Installation, cont'd

Installation instructions

For optional rack mounting, mount the SW VGArs / Ars Series
on an optional RSU 129 1U Universal Rack Shelf
(part #60-1 0-01) or RSB 129 1U Basic Rack Shelf
(part #60-604-01) (figure 2-1). The switcher mounts either to the
right or to the left at the front of the rack.
RSU 129 1U Universal Rack Shelf
Front false
faceplate
uses 2
screws.
Use 2 mounting holes on
opposite corners.
Figure 2-1 — ac - ounting the switcher
1. If rubber feet were previously installed on the bottom of the
switcher, remove them.
2. Mount the SW VGArs / Ars Switcher on the rack shelf,
using two 4-40 x 3/16-inch screws in opposite (diagonal)
corners to secure the switcher to the shelf (figure 2-1).
3. Attach a blank panel or other unit(s) to the rack shelf.
4. Insert the shelf into the rack, aligning the holes in the shelf
with those of the rack.
. Secure the shelf to the rack using the supplied machine
screws.
2-4 SW VGArs / Ars Series Switchers • Installation
1/2 Rack Width Front False
Faceplate
(2) 4-40 x 3/16"
Screws
NOTE:
Using screws longer
than 3/16" will damage the
unit and void the warranty.

Furniture mounting

All of the switcher models can be mounted under furniture,
such as a table or podium surface, using optional MBU 125
under-desk mounting brackets (# 0-0 -01). All models can
also be mounted through a table or podium, using optional
MBD 129 through-desk mounting brackets (# 0-0 -02).
Furniture mount the switcher as follows:
1. Attach the mounting brackets to the switcher with the
provided machine screws (figure 2-2).
Through Desk Kit
Figure 2-2 — n er sur ace or through sur ace
ounting
2. -
the mounting surface.
3. -
attached brackets against the underside of the table or other
furniture. Mark the location of the screw holes of the
bracket on the mounting surface.
4. -
diameter pilot holes, 1/4 inch (6.3 mm) deep in the
mounting surface at the marked screw locations.
. -
through the bracket and into the four pilot holes. Tighten
all four screws to secure the switcher in place.
6. -
the four pilot holes. Tighten each screw into the mounting
surface until just less than 1/4 inch of the screw head
protrudes.
. -
with the slots in the brackets and place the switcher against
the surface, with the screws through the bracket slots.
. -
forward or back, then tighten all four screws to secure the
switcher in place.
SW VGArs / Ars Series Switchers • Installation
AU
TO SW
ICH
AC TIV
E
1
MO 2
DE
3
NO
RM
AL
AU 4
TO SW
VG
A /A
VG rs
A/A SE
UD R IE
IO SW S
ITC
HE
R
Under Desk Kit
, cut the proper sized hole in
hold the switcher with the
drill four 3/32-inch (2 mm)
insert four #8 wood screws
, insert #8 wood screws into
, align the mounting screws
, slide the switcher slightly
2-5
