VTech S1310 User Manual

VTech S1310 User Manual

Sip cordless series
Hide thumbs Also See for S1310:
Table of Contents

Advertisement

Quick Links

S I P C o r d l e s s S e r i e s
Master User Guide
Models:
SIP classic trimstyle 1-line hotel telephone - S1310,
SIP classic trimstyle 2-line hotel telephone - S1320,
SIP classic cordless 1-line hotel telephone - S1410,
SIP classic cordless 2-line hotel telephone - S1420,
SIP classic charging base - C3300,
SIP classic cordless 1-line accessory handset - C3400,
SIP classic cordless 2-line accessory handset - C3500,
SIP contemporary trimstyle 1-line hotel telephone - S2310/S2310-6VDC,
SIP contemporary trimstyle 2-line hotel telephone - S2320/S2320-6VDC,
SIP contemporary cordless 1-line hotel telephone - S2410/CTM-S2411,
SIP contemporary cordless 2-line hotel telephone - S2420/CTM-S2421,
SIP contemporary charging base - C4300,
SIP contemporary charging stand - C4310,
SIP contemporary cordless 1-line accessory handset - C4400/CTM-C4401,
SIP contemporary cordless 2-line accessory handset - C4500/CTM-C4501,
SIP contemporary cordless 1-line accessory Petite
SIP contemporary cordless 2-line accessory Petite
SIP contemporary cordless 1-line accessory handset and charger bundle - CTM-S241HS,
SIP contemporary cordless 2-line accessory handset and charger bundle - CTM-S242HS,
SIP contemporary cordless 1-line accessory handset with speed dials and
charger bundle - CTM-S241SD, and
SIP contemporary cordless 2-line accessory handset with speed dials and
charger bundle - CTM-S242SD
BC
- CTM-S241P,
TM
- CTM-S242P,
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S1310 and is the answer not in the manual?

Questions and answers

Related Manuals for VTech S1310

Summary of Contents for VTech S1310

  • Page 1 S I P C o r d l e s s S e r i e s Master User Guide Models: SIP classic trimstyle 1-line hotel telephone - S1310, SIP classic trimstyle 2-line hotel telephone - S1320, SIP classic cordless 1-line hotel telephone - S1410,...

  • Page 2: Important Safety Instructions

    Important safety instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: This product should be installed by a qualified technician. This product should only be connected to the host equipment and never directly to the network such as Public Switch Telephone Network (PSTN) or Plain Old Telephone Services (POTS).

  • Page 3: Table Of Contents

    Table of contents Parts checklist ..........................1 Telephone layout ..........................4 SIP classic trimstyle 1-line - S1310 ....................4 SIP classic trimstyle 2-line - S1320 ....................5 SIP classic cordless 1-line - S1410 ....................6 SIP classic cordless 2-line - S1420 ....................7 SIP classic charging base - C3300 ....................8 SIP classic cordless 1-line accessory handset - C3400 ..............9...
  • Page 4 Precautions for users of implanted cardiac pacemakers ..............81 Operating range..........................81 About cordless telephones ......................81 The RBRC ® seal ...........................81 VTech Hospitality limited warranty program ................82 FCC, ACTA and IC regulations ....................83 Energy-saving charging mode .....................84 Maintenance ..........................84 Technical specifications .......................85 Index ............................89...

  • Page 5: Parts Checklist

    Parts checklist Items contained in the respective telephone package: Model name Model number Parts included SIP classic S1310 trimstyle 1-line Mounting bracket Telephone base Corded handset with a screw Cat-5 network cables (2) SIP classic S1320 trimstyle 2-line Mounting bracket...
  • Page 6 Parts checklist Items contained in the respective telephone package: Model name Model number Parts included SIP contemporary S2320 trimstyle 2-line Mounting bracket Telephone base Corded handset Cat-5 network cables (2) with a screw SIP contemporary S2320-6VDC trimstyle 2-line Telephone base Mounting bracket Corded handset with a screw...
  • Page 7 Parts checklist Items contained in the respective telephone package: Model name Model number Parts included SIP contemporary C4300 charging base Mounting bracket Charging base with a screw Cat-5 network cable SIP contemporary C4310 charging stand Charging stand Cat-5 network cable SIP contemporary C4400 cordless 1-line...

  • Page 8: Telephone Layout

    Telephone layout SIP classic trimstyle 1-line - S1310 +/VOLUME/- MESSAGE WAITING LED TALK HOLD REDIAL FLASH /SPEAKER MUTE Wall mount clip POWER LED...

