DS Camera Head

DS Camera Head
Image pickup device
Color / Black and white
Infrared blocking filter
Note
Maximum frame rate
Number of recording pixels
Quantization
Sensitivity
Lens mount
Outer dimensions
Weight
Fixed tripod mount
Body color
Image pickup device cooling
Chapter 21
DS-Fi2
5.24 million pixel interline CCD
for 2/3 square pixel
10 (FULL)
18 (2x2)
29 (4x4)
21 (FAST)
19 (ROI-L)
37 (ROI-S)
2560 x 1920
1280 x 960
1280 x 480
640 x 480
14 bit
Equivalent to ISO 64
(Contrast: Standard, Camera
sensitivity: For setting x1)
C mount
Protrusion dimensions from the
mount surface to the inside of the
camera: 10 mm or less
Image circle: ø11 mm
82 (W) x 77.5 (D) x 48 (H) mm
270 g
Major Specifications
DS-Fi1
Color
Embedded
5.9 (FULL)
10 (2x2)
17 (4x4)
12 (FAST)
12 (ROI-L)
23 (ROI-S)
77 (W) x 76 (D) x 44 (H) mm
Tripod screw for the camera
White
None
Note: Description surrounded by parentheses indicates the
control mode for the image pickup device (image mode).
267
DS-Vi1
2.11 million pixel interline CCD
for 1/1.8 square pixel
15 (FULL)
27 (2x2)
29 (FAST)
29 (C.SCAN)
1600 x 1200
1600 x 560
800 x 600
800 x 560
400 x 300
400 x 280
12 bit
Equivalent to ISO 100
(Contrast: Standard, Camera
sensitivity: For setting x1)
C mount
Protrusion dimensions from the
mount surface to the inside of the
camera: 10 mm or less
Image circle: ø8.9 mm
260 g
