- Page 1 : 2012.03.30 model : QVI-LVTX-1CH-V6 / product code : LVTX-1CH-1201-003 Car Video Interface for Volkswagen with RCD550 Manual...
-
Page 2: Table Of Contents
Contents 1. Before installation 1.1 Main specification 1.2 Features 1.3 System diagram 1.4 Components 1.5 Exterior 2. SETUP 2.1 DIP switch 2.2 Remote control 2.3 Original buttons in car 2.4 OSD implementation 2.5 OSD (on screen display) 2.6 FACTORY mode 2.7 Rear view parking guide line 2.8 Touch calibration 2.9 Remote controller button... -
Page 3: Main Specification
1.1 Main specification 1. Input Spec. (MULTI VIDEO INTERFACE) - 1 x Analog R, G, B, C sync - 1 x CVBS(REAR CAMERA) Input. (Rear camera source) - 3 x A/V (NTST & PAL) Input. - 1 x LCD Input (Car system Input) 2. -
Page 4: Features
1.2 Features DVD, DTV and navigation are controlled via touching screen DVD, DTV are controlled via registering values of the buttons on the remote controller (only for models including remote controller) Control of position of the DVD, navigation image Mode change via mode switch... -
Page 5: System Diagram
1.3 System diagram Remote Control Switch for source toggle RGB Touch Input OEM Button (Can Signal) RGB Input In/Out A/V1 A/V2 VIDEO A/V3 CIRCUIT VIDEO MUX CVBS (Rear Camera) POWER CIRCUIT HEADREST TOUCH MONITOR NAVI DIP S/W Power Input (+8VDC~+18VDC) -
Page 6: Components
1.4 Components LVDS cable* 1ea TOUCH OUT cable * 1ea (HLVDSC0018) IR cable * 1ea (HTOUCH0004) (HIRCAB0002) SUB BOARD* 1EA (QCPASS0284) MODE cable * 1ea (HARETC0001) RGB cable * 1ea FFC cable(SMALL)*1ea (HNAVIC0004) (FFCABL0013) Remote control * 1ea (REMOTE0001) FFC cable(BIG)*1ea (FFCABL0012) POWER cable (24P) * 1ea REAR CAMERA POWER cable * 1ea... -
Page 7: Exterior
1.5 Exterior - SUB BOARD - ⑦ ⑥ ⑤ Dimension Horizontal length 147mm ⑧ ⑨ Vertical length 91mm Height 27mm ① LED ② POWER/CAN/RGB ⑪ ③ Rear camera ⑫ ⑩ ④ AV(IN/OUT) ⑧ FROM LCD PANEL ⑤ LVDS OUT ⑨ TO CAR SYSTEM ⑥... -
Page 8: Dip Switch
2.1 DIP switch #PIN function DIP S/W selection ※ ON : DOWN, OFF : UP ON : Skipping RGB Mode ※ DIP S/W usage RGB INPUT skip OFF : RGB Display - Input mode to intend to use : A/V3(DVD), Navigation (RGB) ON : Skipping A/V 1 - Rear view camera : installation on CVBS4 A/V 1 skip... -
Page 9: Remote Control
2.2 Remote control Function POWER & PIP Not for use MENU OSD implementation Making a selection Move upward ▲ ▼ Move downward Move leftward, press 2 seconds long-Factory ◀ mode implementation Move rightward, press 2 seconds long-Factory ▶ Mode implementation-Factory mode Reset... -
Page 10: Original Buttons In Car
2.3 Original buttons in car Mode change If there is the “receiver” button in car and CAN wire is connected, driver can change modes with the “receiver” button. Press long : mode change Press short : return to main image ※... -
Page 11: Osd Implementation
2.4 OSD implementation OSD implementation - DVD To implement DVD OSD menu, installer must install DVD system on AV1 and connect “IR-AV1” cable among power cables with remote sensor cable of DVD. First of all, if you touch the screen on mode ”AV1”, you can see the menu as shown left. -
Page 12: Osd (On Screen Display)
2.5 OSD (on screen display) OSD menu: Press ”MENU” button on the remote controller. Analog RGB Analog RGB Analog RGB Video Video Video IMAGE UTIL - BRIGHTNESS - LANGUAGE : To change the language - FACTORY RESET : To reset all the - CONTRAST displaying on navigation, DVD, DTV OSD values about navigation, DVD screen to... -
Page 13: Factory Mode
2.6 Factory mode Factory mode: press ◀ button 2 seconds long. IMAGE - H-POSITION : Control over horizontal movement of screen - V-POSITION : Control over vertical movement of the screen - NAVI MODEL : DEFAULT, KD900(WVGA), MD7000(WVGA),MYVI(WVGA),PAPAGO(WVGA) - AVOUT SELECT : DEFAULT, AV1, AV2, AV3 PARK - PARK ENABLE : Setup of rear view parking guide line - PARK SETUP : Control over position of rear view parking guide line (Refer to... -
Page 14: Rear View Parking Guide Line
2.7 Rear view parking guide line Factory mode: press ◀ button 2 seconds long. ① Register the value needed on the “PARK ENABLE” as “ON” in the PARK section as shown left. (default – ON) ② If you get rear gear after setup, parking guide line will appear on screen as shown left. -
Page 15: Touch Calibration
2.8 Touch calibration >>> ① First of all, press ◀ button on remote controller 2 ③ Then you can see “touch calibration” on seconds long. Then you can access to the FACTORY mode. screen about 2 seconds long as shown above. After the word “touch calibration”... -
Page 16: Remote Controller Button
2.9.1 Remote controller button Registering value of remote controller buttons? When you want to control DVD and DTV via touch screen (using OSD menu) with other models besides already registered option-SANYO and NECVOX, you can register value of DVD and DTV’ s remote controller which you have. Then you can control DVD and DTV via touch screen. - Page 17 2.9.2 Remote controller button >>> ③ After register, select “INPUT” in OSD menu and Instruction> continued… press “OK”. Then you can see confirmation window as c. The values that you registered will appear as green shown above. At the moment, if you choose “YES”, all text in the marked area on pressing the button.
-
Page 18: Dvd, Dtv Model Selection
2.10 DVD, DTV model selection Factory Default : DVD TYPE – NECVOX/SANYO (For Chinese DVD) DTV TYPE – CMMB (For Chinese DTV) DTV TYPE DVD TYPE UTIL – DVD/DTV TYPE If DVD/DTV type that you want to use is not NECVOX or SANYO, you have to register values of the remote controller that you want to use in the “IR MEMORY”... -
Page 19: Troubleshooting
3. Troubleshooting Q. I can not switch A/V sources. A. Check IR or Ground cable connection. Check LED lamps in the interface, if it is not on, check power cable. Q. All I got on the screen is black. A. Check second LED lamp of the interface is on, if not, check A/V sources connected are working well. (Second lamp indicates AV sources connected works well.) Check interface connection has been done well.