  • Page 9: Sip Classic Trimstyle 2-Line - S1320

    Telephone layout SIP classic trimstyle 2-line - S1320 +/VOLUME/- MESSAGE WAITING LED LINE 2 LINE 1 HOLD CONF FLASH MUTE /SPEAKER REDIAL Wall mount clip POWER LED...

  • Page 10: Sip Classic Cordless 1-Line - S1410

    Telephone layout SIP classic cordless 1-line - S1410 RJ-45 LAN port MESSAGE WAITING LED RJ-45 COMPUTER port /USB CHARGE ONLY (USB port for charging only) Wall mount clip Speed Dial keys REDIAL FLASH /FIND HANDSET MUTE +/- VOLUME /SPEAKER LINE HOLD CHARGE LED +/VOLUME/-...

  • Page 11: Sip Classic Cordless 2-Line - S1420

    Telephone layout SIP classic cordless 2-line - S1420 RJ-45 LAN port MESSAGE WAITING LED RJ-45 COMPUTER port /USB CHARGE ONLY (USB port for charging only) Wall mount clip Speed Dial keys REDIAL FLASH /FIND HANDSET MUTE +/- VOLUME /SPEAKER HOLD CONF CHARGE LED LINE 1 LINE 2...

  • Page 12: Sip Classic Charging Base - C3300

    Telephone layout SIP classic charging base - C3300 Wall mount clip CHARGE LED...

  • Page 13: Sip Classic Cordless 1-Line Accessory Handset - C3400

    Telephone layout SIP classic cordless 1-line accessory handset - C3400 +/VOLUME/- MESSAGE WAITING LED TALK HOLD REDIAL FLASH MUTE /SPEAKER LOW BATTERY LED...

  • Page 14: Sip Classic Cordless 2-Line Accessory Handset - C3500

    Telephone layout SIP classic cordless 2-line accessory handset - C3500 +/VOLUME/- MESSAGE WAITING LED LINE 2 LINE 1 HOLD CONF FLASH MUTE /SPEAKER REDIAL LOW BATTERY LED...

  • Page 15: Sip Contemporary Trimstyle 1-Line - S2310/S2310-6Vdc

    Telephone layout SIP contemporary trimstyle 1-line - S2310/S2310-6VDC -/VOLUME/+ MESSAGE WAITING LED TALK HOLD REDIAL FLASH /SPEAKER MUTE INTERCOM Wall mount clip POWER LED...

  • Page 16: Sip Contemporary Trimstyle 2-Line - S2320/S2320-6Vdc

    Telephone layout SIP contemporary trimstyle 2-line - S2320/S2320-6VDC -/VOLUME/+ MESSAGE WAITING LED LINE 2 LINE 1 HOLD CONF FLASH /SPEAKER MUTE REDIAL INTERCOM Wall mount clip POWER LED...

  • Page 17: Sip Contemporary Cordless 1-Line - S2410

    Telephone layout SIP contemporary cordless 1-line - S2410 RJ-45 LAN port MESSAGE WAITING LED RJ-45 COMPUTER port /USB CHARGE ONLY (USB port for charging only) Wall mount clip Speed Dial keys Slide switch (inside) (for energy-saving charging mode) REDIAL FLASH /FIND HANDSET MUTE +/VOLUME...

  • Page 18: Sip Contemporary Cordless 1-Line - Ctm-S2411

    Telephone layout SIP contemporary cordless 1-line - CTM-S2411 RJ-45 LAN port MESSAGE WAITING LED RJ-45 COMPUTER port /USB CHARGE ONLY (USB port for charging only) Wall mount clip Speed Dial keys Slide switch (inside) (for energy-saving charging mode) Speed Dial key REDIAL FLASH /FIND HANDSET...

  • Page 19: Sip Contemporary Cordless 1-Line Accessory Petite - Ctm-S241P

    Telephone layout contemporary cordless 1-line accessory Petite - CTM-S241P MESSAGE WAITING LED Switch hook Wall mount clip Speed Dial keys /USB CHARGE ONLY (USB port for charging only) FLASH +/VOLUME -/VOLUME MUTE RINGER VOL IN USE light HOLD Speed Dial key...

  • Page 20: Sip Contemporary Cordless 2-Line - S2420

    Telephone layout SIP contemporary cordless 2-line - S2420 RJ-45 LAN port MESSAGE WAITING LED RJ-45 COMPUTER port /USB CHARGE ONLY (USB port for charging only) Wall mount clip Speed Dial keys Slide switch (inside) (for energy-saving charging mode) REDIAL FLASH /FIND HANDSET MUTE +/VOLUME...

