PRIVACY
You can hide some parts of the screen for privacy masking.
A total of 8 different privacy masking zones are available.
MASK 1 ~ MASK 8
Select ON or OFF for each mask (MASK 1 through 8).
OFF / ON
If ON is selected you can set the area to be masked and the shape
and color of the mask.
*START POINT: Select the START POINT to adjust the size of the
*privacy zone.
*L_TOP (Left Top)
*R_TOP (Right Top)
*L_BOT (Left Bottom)
*R_BOT (Right Bottom)
*MODIFY: After selecting the START POINT, you can modify the
*size of the privacy zone by moving the joystick left or right.
*POSITION: You can move the privacy zone by moving the joystick
*left or right.
*COLOR SET:
*Privacy zones can be set with eight different colors-GRAY,
*BLACK, WHITE, RED, GREEN, BLUE, MAGENTA, and CYAN.
