- Page 1 Video Interface for Nissan Juke User Manual www.car-solutions.com support@car-solutions.com...
-
Page 2: Table Of Contents
1. Before installation 1.1 Specification 1.2 Features 1.3 System diagram 1.4 Components 1.5 Exterior 2. User interface 2.1 Dip switch 2.2 Keypad 2.3 Factory mode 2.4 Rear parking guide line 2.5 OSD(On Screen Display) Troubleshooting www.car-solutions.com support@car-solutions.com... - Page 3 - 3 x A/V Input (Rear video source) Input Spec. - 1 x CVBS(Rear camera) Input (Rear camera source) - 1 x Analog RGB Input (Navigation System output) (video interface) - 1 x LCD Input (Car system Input) - 1 x LCD Output (LCD operation) Output Spec.
-
Page 4: Features
– Clear high definition screen – NTSC, PAL system support – Mode exchange via the original buttons – Control over the position of NAVI, AV screen – Additional function of adjusting the screen size of NAVI www.car-solutions.com support@car-solutions.com... -
Page 5: System Diagram
Switch for source toggle Keypad OEM Navi Button (NAV) NAVIGATION Input (Analog RGB) DISPLAY Car Installation A/V 1 OEM LCD VIDEO MUX A/V 2 VIDEO CIRCUIT A/V 3 CVBS (Rear camera) POWER Car Screen Input A/V OUT CIRCUIT (CAR MAIN BOARD) HEADREST MONITOR Power Input... -
Page 6: Components
Black wire * 1ea AV cable * 1ea I/O board * 1ea FPC cable * 3ea RGB cable * 1ea Power cable * 1ea Touch cable * 1ea Main board * 1ea LVDS cable * 1ea Mode switch * 1ea OSD keypad with Relay * 1ea Sub-board * 1ea Ground cable * 1ea... -
Page 7: Exterior
1.5 Exterior ⑤ ⑥ ⑦ ⑧ Product dimension 155mm (Horizontal length) ⑧ ⑦ ⑥ ⑤ 93mm (Vertical length) 20mm (Height) ① POWER ② MODE ③ RGB (IN) ④ AV(IN/OUT) ⑤ LCD OUT ⑥ KEYPAD ⑦ DIP S/W ① ② ③ ④... -
Page 8: Dip Switch
2.1 DIP switch ※ ON : DOWN, OFF : UP default : all OFF #PIN Function Usage ※ DIP S/W usage example ON : RGB Mode X RGB INPUT skip - Input mode use : A/V2, A/V3 OFF : RGB Display - Use original navigation ON : A/V 1 X A/V 1 skip... -
Page 9: Keypad
2.2 Keypad ※ FACTORY MODE (Interface setting) : Press “UP” button about 2 seconds long and you will approach FACTORY mode. Also you can get there in pressing these keys in this sequence; “UP” → “DOWN” → “UP” → “MENU” Function MENU/EXIT Implement OSD screen... -
Page 10: Factory Mode
2.3 Factory mode ※ FACTORY mode – Press “UP” button on the keypad long about 2 seconds or press these buttons in this sequence; “UP”→”DOWN”→”UP”→”MENU” IMAGE - H-POSITION : control over the horizontal position of the screen - V-POSITION : control over the vertical position of the screen - H-SIZE : control over the size of NAVI screen PARK - PARK ENABLE : able to choose whether the rear guide line is displayed or not with rear... -
Page 11: Rear Parking Guide Line
① Once you change up into rear gear, the rear parking guide line will automatically appear on the screen like the left picture. ※ FACTORY default : DISPLAY - ENABLE ② If you press “UP” button on the keypad about 2 seconds long, you can see the left image on the screen. - Page 12 >>> level 4 level 0 ③ The width of the rear parking guide line has 5 level(0~4). After you control the level with “UP”, “DOWN” button on the keypad, you can move to the horizontal positioning mode after pressing “SEL” button and saving process. ( The current state is displayed right-top.
-
Page 13: Osd(On Screen Display)
Analog RGB Mode Video Mode IMAGE - BRIGHTNESS : adjusting brightness - CONTRAST : adjusting contrast - SATURATION : adjusting saturation - HUE : adjusting hue - SHARPNESS : adjusting sharpness - USER IMAGE : able to make a choice among 4 set-colors of the screen - LANGUAGE : choice of language - TRANSPARENT : control over the... -
Page 14: Troubleshooting
3 Troubleshooting Q. I can not switch A/V sources. A. Check IR or Ground cable connection. Check LED lamps in the interface, if it is not on, check power cable. Q. All I got on the screen is black. A. Check second LED lamp of the interface is on, if not, check A/V sources connected are working well. (Second lamp indicates AV sources connected works well.) Check interface connection has been done well.