  • Page 21: Sip Contemporary Cordless 2-Line - Ctm-S2421

    Telephone layout SIP contemporary cordless 2-line - CTM-S2421 RJ-45 LAN port MESSAGE WAITING LED RJ-45 COMPUTER port /USB CHARGE ONLY (USB port for charging only) Wall mount clip Speed Dial keys Slide switch (inside) (for energy-saving charging mode) Speed Dial key REDIAL FLASH /FIND HANDSET...

  • Page 22: Sip Contemporary Cordless 2-Line Accessory Petite - Ctm-S242P

    Telephone layout SIP contemporary cordless 2-line accessory Petite - CTM-S242P MESSAGE WAITING LED Switch hook Wall mount clip Speed Dial keys /USB CHARGE ONLY (USB port for charging only) FLASH +/VOLUME Speed Dial key -/VOLUME MUTE RINGER VOL LINE 1 HOLD LINE 2 CONF...

  • Page 23: Sip Contemporary Charging Base - C4300

    Telephone layout SIP contemporary charging base - C4300 Wall mount clip Slide switch (for energy-saving charging mode) CHARGE LED NOTE: Keep the slide switch on the left side to maintain normal telephone operation.

  • Page 24: Sip Contemporary Charging Stand - C4310

    Telephone layout SIP contemporary charging stand - C4310 Slide switch (for energy-saving charging mode) CHARGE LED NOTE: Keep the slide switch on the left side to maintain normal telephone operation.

  • Page 25: Sip Contemporary Cordless 1-Line Accessory Handset - C4400

    Telephone layout SIP contemporary cordless 1-line accessory handset - C4400 -/VOLUME/+ MESSAGE WAITING LED TALK HOLD REDIAL FLASH /SPEAKER MUTE INTERCOM LOW BATTERY LED...

  • Page 26: Sip Contemporary Cordless 1-Line Accessory Handset - Ctm-C4401

    Telephone layout SIP contemporary cordless 1-line accessory handset - CTM-C4401 -/VOLUME/+ MESSAGE WAITING LED TALK HOLD FLASH REDIAL /SPEAKER MUTE MESSAGES Speed Dial keys LOW BATTERY LED...

  • Page 27: Sip Contemporary Cordless 2-Line Accessory Handset - C4500

    Telephone layout SIP contemporary cordless 2-line accessory handset - C4500 -/VOLUME/+ MESSAGE WAITING LED LINE 2 LINE 1 HOLD CONF FLASH /SPEAKER MUTE REDIAL INTERCOM LOW BATTERY LED...

  • Page 28: Sip Contemporary Cordless 2-Line Accessory Handset - Ctm-C4501

    Telephone layout SIP contemporary cordless 2-line accessory handset - CTM-C4501 -/VOLUME/+ MESSAGE WAITING LED LINE 2 CONF LINE 1 FLASH HOLD REDIAL /SPEAKER MUTE MESSAGES Speed Dial keys LOW BATTERY LED...

  • Page 29: Sip Contemporary Cordless 1-Line Accessory Handset And Charger Bundle - Ctm-S241Hs

    Telephone layout SIP contemporary cordless 1-line accessory handset and charger bundle - CTM-S241HS -/VOLUME/+ MESSAGE WAITING LED TALK HOLD REDIAL FLASH /SPEAKER MUTE INTERCOM LOW BATTERY LED CHARGE LED...

  • Page 30: Sip Contemporary Cordless 2-Line Accessory Handset And Charger Bundle - Ctm-S242Hs

    Telephone layout SIP contemporary cordless 2-line accessory handset and charger bundle - CTM-S242HS -/VOLUME/+ MESSAGE WAITING LED LINE 2 LINE 1 HOLD CONF FLASH /SPEAKER MUTE REDIAL INTERCOM LOW BATTERY LED CHARGE LED...

  • Page 31: Sip Contemporary Cordless 1-Line Accessory Handset With Speed Dials And Charger Bundle - Ctm-S241Sd

    Telephone layout SIP contemporary cordless 1-line accessory handset with speed dials and charger bundle - CTM-S241SD -/VOLUME/+ MESSAGE WAITING LED TALK HOLD FLASH REDIAL /SPEAKER MUTE MESSAGES Speed Dial keys LOW BATTERY LED CHARGE LED...

  • Page 32: Sip Contemporary Cordless 2-Line Accessory Handset With Speed Dials And Charger Bundle - Ctm-S242Sd

    Telephone layout SIP contemporary cordless 2-line accessory handset with speed dials and charger bundle - CTM-S242SD -/VOLUME/+ MESSAGE WAITING LED LINE 2 CONF LINE 1 FLASH HOLD REDIAL /SPEAKER MUTE MESSAGES Speed Dial keys LOW BATTERY LED CHARGE LED...

