Buell 2002 X1 Handbook

Buell 2002 X1 Handbook

Hide thumbs Also See for 2002 X1:

Service manual (462 pages)

,

Owner's manual (33 pages)

Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, Owner's Manual

Table Of Contents

SUBJECT

1.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Fluid Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Care of Molded-in-Color Body Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 Ceramic Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.5 Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.6 Engine Lubrication System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.7 Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.8 Brake Pads and Rotors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.9 Tires and Wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.10 Clutch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.11 Drive Belt Deflection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.12 Drive Belt and Sprocket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.13 Primary Chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.14 Preload Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.15 Suspension Damping Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.16 Front Fork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.17 Steering Head Bearings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.18 Spark Plugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.19 Air Cleaner Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.20 Throttle Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.21 Ignition Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.22 Handlebars . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.23 Headlamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.24 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.25 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

MAINTENANCE

PAGE NO.

1-1

1-5

1-11

1-12

1-13

1-15

1-17

1-20

1-21

1-22

1-24

1-26

1-28

1-29

1-30

1-31

1-32

1-34

1-35

1-36

1-37

1-39

1-40

1-41

1-42

1

Table of Contents

Advertisement

Chapters

Table of Contents

Troubleshooting

Need help?

Need help?

Do you have a question about the 2002 X1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Buell 2002 X1

