Summary of Contents for Baumann Meyer DT2620D
- Page 1 LCD TV Operating Instructions 26” 32” P/N 6P9-A30-107100...
-
Page 2: Table Of Contents
Content Content ■ Conformity ............................... 3 Disposal ..............................3 ■ Unpacking and Setup ......................... 4 Scope of Supply ............................4 Safety ................................. 4 Location ..............................6 Intended purpose ........................... 6 ■ Viewing the Control Panels ......................7 Front View ..............................7 Rear View .............................. - Page 3 Content Adjust Medium and Low Frequencies ....................29 Set the Audio Input (HDMI or PC) ...................... 29 Set Sound Source ..........................30 Set Time ..............................30 Set Switch on Time ..........................31 Set Switch off Time ..........................32 Automatic Switch off ..........................
-
Page 4: Conformity
Conformity Conformity This product fulfills the EC guidelines 89/336/EEC (EMC guideline) with amendments 93/68 EEC and 92/31 EEC and the EC guideline 73/23/EEC (low voltage guideline) with amendments 93/68/EEC. Disposal This product is subject to the European guideline 2002/96/EC. All electric and electronic devices must be disposed of separately from household waste at publicly established facilities. -
Page 5: Unpacking And Setup
Unpacking and Setup Unpacking and Setup Scope of Supply Please check, that the delivery is complete. Unit Remote control Batteries Mains cable Safety • Read the following instructions carefully. • Keep this manual at hand. • Closely follow the instructions given. •... - Page 6 Unpacking and Setup • Only use suitable stands, supports, carts or tables that ensure the unit does not tip over. If you place the unit on a cart, move it with caution to prevent injuries or damage resulting from tip-over. •...
-
Page 7: Location
Unpacking and Setup Location ➤ The Best Distance The distance when watching programs on a television of this size should be approximately 2.2 to 2.7 metres. If the distance is too large or too small, this may lead to strain of your eyes. This may impair your health. ➤... -
Page 8: Viewing The Control Panels
Viewing the Control Panels Viewing the Control Panels Front View Input source selection button Remote control sensor MENU selection button Power Indicator Volume adjustment button Power button Channel selection button Speaker Rear View 26” 32” SPDIF OUT (Optical) may have the signal compatibility problems with certain A/V receiver and this is known issues. -
Page 9: Remote Control
Remote Control Remote Control Remote Control 1 Power On/Off button 13 Temporary Sound Mute 2 Numeric buttons 14 TV Input Source Selection 3 One/Two-Digit Channel 15 External Source Input Selection Selection 4 Favorite Channel Selection 16 Picture Size Selection 5 Picture Still 17 Previous Channel 6 Sleep Timer 18 TV Information Display... -
Page 10: Remote Control (For Dtv)
Remote Control Remote Control (For DTV) 1 Power On/Off button 15 External Source Input 2 Numeric buttons Selection 16 Picture Size Selection 3 One/Two-Digit Channel 17 Previous Channel Selection 4 Favorite Channel Selection 18 TV Information Display 5 Picture Still 19 Sound Selection : 6 Sleep Timer Mono/Stereo Dual Select... -
Page 11: Connections And Start Of Operation
Connections and Start of Operation Connections and Start of Operation Connections for TV Reception You can connect roof aerial, cable reception, a satellite receiver, set top boxes (DVB-T) or video recorders etc. to the unit. Connecting a Satellite Receiver, a Set Top Box or a Video Recorder ➤... -
Page 12: Connecting To The Roof Aerial
Connections and Start of Operation ➤ Connecting to a Device without SCART Socket Use a coaxial cable to connect the units. 1 Plug the coaxial cable into the socket [ANT] on the television set. 2 Plug the other end of the coaxial cable into the output socket on the receiver. -
Page 13: Connecting To Cable Reception
Connections and Start of Operation Connecting to Cable Reception 1 Plug the coaxial cable of the cable reception into the socket [ANT]. Connecting to Headphones The output for the headphone is on the right rear side of the unit. If you connect a headset to the unit, the main speaker will be switched off. - Page 14 Connections and Start of Operation ➤ Connecting Camcorders and Video Games by S-Video Cable 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 Connect the S-Video cable to the socket [S-VIDEO] and the output sockets of the external devices. Plug the audio cable into the socket [AUDIO IN] on the television set and connect the cable to the output socket of the external device.