  • Page 33: Installation

    Installation SIP classic trimstyle 1-line/2-line - S1310/S1320 Telephone base installation The telephone base can be adapted to desktop use or mount on a standard telephone wall plate. Installation option - desktop position Turn the telephone base over with the bottom side facing up. Connect the Cat-5 network cable into the RJ-45 LAN port on the telephone base and route through the channel as shown below.
  • Page 34 Installation SIP classic trimstyle 1-line/2-line - S1310/S1320 Installation option - converting from desktop to wall mount position Unplug the Cat-5 network cable from the network wall jack. Put the handset aside. On the telephone base, place a coin in the slit of the wall mount clip and rotate a half turn (180 degrees).

  • Page 35: Handset Registration

    SIP classic trimstyle 1-line/2-line - S1310/S1320 Handset registration An S1310/S1320 handset must be registered to an S1410/S1420 telephone base before use. To register an S1310 handset: Place the corded handset on the S1410 telephone base cradle. Handset registration happens automatically the first time a handset is placed on the S1410.

  • Page 36: Sip Classic Cordless 1-Line/2-Line - S1410/S1420

    Installation SIP classic cordless 1-line/2-line - S1410/S1420 Telephone base installation The telephone comes ready for desktop use. Install the telephone base as shown below. Network wall jack with Power over Ethernet(PoE) Cat-5 network cable RJ-45 LAN port Once installed, the telephone begins a four-step initialization and system registration process. •...

  • Page 37: Handset Battery Installation

    Installation SIP classic cordless 1-line/2-line - S1410/S1420 Handset battery installation Install the battery as shown below. Gently lift the handset cover. Do not detach the speaker wires between the handset cover and the handset. Plug the battery connector securely into the socket inside the handset battery compartment. Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment.
  • Page 38 Installation SIP classic cordless 1-line/2-line - S1410/S1420 Installation option - converting from desktop to wall mount position This telephone can be adapted to desktop use or mount on a standard telephone wall plate. To mount the telephone base on the wall: Unplug the Cat-5 network cable from the network wall jack.

  • Page 39: Sip Classic Charging Base - C3300

    Installation SIP classic charging base - C3300 Charging base installation The charging base can be adapted to desktop use or mount on a standard telephone wall plate. Installation option - desktop position Turn the charging base over with the bottom side facing up. Connect the Cat-5 network cable into the RJ-45 LAN port on the charging base.

  • Page 40: Sip Classic Cordless 1-Line/2-Line Accessory Handset - C3400/C3500

    Installation SIP classic cordless 1-line/2-line accessory handset - C3400/C3500 Handset battery installation Install the battery as shown below. Gently lift the handset cover. Do not detach the speaker wires between the handset cover and the handset. Plug the battery connector securely into the socket inside the handset battery compartment. Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment.

  • Page 41: Sip Contemporary Trimstyle 1-Line/2-Line - S2310/S2320

    Installation SIP contemporary trimstyle 1-line/2-line - S2310/S2320 Telephone base installation The telephone can be adapted to desktop use or mount on a standard telephone wall plate. Installation option - desktop position Turn the telephone base over with the bottom side facing up. Connect the Cat-5 network cable into the RJ-45 LAN port on the telephone base and route the cord out from the top eyelet on the mounting bracket, then position the mounting bracket as shown.
  • Page 42 Installation SIP contemporary trimstyle 1-line/2-line - S2310/S2320 Installation option - converting from desktop to wall mount position Unplug the Cat-5 network cable from the network wall jack. Put the corded handset aside. On the telephone base, place a coin in the slit of the wall mount clip and rotate a half turn (180 degrees).

  • Page 43: Sip Contemporary Trimstyle 1-Line/2-Line - S2310-6Vdc/S2320-6Vdc

    Installation SIP contemporary trimstyle 1-line/2-line - S2310-6VDC/S2320-6VDC Telephone base installation The telephone can be adapted to desktop use or mount on a standard telephone wall plate. Installation option - desktop position Turn the telephone base over with the bottom side facing up. Route the small end of the power adapter cord out from the top eyelet on the mounting bracket.
  • Page 44 Installation SIP contemporary trimstyle 1-line/2-line - S2310-6VDC/S2320-6VDC Installation option - converting from desktop to wall mount position Unplug the power adapter from the electrical outlet. Put the corded handset aside. On its telephone base, place a coin in the slit of the wall mount clip and rotate a half turn (180 degrees).

