SAFETY TEST

Clutch

2
A
3
Clutch lever play
CAUTION
If you drive with no clutch lever play, the
clutch will be damaged.
Checks:
- Pull the lever until there is discernable
resistance.
- Measure the play. Required value:
A = 3-4 mm
12
Adjustment:
- Remove the rubber cap (1).
- Release the lock nut (2).
1
- Turn setting screw (3) as appropriate.
- Tighten up the lock nut (2).
- Check the play.
NOTE
If this adjustment is not sufficient, adjust
by turning the setting screw at the other
end of the clutch cable in the direction of
the engine
MAINTENANCE.
