SIP Cordless Phone User Guide
SIP contemporary trimstyle 1-line - S2310-6VDC
SIP contemporary trimstyle 2-line - S2320-6VDC
Before using this telephone, please read Important safety instructions on page 7 of this user guide.
Parts checklist
Items contained in the respective telephone package:
Model name
Model number
SIP contemporary
S2310-6VDC
trimstyle 1-line
SIP contemporary
S2320-6VDC
trimstyle 2-line
Telephone layout
SIP contemporary trimstyle 1-line - S2310-6VDC
MESSAGE WAITING LED
Parts included
Telephone base
Telephone base
TALK
REDIAL
/SPEAKER
INTERCOM
Mounting bracket
Corded handset
with a screw
Mounting bracket
Corded handset
with a screw
-/VOLUME/+
OFF
FLASH
HOLD
MUTE
1
Telephone base
power adapter
Telephone base
power adapter
Wall mount clip
POWER LED
Advertisement
Table of Contents
Related Manuals for VTech S2310-6VDC
Summary of Contents for VTech S2310-6VDC
-
Page 1: Parts Checklist
SIP Cordless Phone User Guide SIP contemporary trimstyle 1-line - S2310-6VDC SIP contemporary trimstyle 2-line - S2320-6VDC Before using this telephone, please read Important safety instructions on page 7 of this user guide. Parts checklist Items contained in the respective telephone package:... - Page 2 REDIAL INTERCOM POWER LED Installation SIP contemporary trimstyle 1-line/2-line - S2310-6VDC/S2320-6VDC Telephone base installation The telephone can be adapted to desktop use or mount on a standard telephone wall plate. Installation option - desktop position Turn the telephone base over with the bottom side facing up. Route the small end of the power adapter cord out from the top eyelet on the mounting bracket.
- Page 3 Plug the large end of the power adapter into the electrical outlet not controlled by a wall switch. Then connect the coiled handset cord to the telephone base. Installation option - converting from desktop to wall mount position Unplug the power adapter from the electrical outlet. Put the corded handset aside.
-
Page 4: Telephone Settings
Handset registration An S2310-6VDC/S2320-6VDC handset must be registered to an S2410/S2420 telephone base before use. To register an S2310-6VDC handset: Place the corded handset on the S2410 is placed on the telephone base. When the registration process completes, the MESSAGE WAITING When you already have 4 registered handsets, you can replace one of them by a new handset if any one of the 4 registered handsets is disconnected from the base. - Page 5 Call waiting When you hear a call waiting tone during a call, press FLASH to put the current call on hold and take the new incoming call. Press FLASH at any time to switch back and forth between calls. Mute To mute the microphone: During a call, press MUTE.
- Page 6 Volume Listening volume can be adjusted on the handset. To adjust the listening volume: During a call on the handset, press -/VOLUME/+ listening volume. Call waiting for details. When you hear a call waiting tone during a call, press the corresponding line key to put the current call on hold and take the new incoming call.
-
Page 7: Important Safety Instructions
Important safety instructions and injury, including the following: This product should only be connected to the host equipment and never directly to the network such as Public Switch Telephone Network (PSTN) or Plain Old Telephone Services (POTS). Read and understand all instructions. Follow all warnings and instructions marked on the product. -
Page 8: Fcc Part
A member of THE VTECH GROUP OF COMPANIES. Distributed in the U.S.A. by VTech Communications, Inc., Beaverton, Oregon 97008. Distributed in Canada by VTech Technologies Canada Ltd., Richmond, B.C. V6W 1L5. VTech is the registered trademark of VTech Holdings Limited.