  • Page 45: Sip Contemporary Trimstyle 1-Line/2-Line - S2310/S2310-6Vdc/S2320/S2320-6Vdc

    Installation SIP contemporary trimstyle 1-line/2-line - S2310/S2310-6VDC/S2320/S2320-6VDC Handset registration An S2310/S2310-6VDC handset must be registered to an S2410/CTM-S2411 telephone base before use. An S2320/S2320-6VDC handset must be registered to an S2420/CTM-S2421 telephone base before use. To register an S2310/S2310-6VDC handset: Place the corded handset on the S2410/CTM-S2411 telephone base cradle.

  • Page 46: Sip Contemporary Cordless 1-Line/2-Line - S2410/Ctm-S2411/S2420/Ctm-S2421

    Installation SIP contemporary cordless 1-line/2-line - S2410/CTM-S2411/S2420/CTM-S2421 Telephone base installation This telephone can be adapted to desktop use or mount on a standard telephone wall plate. Installation option - desktop position Turn the telephone base over with the bottom side facing up. Insert the lower tabs of the mounting bracket into the lower grooves of the telephone base.
  • Page 47 Installation SIP contemporary cordless 1-line/2-line - S2410/CTM-S2411/S2420/CTM-S2421 Installation option - converting from desktop to wall mount position To mount the telephone base on the wall: Unplug the Cat-5 network cable from the network wall jack. Remove the cordless handset from the telephone base if it is cradled in the telephone base. On the telephone base, place a coin in the slit of the wall mount clip and rotate a half turn (180 degrees).

  • Page 48: Sip Contemporary Cordless 1-Line/2-Line - S2410/S2420

    Installation SIP contemporary cordless 1-line/2-line - S2410/S2420 Handset battery installation Install the battery as shown below. Gently lift the handset cover. Do not detach the speaker wires between the handset cover and the handset. Plug the battery connector securely into the socket inside the handset battery compartment. Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment.
  • Page 49 Installation SIP contemporary cordless 1-line/2-line - S2410/S2420 Handset registration Place the cordless handset on the telephone base cradle. Handset registration happens automatically the first time a cordless handset is placed on the telephone base. When the registration process completes, the MESSAGE WAITING LED flashes once and you hear 3 rising beeps as confirmation.

  • Page 50: Sip Contemporary Cordless 1-Line/2-Line - Ctm-S2411/Ctm-S2421

    Installation SIP contemporary cordless 1-line/2-line - CTM-S2411/CTM-S2421 Handset battery installation Install the battery as shown below. Plug the battery connector securely into the socket inside the handset battery compartment. Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment. To replace the handset cover, align all the tabs on the handset cover against the corresponding grooves on the handset, then firmly push downward until all the tabs lock in the grooves.
  • Page 51 Installation SIP contemporary cordless 1-line/2-line - CTM-S2411/CTM-S2421 Handset registration Place the cordless handset on the telephone base cradle. Handset registration happens automatically the first time a cordless handset is placed on the telephone base. When the registration process completes, the MESSAGE WAITING LED flashes once and you hear 3 rising beeps as confirmation.

  • Page 52: Sip Contemporary Cordless 1-Line/2-Line Accessory Petite - Ctm-S241P/Ctm-S242P

    Installation SIP contemporary cordless 1-line/2-line accessory Petite - CTM-S241P/CTM-S242P Accessory Petite installation The telephone can be adapted to desktop use or mounted on a standard telephone wall plate. Installation option - desktop position Turn the accessory Petite over with the bottom side facing up. Connect the small end of the power adapter cord to the accessory Petite.
  • Page 53 Installation SIP contemporary cordless 1-line/2-line accessory Petite - CTM-S241P/CTM-S242P Installation option - converting from desktop to wall mount position To mount the accessory Petite on the wall: Set aside the handset. On the accessory Petite cradle, place a coin in the slit of the wall mount clip and rotate a half turn (180 degrees).
  • Page 54 Installation SIP contemporary cordless 1-line/2-line accessory Petite - CTM-S241P/CTM-S242P Accessory Petite registration A CTM-S241P accessory Petite must be registered to a S2410/CTM-S2411 telephone base before use. A CTM-S242P accessory Petite must be registered to a S2420/CTM-S2421 telephone base before use. To register a CTM-S241P accessory Petite: Place the SIP cordless 1-line accessory Petite CTM-S241P on the S2410/CTM-S2411 telephone base cradle.

  • Page 55: Sip Contemporary Charging Base - C4300

    Installation SIP contemporary charging base - C4300 Charging base installation The charging base can be adapted to desktop use or mount on a standard telephone wall plate. Installation option - desktop position Turn the charging base over with the bottom side facing up. Connect the Cat-5 network cable into the RJ-45 LAN port on the charging base and route the cord out from the top eyelet on the mounting bracket, then position the mounting bracket as shown.