Page 1 MAINTENANCE Table Of Contents SUBJECT PAGE NO. 1.1 General ............1.2 Fluid Requirements .
Page 3: General
(800 km), and at every 2500 mile (4000 km) interval thereaf- whenever necessary. Do not lift heavy parts by hand. A hoist ter, have a Buell dealer perform the service operations listed and adjustable lifting beam or sling are needed to remove Table 1-2.
Page 4: Repair And Replacement Procedures
Always use the proper tools and ﬁxtures for removing and installing bearings. Part Replacement Bearings do not usually need to be removed. Only remove bearings if necessary. Always replace worn or damaged parts with new parts. 2002 Buell X1: Maintenance...
Page 5: Part Protection
If possible, always pull on a wrench handle and adjust your stance to prevent a fall if something lets go. Don’t use a screwdriver with rounded edges because it Never cock a wrench. will slip – redress with a ﬁle. 2002 Buell X1: Maintenance...
Page 6: Ratchets And Handles
Never cock any wrench or socket. Select only impact sockets for use with air or electric impact wrenches. Replace sockets showing cracks or wear. Keep sockets clean. Always use approved eye protection when using power or impact sockets. 2002 Buell X1: Maintenance...
Page 7: Fluid Requirements
= 1,000 milliliters (mL). Should you need to convert from U.S. descending order, are 20W-50, 15W-40 and 10W-40. At the units-of-measure to metric units-of-measure (or vice versa), ﬁrst opportunity, see a Buell dealer to change back to 100 refer to the following: percent Harley-Davidson oil.
Page 8 2002 Buell X1: Maintenance...
Page 9 2002 Buell X1: Maintenance...
Page 10 2002 Buell X1: Maintenance...
Page 11 2002 Buell X1: Maintenance...
Page 12 HOME NOTES 1-10 2002 Buell X1: Maintenance...
Page 13: Care Of Molded-In-Color Body Panels
NOTE maintenance instructions required for the molded-in-color Rain or water will remove Harley Gloss from body panels. body panels that are standard on your 2002 Buell Lightning Reapply Harley Gloss as described above to keep surfaces X1 motorcycle. looking their best.
Page 14: Ceramic Header
CARE AND MAINTENANCE The purpose of this section is to provide special care Washing instructions required for the blue ceramic header on the Buell Lightning X1 motorcycle. To wash blue ceramic header, follow the instructions below: Rinse surface with water.
Page 15 12.6 Clean cable connectors and battery terminals using a 12.3 wire brush or sandpaper. Remove any oxidation. 12.0 Inspect the battery screws, clamps and cables for break- 11.8 age, loose connections and corrosion. Clean clamps. 2002 Buell X1: Maintenance 1-13...
Page 16 Install battery strap locknut on threaded shaft. Tighten to 40 in-lbs (4.5 Nm). Apply light coat of petroleum jelly or corrosion-retardant material to both battery terminals. Secure oxygen sensor connector with new cable straps. Install seat. See 2.40 SEAT. 1-14 2002 Buell X1: Maintenance...
Page 17: Engine Lubrication System
WEATHER 20W-50, 15W-40 and 10W-40. At the ﬁrst opportu- HARLEY-DAVIDSON VISCOSITY DAVIDSON AMBIENT STARTS TYPE nity, see a Buell dealer to change back to 100 per- RATING TEMP °F BELOW cent Harley-Davidson oil. 50° F ° H.D. Multi-Grade Below 40 Install ﬁller cap/dipstick.
Page 18 1000 RPM or above. 14. Check for oil leaks at oil ﬁlter and drain hose. 15. Check oil level. See CHECKING ENGINE OIL LEVEL. 1-16 2002 Buell X1: Maintenance...
Page 19: Brakes
Get medical attention for eyes. KEEP BRAKE Stand motorcycle upright. FLUID OUT OF THE REACH OF CHILDREN. Failure to comply could result in death or serious injury. Front brake caliper bleeder valve-Figure 1-8. 2002 Buell X1: Maintenance 1-17...
Page 20 Attach covers to master cylinder reservoirs. Tighten screws on front master cylinder reservoir to 9-13 in-lbs (1.0-1.5 Nm). Tighten cap on rear master cylinder reservoir securely. Remove cover from molded-in-color surfaces and right handlebar switches. 1-18 2002 Buell X1: Maintenance...
Page 21: Rear Brake Pedal
Always test motorcycle brakes at low speed after servic- ing or bleeding system. To prevent death or serious injury, Buell recommends that all brake repairs be per- formed by a Buell dealer or other qualiﬁed mechanic. Check rear brake pedal height.
Page 22: Brake Pads And Rotors
The brake rotor must be within the following speciﬁca- tions. If the brake rotor is suspected of being damaged, inspect rotor using the following measurements: Lateral Movement: 0.5 mm Radial Movement: 0.45 mm Rotational Movement: 0.39 mm 1-20 2002 Buell X1: Maintenance...
Page 23: Tires And Wheels
At every 10,000 mile (16,000 km) service interval. When storing or removing the motorcycle for the season. Check wheel bearings and axle spacers for wear and corro- sion. Excessive play or roughness indicates worn bearings. Replace bearings in sets only. 2002 Buell X1: Maintenance 1-21...
Page 24: Clutch
TORX screws with washers. Tighten in a crosswise pattern to 7-9 ft-lbs (10-12 Nm). Clutch Adjusting Screw Quad Ring Install mufﬂer. See 2.28 EXHAUST SYSTEM. Clutch Diaphragm Spring Fluid Level Figure 1-17. Fluid Level 1-22 2002 Buell X1: Maintenance...
Page 25 Install clutch inspection cover (2) using four TORX screws with washers (1). Tighten in a cross- wise pattern to 7-9 ft-lbs (10-12 Nm). Figure 1-20. Adjusting Clutch Free Play Check clutch cable free play. See Step 6 above. 2002 Buell X1: Maintenance 1-23...
Page 26: Drive Belt Deflection
Figure 1-22. Rear Axle Adjuster If belt requires adjustment, see Deﬂection Adjust- ment under 1.11 DRIVE BELT DEFLECTION. After adjusting deﬂection, check axle alignment. Install drive support arm, sprocket cover and chin fairing. 2.30 SPROCKET COVER. 1-24 2002 Buell X1: Maintenance...
