- Page 2 •Specification Car Compatibility : Discovery Sports, Jaguar XE, XF, F-Pace (8”) Components : Interface* 1ea, Sub-board*1ea Multimedia interface Input/output spec Input : HDMI*2, Analog RGB*1, A/V*1, CVBS(Rear view Camera)*1, CVBS(Front camera)*1 Output : To LCD*1 Power spec Input power : 8VDC ~ 18VDC Consumption : 5WATT Switch input mode ...
- Page 3 •Product exterior Length-90mm Height-18mm Width-140mm 5V-OUT(Power supply for Mirroring device) | HDMI-1 | HDMI-2 | MULTI | RGB-IN(RGB Navigation input) LVDS-OUT(Connection to Sub-board) | CAP T/S INPUT(Original touch cable connection) | RES T/S OUT(NOT FOR USE) | CAP T/S OUT(TOUCH CABLE CONNECTION-ONLY ITS PRODUCT) | TEST(NOT FOR USE) | LED | POWER/CAN(Power / CAN connection) | DIP S/W(DIP switch setting) •Components Sub-board * 1ea...
-
Page 4: Remote Control Setting
•DIP SWITCH ※ ON : DOWN / OFF : UP FUNCTION Dip S/W SETTING OFF : RGB DISPLAY RGB INPUT MUTE ON : Skipping RGB Mode OFF : HDMI1 DISPLAY HDMI1 MODE MUTE ON : Skipping HDM1 Mode OFF : AV DISPLAY AV MODE MUTE ON : Skipping AV Mode OFF : Front camera function on... - Page 5 •Factory setting Adjust a current screen position and size. H-POSITION : Move display horizontally V-POSITION : Move display vertically BRIGHTNESS : Adjust brightness of screen CONTRAST : Adjust contrast of screen Adjust rear view camera setting. PAS TYPE : Select type of parking guide line - NOT USED : No use parking guide line - PAS ON : Selecting Dynamic parking guide line - PAS OFF : Selecting fixed parking guide line...
- Page 6 •Factory setting Navigation & Car model setting up NAVI MODEL : Setting up RGB Navigation. (Default, Q-roi RGB, WP9230, HDMI(WVGA)) HDMI MODEL : Setting up HDMI1 Navigation. (Q-roi RGB, WP9320) CAR MODEL : Selecting the model of car. (2016 MODEL) HDMI2 SKIP : Skipping HDMI mode when switching modes.
- Page 7 •How to use OEM buttons ※ Able to switch modes via HOME or NAV button of car monitor. ※ Set up a button to switch on Factory Menu.
- Page 8 •Installation Diagram OE MNT Command HDMI NAVI BOX NAVI BOX CAN1-H(IN) CAN1-L(IN) CAN2-H(OUT) CAN2-L(OUT) LVDS Cable NAVI BOX Mirroring Device HDMI NAVI BOX ※ HDMI NAVI must be connected to HDMI-1.
- Page 9 •CAN cable connection ※ You may find cables as below behind of car command. Find a bunch of Disconnect the red Take out the black cover cables like above. marked cable. from the connector. Assemble the black Connect the Plug in the provided cable provided CAN IN/OUR cover to the provided to the red marked spot.
- Page 10 •CAN wire connection (F-Pace) ※ You can find the head unit under the driver seat. Find the head unit under the driver seat as above. Find the CAN cable as above behind the air conditioner unit and wire CAN cables. •LCD cable connection for Evoque ※...
- Page 11 •CAN wires setting (in case of CAN failure) ※ Swap 3 and 4 wires of provided power cable. ※ Car model for Switching CAN wires Discovery Sports equipped with 1 CAN connection...
- Page 12 •Connect to Q-ROI RGB Connect one wire into the most right pin hole of RGB Out cable. It’s Q-ROI RGB Uart wire. Connect the Uart cable* to CAP T/S Out from QHI-LR15 Interface. *The pink wire among three wires...
-
Page 13: Troubleshooting
•Trouble shooting Q. I cannot change mode A. Check connection of Ground cable and IR Cable. Check LED lamp is on, if not check connection of POWER cable. Q. All I got on the screen is black. A. Check second LED lamp of the interface is on, if not, check A/V sources connected are working well.