  • Page 56: Sip Contemporary Charging Stand - C4310

    Installation SIP contemporary charging stand - C4310 Charging stand installation The charging stand is designed for desktop use only. Install the charging stand as shown below. Network wall jack with Power over Ethernet (PoE) Cat-5 network cable...

  • Page 57: Sip Contemporary Cordless 1-Line/2-Line Accessory Handset - C4400/C4500/Ctm-S241Hs/Ctm-S242Hs

    Installation SIP contemporary cordless 1-line/2-line accessory handset - C4400/C4500/ CTM-S241HS/CTM-S242HS Handset battery installation Install the battery as shown below. Gently lift the handset cover. Do not detach the speaker wires between the handset cover and the handset. Plug the battery connector securely into the socket inside the handset battery compartment. Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment.
  • Page 58 Installation SIP contemporary cordless 1-line/2-line accessory handset - C4400/C4500/ CTM-S241HS/CTM-S242HS Handset registration Place the cordless handset on the telephone base cradle. Handset registration happens automatically the first time a cordless handset is placed on the telephone base. When the registration process completes, the MESSAGE WAITING LED flashes once and you hear 3 rising beeps as confirmation.

  • Page 59: Sip Contemporary Cordless 1-Line/2-Line Accessory Handset - Ctm-C4401/Ctm-C4501/Ctm-S241Sd/Ctm-S242Sd

    Installation SIP contemporary cordless 1-line/2-line accessory handset - CTM-C4401/CTM-C4501/ CTM-S241SD/CTM-S242SD Handset battery installation Install the battery as shown below. Plug the battery connector securely into the socket inside the handset battery compartment. Place the battery with the label THIS SIDE UP facing up and the wires inside the battery compartment. To replace the handset cover, align all the tabs on the handset cover against the corresponding grooves on the handset, then firmly push downward until all the tabs lock in the grooves.
  • Page 60 Installation SIP contemporary cordless 1-line/2-line accessory handset - CTM-C4401/CTM-C4501/ CTM-S241SD/CTM-S242SD Handset registration Place the cordless handset on the telephone base cradle. Handset registration happens automatically the first time a cordless handset is placed on the telephone base. When the registration process completes, the MESSAGE WAITING LED flashes once and you hear 3 rising beeps as confirmation.

  • Page 61: Telephone Settings

    Telephone settings SIP classic trimstyle - S1310/S1320 SIP classic cordless 1-line/2-line - S1410/S1420 SIP contemporary trimstyle - S2310/S2310-6VDC/S2320/S2320-6VDC SIP contemporary cordless 1-line/2-line - S2410/CTM-S2411/S2420/CTM-S2421 SIP contemporary cordless 1-line/2-line accessory Petite - CTM-S241P/CTM-S242P All telephone settings are programmed through the administrative web portal.

  • Page 62: Telephone Operation

    Telephone operation SIP classic trimstyle 1-line - S1310 Receive a call When there is an incoming call, the telephone rings and the TALK key flashes. To answer a call: Press TALK or /SPEAKER. The TALK key illuminates when the phone line is in use. The /SPEAKER key illuminates when in speakerphone mode.

  • Page 63: Sip Classic Trimstyle 2-Line - S1320

    Telephone operation SIP classic trimstyle 2-line - S1320 Receive a call When there is an incoming call, the telephone rings and the corresponding line key flashes. To answer a call: Press the flashing line key, or press /SPEAKER to pick up the ringing line. The respective line key illuminates when the phone line is in use.
  • Page 64 Telephone operation SIP classic trimstyle 2-line - S1320 Conference call This telephone allows three-way conversations. To initiate a conference call: Place a call to the first party. Press HOLD to place the first party on hold. Place a second call on the other line. Once the second party is on the line, press CONF to start a three-way conference.

  • Page 65: Sip Classic Cordless 1-Line - S1410

    Telephone operation SIP classic cordless 1-line - S1410 Using the cordless handset and the telephone base The cordless handset and the telephone base speakerphone cannot be used on the same call. However, calls can be switched between the corded handset and the telephone base speakerphone. When the cordless handset or the telephone base is in use, the TALK key on the cordless handset and the LINE key on the telephone base illuminate.

  • Page 66: Message Waiting Indicator

    Telephone operation SIP classic cordless 1-line - S1410 Volume Listening volume can be adjusted on the cordless handset and the telephone base. To adjust the listening volume: • During a call on the cordless handset, press +/VOLUME/- on it to adjust the listening volume. The next call returns to the default listening volume.