Page 27 Tighten locknut (2) ﬂush against adjust- ing nut (3). Tighten axle nut (metric) to 66-73 ft-lbs (90-99 Nm). Axle Adjuster Bolt Verify that belt deﬂection is correct. Locknut Adjusting Nut Figure 1-24. Axle Adjuster Bolt, Right Side Shown 2002 Buell X1: Maintenance 1-25...
Page 28: Drive Belt And Sprocket
This condition will result in belt failure and indicates worn transmission sprocket teeth. Replace belt and transmis- sion sprocket. Signs of puncture or cracking at the base of the belt teeth. Replace belt if either condition exists. 1-26 2002 Buell X1: Maintenance...
Page 29 OK to run, but monitor condition Fuzzy edge cord OK to run, but monitor condition Hook wear Replace belt Stone damage Replace belt if damage is on the edge Bevel wear (outboard edge only) OK to run, but monitor condition 2002 Buell X1: Maintenance 1-27...
Page 30: Primary Chain
Loosen locknut (1). Turn adjusting screw (2): Clockwise (inward) to reduce free play. Adjusting Screw Counterclockwise (outward) to increase free play. Tighten locknut (1) to 20-25 ft-lbs (27-34 Nm). Figure 1-28. Measuring Primary Chain Adjustment 1-28 2002 Buell X1: Maintenance...
Page 31: Preload Adjustment
90 degrees to the torque wrench. Wipe excess grease off of shock absorber. NOTE When preload is increased, both compression and rebound damping should be increased. If preload is decreased, both compression and rebound damping should be decreased. 2002 Buell X1: Maintenance 1-29...
Page 32: Suspension Damping Adjustments
Recommended Damping Settings (X1) Rebound Adjuster SOLO SOLO SOLO Slotted Dial SETTINGS 2 UP (STD) (FIRM) (SOFT) Figure 1-33. Rear Shock Compression and Rebound Front Rebound Damping Adjustments Front 1.25 Compression Rear Rebound Rear 2.25 0.25 0.75 Compression 1-30 2002 Buell X1: Maintenance...
Page 33: Front Fork
Left and right forks must contain equal amounts of fork oil. Standard Oil Level 3.15 in. 80 mm Assemble and install forks. See 2.16 FRONT FORK. Maximum Oil Level 4.333 in. 110 mm Minimum Oil Level 2.36 in. 60 mm 2002 Buell X1: Maintenance 1-31...
Page 34: Steering Head Bearings
(16,000 km) thereafter, lubricate the steering head bearings with WHEEL BEARING GREASE (Part No. 99855-89). 4.5-6.5 lbs 2.17 FORK STEM AND BRACKET ASSEMBLY for lubri- (2.0-2.9 kg) cation procedure. b0745a1x Figure 1-38. Checking Steering Head Bearings 1-32 2002 Buell X1: Maintenance...
Page 35 Fork Stem Bolt Upper Triple Clamp Dust Shield (2) Roller Bearing (2) Bearing Cup (2) Lower Triple Clamp Lower Triple Clamp Pinch Screws (2) Screw Upper Triple Clamp Pinch Screws (2) Figure 1-39. Steering Head Assembly 2002 Buell X1: Maintenance 1-33...
Page 36: Spark Plugs
If the plugs cannot be cleaned, replace with No. 10R12 connected to coil and spark plugs. spark plugs. 10. Install left side air scoop. See 2.36 AIR SCOOP. Check electrode gap with a wire-type feeler gauge. Gap should be 0.038-0.043 in. (0.97-1.09 mm). 1-34 2002 Buell X1: Maintenance...
Page 37: Air Cleaner Filter
(3). Make sure air ﬁlter and trim are correctly posi- tioned. Install long screw and nylon washer (2). Tighten to 27-29 in-lbs (3.1-3.3 Nm). Install two screws and nylon washers (1) to secure air cleaner cover. Tighten to 27-29 in-lbs (3.1-3.3 Nm). 2002 Buell X1: Maintenance 1-35...
Page 38: Throttle Cables
Recheck engine slow idle speed; adjust if required. Regular idle speed is 850-1050 RPM. Set idle speed using 11. Install air cleaner assembly. See 4.42 AIR CLEANER. idle adjustment screw (4) shown in Figure 1-45. 1-36 2002 Buell X1: Maintenance...
Page 39: Ignition Timing
Attach female gray connector on BREAKOUT BOX (Part No. HD-42682) to electronic control module. Attach male gray connector on BREAKOUT BOX to wiring harness. Connect red (+) lead on voltmeter to Pin 3 on gray side of BREAKOUT BOX. 2002 Buell X1: Maintenance 1-37...
Page 40 If seat is loose, it could shift during vehicle operation and startle the rider, causing loss of control which could result in death or serious injury. 10. Install seat. See 2.40 SEAT. 1-38 2002 Buell X1: Maintenance...
Page 41: Handlebars
Attach windscreen with four screws and rubber washers. Check steering motion range to both fork stops. Handle- bars should not make contact with the front forks or fuel tank cover. If handlebar needs further adjustment, repeat adjustment beginning with Step 1. 2002 Buell X1: Maintenance 1-39...
Page 42 Tilt headlamp up or down to aim it in relation to the horizontal line. At the same time, turn headlamp right or left to direct light beam straight ahead. Tighten both adjuster screws (metric) to 5-7 ft-lbs (7-10 Nm). 1-40 2002 Buell X1: Maintenance...
Page 43: Electrical System
Shifter pawl improperly adjusted. Smokes Excessively Shifter engaging parts (inside transmission) badly worn Piston rings badly worn or broken. and rounded. Valve stem seals worn or damaged. Shifter forks bent. Valve guides worn. Damaged gears. 2002 Buell X1: Maintenance 1-43...
Page 44: Storage
REMOVAL FROM STORAGE varnish in the fuel system. This work should be performed by your local Buell dealer fol- lowing Service Manual procedures. WARNING WARNING Fill fuel tank and add a gasoline stabilizer.
Page 45: Troubleshooting
20. TPS/fast idle screw not set properly. See dealer. 20. Inoperative fuel injector. See dealer. 21. No output from CMP sensor. See dealer. 21. Obstructed fuel tank vent valve or pinched vent tube. 22. Inoperative fuel pump. See dealer. See dealer. 1-42 2002 Buell X1: Maintenance...
Page 46 Brake pads badly worn to minimum lining thickness. Brake rotor badly worn or warped. Brake pads dragging or excessive braking (brake fades due to heat buildup). Insufﬁcient brake pedal or hand lever free play (brake drags). 1-44 2002 Buell X1: Maintenance...
Page 47: Table Of Contents
Table Of Contents CHASSIS SUBJECT PAGE NO. 2.1 Specifications ..........2.2 Tire Specifications .
