Changing the bulbs

NOTE
Use only tested, incandescent bulbs with
the 'E' designation. Use of non-approved
bulbs will void the operating license. Do
not touch the bulbs with bare fingers. Hold
bulbs with a clean, dry cloth when installing
or removing them.
Headlight
1 = low beam
bulb 12V 55W E1
2 = High beam
12V 55W E1
bulb
3 = Position light
bulb 12V/5W
4
1
2
4
3
- Remove the screws (4) on both sides.
- Detach the rubber cover (5) from the
headlight case.
NOTES ON MAINTENANCE
6
7
- Release the holder clamp (6) and remove
the bulb (7).
- Pull the position light (3) with the bulb
holder carefully out of the headlight
housing.
Installation takes place in reverse order to
disassembly.
5