  • Page 67: Sip Classic Cordless 2-Line - S1420

    Telephone operation SIP classic cordless 2-line - S1420 Using the cordless handset and the telephone base The cordless handset and the telephone base cannot be used on the same call. However, calls can be switched between the cordless handset and the telephone base speakerphone. When the cordless handset or the telephone base is in use, the corresponding line keys on the cordless handset and the telephone base illuminate.
  • Page 68 Telephone operation SIP classic cordless 2-line - S1420 Redial The last dialed number on the cordless handset or the telephone base is stored for 15 minutes. To redial the last dialed number from the handset or the telephone base: Press LINE 1, LINE 2 or /SPEAKER.
  • Page 69 Telephone operation SIP classic cordless 2-line - S1420 Conference call This telephone allows three-way conversations. initiate a conference call: Place a call to the first party. Press HOLD to place the first party on hold. Place a second call on the other line. Once the second party is on the line, press CONF to start a three-way conference.

  • Page 70: Sip Contemporary Trimstyle 1-Line - S2310/S2310-6Vdc

    Telephone operation SIP contemporary trimstyle 1-line - S2310/S2310-6VDC Receive a call When there is an incoming call, the telephone rings and the TALK key flashes. To answer a call: Press TALK or /SPEAKER. The TALK key illuminates when the phone line is in use. The /SPEAKER key illuminates when in speakerphone mode.
  • Page 71 Telephone operation SIP contemporary trimstyle 1-line - S2310/S2310-6VDC Intercom Use this feature for conversations between two handsets. To initiate an intercom call: Press INTERCOM when the handset is not in use. It beeps and the INTERCOM key flashes. All destination cordless handsets and •...

  • Page 72: Sip Contemporary Trimstyle 2-Line - S2320/S2320-6Vdc

    Telephone operation SIP contemporary trimstyle 2-line - S2320/S2320-6VDC Receive a call When there is an incoming call, the telephone rings and the corresponding line key flashes. To answer a call: Press the flashing line key, or press /SPEAKER to pick up the ringing line. The respective line key illuminates when the phone line is in use.
  • Page 73 Telephone operation SIP contemporary trimstyle 2-line - S2320/S2320-6VDC Intercom Use this feature for conversations between two handsets. To initiate an intercom call: • Press INTERCOM when the handset is not in use. It beeps and the INTERCOM key flashes. All destination cordless handsets and the main telephone base ring.

  • Page 74: Sip Contemporary Cordless 1-Line - S2410/Ctm-S2411

    Telephone operation SIP contemporary cordless 1-line - S2410/CTM-S2411 Using the cordless handset and the telephone base The cordless handset and the telephone base cannot be used on the same call. However, calls can be switched between the cordless handset and the telephone base speakerphone. When the cordless handset or the telephone base is in use, the TALK key on the cordless handset and the LINE key on the telephone base illuminate.
  • Page 75 Telephone operation SIP contemporary cordless 1-line - S2410/CTM-S2411 Volume Listening volume can be adjusted on the cordless handset and the telephone base. To adjust the listening volume: During a call on the handset, press -/VOLUME/+ on it to adjust the listening volume. The next call returns to the default •...
  • Page 76 Telephone operation SIP contemporary cordless 1-line - S2410/CTM-S2411 To answer an intercom call: Lift the cordless handset from the telephone base, charging base or charging stand, or press INTERCOM on the • cordless handset when it is not cradled on the telephone base, charging base or charging stand. -OR- •...

  • Page 77: Sip Contemporary Cordless 1-Line Accessory Petite - Ctm-S241P

    Telephone operation SIP contemporary cordless 1-line accessory Petite - CTM-S241P Receive a call When there is an incoming call, the telephone rings. The IN USE LED flashes. To answer a call: Lift the corded handset from the accessory Petite phone base. The IN USE LED illuminates. Place a call Lift the corded handset.

  • Page 78: Sip Contemporary Cordless 2-Line - S2420/Ctm-S2421

    Telephone operation SIP contemporary cordless 2-line - S2420/CTM-S2421 Using the cordless handset and the telephone base The cordless handset and the telephone base cannot be used on the same call. However, calls can be switched between the cordless handset and the telephone base speakerphone. When the cordless handset or the telephone base is in use, the corresponding line keys on the cordless handset and the telephone base illuminate.
  • Page 79 Telephone operation SIP contemporary cordless 2-line - S2420/CTM-S2421 Redial The last dialed number on the cordless handset or the telephone base is stored for 15 minutes. To redial the last dialed number: Press LINE 1, LINE 2 or /SPEAKER. Listen for a dial tone. Then press REDIAL. Volume Listening volume can be adjusted on the cordless handset and the telephone base.
  • Page 80 Telephone operation SIP contemporary cordless 2-line - S2420/CTM-S2421 To answer an intercom call: Lift the cordless handset from the telephone base, charging base or charging stand, or press INTERCOM on the cordless • handset when it is not cradled on the telephone base, charging base or charging stand. -OR- •...