-
Page 15: Connecting To A Computer
Connections and Start of Operation Connecting to a Computer You can use the television set as a monitor for the computer. This is possible parallel to television operation. Use a 15-pin D-Sub cable to connect the television set to the computer. 1 Plug the cable into the output socket of the graphic board. -
Page 16: Connecting The Digital Audio Output
Connections and Start of Operation Connecting the Digital Audio Output You can Connect optical digital audio cable to "DIGITAL AUDIO OUT" on the rear of the TV and the other end to "DIGITAL AUDIO IN" of the equipment with a digital output to enjoy digital sound (Multi-Channel Surround Sound, Stereo, Dolby Sound). -
Page 17: Inserting The Batteries
Connections and Start of Operation 1 Connecting HDMI/DVI Cable Connect the HDMI/DVI cable and audio cable from the output jacks on the DVD player or Set-top box to the [HDMI] input jack and PC Audio input jacks on the TV. 2 Connecting HDMI Cable Connect the HDMI cable from the output jack on the DVD player or Set-top box to the [HDMI] input... -
Page 18: Settings
Settings Settings Switching On Press the power switch (main) on the back of the unit. (32” model only) Press on the remote control. This switches the unit on and it can be operated using the remote control. If it is not explicitly stated otherwise, it will be assumed that the unit and the TV set are switched on and will be operated by the remote control. -
Page 19: Open, Select And Close Menus
Settings Open, Select and Close Menus The settings of the unit are accessible via menus. To navigate in the menus proceed as follows: 1 Press The main menu opens. The submenu selected last will be displayed. Picture Audio Timer Install Setup Option 2 If necessary, press... -
Page 20: Change Channel
Settings 1 Press . To return to the main menu, press several times. 2 Press and select INSTALL. Picture Audio Timer Install Setup Option 3 Press and select AUTO TUNING. Auto Tuning Italy Auto Tuning 4 Press Programme Austria Colour Belgium 5 Select the country where you want to operate System... -
Page 21: Set Colour System
Settings Set Colour System Use this function to set the television signal to your national television standard. These settings are made automatically by the automatic tuning function. You should only change the settings described in this section, if you are familiar with the reception of television signals. -
Page 22: Manual Tuning
Settings Manual Tuning Use this function to tune the channels manually. 1 Press . To return to the main menu, press several times. 2 Press and select INSTALL. Picture Audio Timer Install Setup Option 3 Press and select PROGRAMME. Auto Tuning Italy 4 Press Programme... -
Page 23: Change Channel Name
Settings Change Channel Name The names of the channels are programmed into the receiver. You can change these names manually. 1 Press . To return to the main menu, press several times. 2 Press and select INSTALL. Picture Audio Timer Install Setup Option... -
Page 24: Improve Signal Quality
Settings Improve Signal Quality Use this function to improve poor signal quality. 1 Press . To return to the main menu, press several times. 2 Press and select INSTALL. Picture Audio Timer Install Setup Option 3 Press and select WEAK SIGNAL Auto Tuning Italy Programme... -
Page 25: Reduce Noise
Settings Reduce Noise Use this function to reduce picture noise. 1 Press . To return to the main menu, press several times. 2 Press and select OPTION. Picture Audio Timer Install Setup Option 3 Press and select NOISE REDUCTION. Local Lock 4 Press OSD Setting No Signal Power Off... -
Page 26: Set Screen Language
Settings Set Screen Language By default, the unit is set to the English language. The screen display text can be displayed in several languages. 1 Press . To return to the main menu, press several times. 2 Press and select SETUP. Picture Audio Timer... -
Page 27: Set Picture Mode
Settings ➤ Display if no Wide Screen Signal is Received Most programs are broadcast together with a signal describing the format of the picture. With this function you can set the way the picture is displayed, if no such signal is received. This function is only available, if you have set the picture format to AUTO. - Page 28 Settings If you use the PIP function, you can change the picture mode as follows: Press Change the picture mode in the main picture Change the picture mode in the sub picture * There is no the in 2-tuner model. If you want to change the picture mode in the sub picture, first you select the sub picture by pressing the OK, and change the picture mode using the ➤...
