Icom IC-F410 Service Manual page 19

[FRONT UNIT]
REF ORDER
NO. NO.
C21 4030006900 S.CERAMIC
C22 4030007090 S.CERAMIC
C23 4030007090 S.CERAMIC
C24 4030007090 S.CERAMIC
C25 4030007090 S.CERAMIC
C26 4030007090 S.CERAMIC
C27 4030007090 S.CERAMIC
C28 4030006860 S.CERAMIC
C29 4030006860 S.CERAMIC
C30 4030006850 S.CERAMIC
C32 4030006860 S.CERAMIC
C33 4030006860 S.CERAMIC
C34 4030007090 S.CERAMIC
C35 4030006860 S.CERAMIC
C36 4030006900 S.CERAMIC
C37 4550006700 S.TANTALUM
C38 4030008880 S.CERAMIC
C39 4030011600 S.CERAMIC
C40 4030008920 S.CERAMIC
C41 4030008900 S.CERAMIC
C42 4030011600 S.CERAMIC
C43 4030006900 S.CERAMIC
C44 4030006900 S.CERAMIC
C45 4030006900 S.CERAMIC
C46 4030007090 S.CERAMIC
C47 4030007090 S.CERAMIC
C48 4030007090 S.CERAMIC
C49 4030007090 S.CERAMIC
C50 4030007090 S.CERAMIC
C52 4030007090 S.CERAMIC
C56 4030007090 S.CERAMIC
C57 4030007090 S.CERAMIC
C58 4030007090 S.CERAMIC
C59 4030007090 S.CERAMIC
C60 4030007090 S.CERAMIC
C61 4030007090 S.CERAMIC
C62 4030007090 S.CERAMIC
C63 4030007090 S.CERAMIC
C64 4030007090 S.CERAMIC
C65 4030007090 S.CERAMIC
C66 4030007090 S.CERAMIC
C67 4030006860 S.CERAMIC
C69 4030006860 S.CERAMIC
C70 4030007090 S.CERAMIC
C71 4030007090 S.CERAMIC
C73 4030007090 S.CERAMIC
C74 4030007090 S.CERAMIC
C77 4030007090 S.CERAMIC
C78 4030007090 S.CERAMIC
C79 4030007090 S.CERAMIC
C80 4030007090 S.CERAMIC
C82 4030011600 S.CERAMIC
C83 4030006860 S.CERAMIC
C84 4030006860 S.CERAMIC
C85 4030006860 S.CERAMIC
C86 4030006860 S.CERAMIC
C87 4030006860 S.CERAMIC
C88 4030006860 S.CERAMIC
C89 4030006860 S.CERAMIC
C90 4030006860 S.CERAMIC
C92 4030007090 S.CERAMIC
J1 6450001470 CONNECTOR
J2 6510020510 S.CONNECTOR
DS1 5030001540 LCD
DS2 5040002310 S.LED
DS3 5040002310 S.LED
DS4 5040002310 S.LED
DS5 5040002310 S.LED
DS6 5040002310 S.LED
DS7 5040002310 S.LED
DS8 5040002310 S.LED
DS9 5040002310 S.LED
DS10 5040002310 S.LED
DS11 5040002310 S.LED
DS12 5040001760 S.LED
DS13 5040002310 S.LED
DS14 5040002310 S.LED
DS15 5040002310 S.LED
DS16 5040002310 S.LED
DS17 5040002310 S.LED
C: LCD type (F410/F420), E: LED type (F410S/F420S)
DESCRIPTION
C1608 JB 1E 103K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
ECST1AY106R
C1608 JB 1C 223K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 473K-T-A
C1608 JB 1C 333K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A E only
C1608 JB 1H 102K-T-A E only
E
C1608 JB 1H 102K-T-A only
E
C1608 JB 1H 102K-T-A only
C1608 JB 1H 102K-T-A E only
C1608 JB 1H 102K-T-A E only
E
C1608 JB 1H 102K-T-A only
E
C1608 JB 1H 102K-T-A only
C1608 CH 1H 470J-T-A E only
95003-2881
FH12-40S-0.5SV
C
LD-HU10140J only
C
SML-311YTT86 only
SML-311YTT86 C only
SML-311YTT86 C only
C
SML-311YTT86 only
C
SML-311YTT86 only
SML-311YTT86 C only
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
E
SEC 2422C only
E
SML-311YTT86 only
E
SML-311YTT86 only
SML-311YTT86 E only
E
SML-311YTT86 only
E
SML-311YTT86 only
[FRONT UNIT]
REF ORDER
NO. NO.
W1 7030000010 S.JUMPER
W2 7030003860 S.JUMPER
W3 8900007680 CABLE
EP1 0910049322 PCB
0910051231 PCB
EP2 8930044930 LCD CONTACT
6 - 2
DESCRIPTION
MCR10EZHJ JPW (000)
ERJ3GE JPW V
OPC-741
C
B 5042B
E
B 5289A
C
SRCN-2055-SP-N-W only
S.=Surface mount