  • Page 81: Sip Contemporary Cordless 2-Line Accessory Petite - Ctm-S242P

    Telephone operation SIP contemporary cordless 2-line accessory Petite - CTM-S242P Receive a call When there is a line 1 incoming call, the telephone rings. The LINE 1 key flashes. • When there is a line 2 incoming call, the telephone rings. The LINE 2 key flashes. •...
  • Page 82 Telephone operation SIP contemporary cordless 2-line accessory Petite- CTM-S242P Conference call This telephone allows three-way conversations. To initiate a conference call: Place a call to the first party. Press HOLD to place the first party on hold. Place a second call on the other line. Once the second party is on the line, press CONF to start a three-way conference.

  • Page 83: Appendix

    Appendix Troubleshooting If you have difficulty with the telephones, please try the suggestions below. For customer service, visit our website at www.vtechhotelphones.com or call 1-888-907-2007. The telephone does not work at all. Make sure the Cat-5 network cable is plugged into the LAN port of the telephone base and the network wall jack with •...
  • Page 84 Appendix Troubleshooting The battery does not charge in the cordless handset or the battery does not accept charge. • Make sure the cordless handset is placed in the telephone base, charging base or charging stand correctly. The CHARGE LED should be on. •...

  • Page 85: Precautions For Users Of Implanted Cardiac Pacemakers

    VTech product service centers. Please call 1 (800) 8 BATTERY in the RBRC ® information on Ni-MH battery recycling and disposal bans/restrictions in your area. VTech’s involvement in this program is part of its commitment to protecting our environment and conserving natural resources. ®...

  • Page 86: Vtech Hospitality Limited Warranty Program

    If the Product failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and will request that you authorize the cost of repair and return shipping costs for the repair of Products that not covered by this limited warranty.

  • Page 87: Fcc, Acta And Ic Regulations

    Appendix FCC, ACTA and IC regulations FCC Part 15 This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 88: Energy-Saving Charging Mode

    Appendix Energy-saving charging mode When this mode is activated, all telephone functions, except handset battery charging, will be disabled. To activate the energy-saving charging mode in the S2410/S2420/CTM-S2411/CTM-S2421 handset which is cradled on the charging base (C4001) or charging stand (C4011): When a registered cordless handset is idle, press *331734# and then press HOLD.

  • Page 89: Technical Specifications

    Appendix Technical specifications SIP classic trimstyle 1-line/2-line - S1310/S1320 Power requirement PoE class 2 powered (48V) Frequency control Crystal controlled PLL synthesizer Transmit frequency Handset: 1921.536-1928.448 MHz Channels Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to environmental conditions at the time of use.
  • Page 90 Appendix Technical specifications SIP contemporary trimstyle 1-line/2-line - S2310/S2320 Power requirement PoE class 2 powered (48V) Frequency control Crystal controlled PLL synthesizer Transmit frequency Handset: 1921.536-1928.448 MHz Channels Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to environmental conditions at the time of use.
  • Page 91 Appendix Technical specifications SIP contemporary cordless 1-line/2-line - CTM-S2411/CTM-S2421 Power requirement 2.4V Ni-MH battery Frequency control Crystal controlled PLL synthesizer Transmit frequency 1921.536-1928.448 MHz Channels Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to environmental conditions at the time of use.
  • Page 92 Appendix Technical specifications SIP comtemporary cordless 1-line/2-line accessory handset - CTM-C4400/CTM-C4500 Power requirement 2.4V Ni-MH battery Frequency control Crystal controlled PLL synthesizer Transmit frequency 1921.536-1928.448 MHz Channels Nominal effective range Maximum power allowed by FCC and IC. Actual operating range may vary according to environmental conditions at the time of use.

  • Page 93: Index

    Users of implanted cardiac pacemakers 81 Important safety instructions i Initialization and system registration 32 Volume 58 Initiate a conference call 60 VTech Hospitality limited warranty program 82 Initiate an intercom call 67 Installation 29–56 Intercom 67 Wall mount 30...
  • Page 94 A member of THE VTECH GROUP OF COMPANIES. Distributed in the U.S.A. by VTech Communications, Inc., Beaverton, Oregon 97008. Distributed in Canada by VTech Technologies Canada Ltd., Richmond, B.C. V6W 1L5. VTech is the registered trademark of VTech Holdings Limited.

This manual is also suitable for:

C3400C3500S1320S2310S2310-6vdcS2320 ... Show all

Table of Contents