-
Page 29: Audio Settings
Settings Audio Settings ➤ Set Balance 1 Press . To return to the main menu, press several times. 2 Press and select AUDIO. Picture Audio Timer Install Setup Option 3 Press and select BALANCE. Balance 4 Press Volume Equalizer Music 5 Press to select the desired setting. -
Page 30: Adjust Medium And Low Frequencies
Settings Adjust Medium and Low Frequencies Use this function to boots the medium and low frequencies to create a better surround sound. For this the SRS technology is used. is a registered trademark. ® 1 Press . To return to the main menu, press several times. -
Page 31: Set Sound Source
Settings Set Sound Source Use this function to set which sound you will hear when watching picture-in-picture mode. 1 Press . To return to the main menu, press several times. 2 Press and select AUDIO. Picture Audio Timer Install Setup Option 3 Press and select AUDIO SELECTION. -
Page 32: Set Switch On Time
Settings ➤ Set Time by Station Use this function to set the time of the unit to the time broadcast by the station. 1 Press . To return to the main menu, press several times. 2 Press and select TIMER. Picture Audio Timer... -
Page 33: Set Switch Off Time
Settings Set Switch off Time Use this function to set a time when the unit turns off. 1 Press . To return to the main menu, press several times. 2 Press and select TIMER. Picture Audio Timer Install Setup Option 3 Press and select OFF TIMER. -
Page 34: Set On-Screen Display
Settings ➤ Switch Off if no Key is Pressed This function switches the unit automatically off, if no key is pressed for a longer time. 1 Press . To return to the main menu, press several times. 2 Press and select OPTION. Picture Audio Timer... -
Page 35: Child Lock
Settings ➤ Set Transparency Use this function to set the transparency of the on-screen display. 1 Press . To return to the main menu, press several times. 2 Press and select OPTION. Picture Audio Timer Install Setup Option 3 Press and select OSD SETTING. -
Page 36: Set Characters For Teletext
Settings ➤ Deactivate Child Lock To deactivate child lock, proceed as described in chapter “Activate Child Lock” on page34 and select OFF. Set Characters for Teletext Use this function to set the character set for teletext to your region. 1 Press . -
Page 37: Dtv Setting (Option)
DTV Setting (Option) Setting up Digital Television Tuner This feature operates only in the model with a built-in digital broadcast tuner. Television is not pre tuned and "No Signal" will appear on screen until antenna is connected to DTV aerial input and Digital Tuner is setup. -
Page 38: Manual Channel Scanning
DTV Setting (Option) Manual Channel Scanning You can specify each channel manually by either physical number or frequency to program TV channels. ☛ Physical channel refers to the channels UHF or VHF number, the familiar channel numbers of 2, 7, 9 and 10 are not the physical channel numbers required for this type of tuning. -
Page 39: Channel Editing
DTV Setting (Option) Channel Editing Press the SETUP button on the bottom row of the remote CHANNEL control, the Digital Setup menu will appear Channel Edit Use the ( ) button to highlight the antenna icon if not Channel Scan already highlighted. -
Page 40: Selecting The Channel
DTV Setting (Option) Selecting the Channel You can change the current channel to any other channel you want. Press the CH.LIST button. The CHANNEL LIST is displayed. Press the ( ) button to select the channel that you want. When the scroll bar is positioned on the channel you want to CHANNEL LIST view press OK . -
Page 41: Setting Up The Parental Lock
DTV Setting (Option) Setting up the Parental Lock This sub-menu allows you to set the age for parental locking and protect children from viewing programs unsuitable for their age. ➤ Setting the Parental Ratings SYSTEM Parental Rating Press the SETUP button. Opacity Press the ( ) button to select SYSTEM and press the OK... -
Page 42: Adjusting The Translucency Level
DTV Setting (Option) Adjusting the Translucency Level You can set the translucency level of menus screen, teletext or closed captions. Press the SETUP button. SYSTEM Press the ( ) button to select SYSTEM and press the OK Parental Rating button. Opacity Press the ( ) button to select Opacity and press the OK... -
