Installing the front wheel

4
1
CAUTION
Take care not to damage the brake
discs and linings (4) while installing
them. Have a Sachs dealer check the
tightening torques.
- Roll the front wheel in between the fork
tubes and insert the spacer bush (4) (on
the right as seen from the riding direc-
tion).
5
3
- Grease the full floating axle (3) and push
it in with the spacer bushing (5) as far as
it will go.
- Attach the axle nut (2) and screw tight.
- Before tightening the screw (1) stand the
motorbike on its wheels and push the
telescopic forks several times to prevent
twisting of the fork struts.
Torque
Axle nut (2):
Axle locking screws (1):
NOTES ON MAINTENANCE
2
3
35-45 Nm
10 Nm
