26 1790001250 S.DIODE
L1 6110001560 COIL
L2 6110001630 COIL
L5 6110003570 COIL
L6 6110003570 COIL
L7 6110003550 COIL
L10 6140001800 COIL
L11 6140001800 COIL
L14 6140003450 COIL
6140003470 COIL
L15 6140003460 COIL
L18 6140002560 COIL
L19 6140002560 COIL
L22 6110002920 COIL
L23 6110003580 COIL
L26 6140001800 COIL
L27 6140001780 COIL
L30 6140002570 COIL
L31 6140002580 COIL
L33 6140003490 COIL
L34 6200002040 S.COIL
L35 6200003950 S.COIL
L36 6200002040 S.COIL
L37 6200002040 S.COIL
L39 6200003950 S.COIL
L41 6200003950 S.COIL
L42 6200003950 S.COIL
L43 6200003950 S.COIL
L44 6200002040 S.COIL
L45 6200002040 S.COIL
L46 6200002040 S.COIL
L47 6200002040 S.COIL
L48 6200002040 S.COIL
L49 6200002040 S.COIL
L50 6140002560 COIL
L51 6200003950 S.COIL
L54 6200002040 S.COIL
L55 6200002040 S.COIL
L56 6200005010 S.COIL
L57 6200002040 S.COIL
L58 6200003950 S.COIL
L59 6200003950 S.COIL
L60 6200002040 S.COIL
L61 6200003950 S.COIL
L63 6200005010 S.COIL
L64 6200002040 S.COIL
L65 6200002040 S.COIL
L66 6200002040 S.COIL
L67 6200002040 S.COIL
L68 6200003590 S.COIL
5 - 20
DESCRIPTION
NJM2904M-T1
DTC114EUA T106
2SC4081 T107 R
2SC4081 T107 R
2SC4081 T107 R
2SC4081 T107 R
2SC4081 T107 R
2SC4081 T107 R
2SC4081 T107 R
2SC4213-B (TE85R)
2SC4081 T107 R
2SD1623-T-TD
DTA114EE TL
1SS302 (TE85R)
1SS302 (TE85R)
1SS302 (TE85R)
1SS302 (TE85R)
1SS302 (TE85R)
1SS302 (TE85R)
1SS302 (TE85R)
1SS302 (TE85R)
1SS375-TL
1SS375-TL
1SS302 (TE85R)
DAP202U T107
1SV312 (TE85L)
MA2S111-(TX)
LA-236
LA-246
LA-550
LA-550
LA-547 (LA-214A)
LR-216 (T50-2)
LR-216 (T50-2)
LR-387 [EUR], [FRA], [ESP]
LR-389 [USA], [OTH]
LR-388
LR-293 (T50-10)
LR-293 (T50-10)
LA-481
LA-551
LR-216 (T50-2)
LR-214 (T50-2)
LR-294 (T50-2)
LR-295 (T50-2)
LR-391
NL 252018T-101J
HF50ACC 322513-T
NL 252018T-101J
NL 252018T-101J
HF50ACC 322513-T
HF50ACC 322513-T
HF50ACC 322513-T
HF50ACC 322513-T
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
LR-293 (T50-10)
HF50ACC 322513-T
NL 252018T-101J
NL 252018T-101J
NL 252018T-100J
NL 252018T-101J
HF50ACC 322513-T
HF50ACC 322513-T
NL 252018T-101J
HF50ACC 322513-T
NL 252018T-100J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
NL 252018T-101J
EXCCL3225U1
S.=Surface mount