Page 43: Selecting The Time Zone
DTV Setting (Option) Selecting the Time Zone Press the SETUP button. SYSTEM Press the ( ) button to select SYSTEM and press the OK Parental Rating NSW/ACT button. Opacity VIC/TAS Press the ( ) button to select Time Zone and press the Time Zone OK button. -
Page 44: Setting The Factory Default
DTV Setting (Option) Setting the Factory Default The status of DTV Mode settings will return to factory default parameters by using this function. Press the SETUP button. SYSTEM Press the ( ) button to select SYSTEM and press the OK Parental Rating button. -
Page 45: Tv / Radio Switching
DTV Setting (Option) TV / RADIO Switching You can use this menu when you change a TV channel to a radio channel or vice versa. Press the TV/RADIO button. When listening a radio channel, radio channel information will be displayed on the TV screen. This TV/RADIO button does not work when the radio channel is not stored. -
Page 46: Watching
Watching Watching Watch Current Television Program When you switch the unit on, the current television program will be displayed. Set Volume Press to set the desired volume. ➤ Mute Press to switch the sound temporarily off. Press to switch the sound on again. Change Channel Press to scroll through the channels. -
Page 47: Recall A Favourite Channel
Watching Recall a Favourite Channel Use this function to scroll through the channels or sources you have stored as your favourite stations. This way you do not need to scroll through all the stations, if you only want to watch specific subjects. On how to store channels as your favourites see: “Channel Groups”... -
Page 48: Watch Two Programs At The Same Time (Pip )
Watching Watch Two Programs at the Same Time (PIP ) Use this function to display a second picture. This way you can watch two programs you are receiving by antenna or by the other inputs at the same time. You can display on large and one small picture or two pictures of the same size. -
Page 49: Set Picture-In-Picture Size
Watching Set Picture-in-Picture Size Use this function to set the size of the small picture. Press Press Press and select the desired size. You can also adjust this setting in the menu OPTIONS. Set Picture-in-Picture Position Use this function to set where the sub screen will be displayed. Press Press Press... -
Page 50: Still Picture
Watching Still Picture Use this function to hold the picture. Press During the display of the still picture the sound will continue to play. Press again to continue watching. Show Time Use this function to display the time. If teletext is displayed, the time will not be shown. Press Press again to hide the time. -
Page 51: Set Sound Effect While Watching
Watching Set Sound Effect while Watching Use this function to set the sound effects. Press Press again to switch the sound effect off. For further information on the settings refer to: “Adjust Medium and Low Frequencies” on page 29. Set Sound while Watching Use this function to adjust the sound optimally to the content. -
Page 52: Cleaning And Troubleshooting
Cleaning and Troubleshooting Cleaning and Troubleshooting Cleaning Use a dry cloth to clean the unit. Never use water, cleaning detergents or spray cleaners. Troubleshooting If there are problems with the unit, please check the following points before contacting the technical service. Never open the unit. - Page 53 Cleaning and Troubleshooting Some Channels Display Black and • Check if other channels display colours. If yes, the program is White broadcast in black and white. Adjust the colour settings. Snow on one or Several Channels • Check whether the antenna cable is in proper condition and if it is connected to the respective sockets.
-
Page 54: Technical Specifications
Technical specifications Technical specifications Type a-Si TFT Active Matrix LCD Aspect Ratio 16:9 Display 1366 x 768 Native Resolution Number of Colors 480i/P, 576i/P, 720P, 1080i Video Compatible PAL/SECAM BG, DK, I, L, L’, AV NTSC System 100 Programs Channel 12 Language OSD Language (Eng/Fr/Ger/Ita/Spa/Dutch/Por/Norse/Dan/Swed/Fin+1) - Page 55 Settings Memo Memo...
