- Page 1 SERVICE MANUAL COOKING Built-in appliances and floor-mounted stoves with „RHEA“ input electronics © Electrolux Distriparts Publ.-Nr.: Muggenhofer Straße 135 599 518 252 D-90429 Nürnberg Germany Fax +49 (0)911 323 1022 DGS-TDS-N Edition: 05.09...
-
Page 2: Table Of Contents
Example circuit diagram OVC 2000 .................. 38 Example circuit diagram SOEC ..................39 Example circuit diagram Prisma ..................40 Example circuit diagram HOC 2000 .................. 41 Operative Equipment Overview ..................42 Changes ............................43 DGS-TDS-N 05.09 A. B. © Electrolux - 2 - 599 518 252... -
Page 3: Esd=Electrostatic Discharge
Endangered are all assembly groups which are provided with control entries, wire paths lying open and free-accessible processors. DGS-TDS-N 05.09 A. B. © Electrolux - 3 - 599 518 252... -
Page 4: Software Specifications, Functions
Position rotary and shuttle not analog OVF/ layout IS-°C Button layout for all appliance groups of the Arthur Martin Elux brand without Pyrolyse function OVF/ IS-°C DGS-TDS-N 05.09 A. B. © Electrolux - 4 - 599 518 252... - Page 5 Button layout for built-in appliances of the AEG and Voss brands with meat thermometer Position rotary and shuttle not analog OVF/ layout Time/ Temp KEY_MODE in MP-functionality Button layout for floor-mounted appliances of the Electrolux brand with meat thermometer OVF/...
-
Page 6: Main Features Of Operation
„„Minus“ button, or, with appliances featuring a Temperature Selection Switch, this must be put into the „Minus“ position when activating the MODE button (=Timer button). DGS-TDS-N 05.09 A. B. © Electrolux - 6 - 599 518 252... -
Page 7: Functions Of Appliance
12,9 Pos.2 1965 Pos.3 3005 13,1 Pos.4 (top-/bottom el.) 2065 Pos.5 3005 13,1 Pos.6 2105 Pos.7 Pos.8 (Pyro2) 2930 12,7 2 dif f . Durat ions Manual booster DGS-TDS-N 05.09 A. B. © Electrolux - 7 - 599 518 252... - Page 8 Pos.0 (OFF) Pos.1 3005 13,1 Pos.2 (top-/bottom el.) 2065 Pos.3 3005 13,1 Pos.4 2965 12,9 Pos.5 1965 Pos.6 Pos.7 1065 Pos.8 (Pyro2) 2930 12,7 2 diff. Durations Manual booster DGS-TDS-N 05.09 A. B. © Electrolux - 8 - 599 518 252...
- Page 9 Pos.1 (top-/bottom el.) 3365 14,6 Pos.2 3405 14,8 Pos.3 2365 10,3 Pos.4 2405 10,5 Pos.5 3365 14,6 Pos.6 (keep warm) 3365 14,6 Pos.7 3365 14,6 Pos.8 3405 14,8 booster "AUTO" DGS-TDS-N 05.09 A. B. © Electrolux - 9 - 599 518 252...
- Page 10 Pos.1 (lighting) Pos.2 3005 13,1 Pos.3 (top-/bottom el.) 2065 Pos.4 3005 13,1 Pos.5 2965 12,9 Pos.6 1965 Pos.7 Pos.8 1065 Pos.9 (Pyro2) 2930 12,7 2 diff. Durations Manual booster DGS-TDS-N 05.09 A. B. © Electrolux - 10 - 599 518 252...
- Page 11 1900 Pos.0 (OFF) Pos.1 Pos.2 (top-/bottom el.) 2105 Pos.3 2065 Pos.4 3005 13,1 Pos.5 1965 Pos.6 Pos.7 1065 Pos.8 (Pyro2) 2930 12,7 2 diff . Durations Manual booster DGS-TDS-N 05.09 A. B. © Electrolux - 11 - 599 518 252...
- Page 12 Pos.2 2505 10,9 Pos.3 (top-/bottom el.) 2065 Pos.4 3505 15,2 Pos.5 2005 Pos.6 1965 Pos.7 2965 12,9 Pos.8 1065 Pos.9 (Pyro) 2930 12,7 2 diff. Durations Manual booster"AUTO" DGS-TDS-N 05.09 A. B. © Electrolux - 12 - 599 518 252...
-
Page 13: Pyrolitical Cleaning - Explanation
Heating period 150min > Heating period 120min > Heating period 90min Note: In appliances which are equipped with two pyrolysis durations, P2 corresponds to the pyrolysis duration P3. DGS-TDS-N 05.09 A. B. © Electrolux - 13 - 599 518 252... -
Page 14: High-Speed Heating - Explanation
Note: Quick-Heating function - manual operation Quick-Heating function „AUTO“ - Automatically active, not switchable The type of Quick-Heating function available is in Chapter 3.1. DGS-TDS-N 05.09 A. B. © Electrolux - 14 - 599 518 252... -
Page 15: Safety Function Safety Cutoff Of Oven
If the cooking zones are not switched off after a certain period of time, or the temperature not changed, they switch off automatically. The temporal cutoff depends on the set cooking level: DGS-TDS-N 05.09 A. B. © Electrolux - 15 - 599 518 252... -
Page 16: Functional Parts - Component Data, Installation Situation, Dismantling
Sensor button connection (optional) „Rotary/Shuttle“ input module connection The illustration depicts the RHEA input electronics in an installed state with the two input modules, Rotary (right) and Shuttle (left). DGS-TDS-N 05.09 A. B. © Electrolux - 16 - 599 518 252... -
Page 17: Power Electronics
Connection description factory programming Door locking system small load heating elements Electrical voltage supply all-pole cutoff input electronic (UI) Analog Input Digital Input Temperature sensor PT500 DGS-TDS-N 05.09 A. B. © Electrolux - 17 - 599 518 252... -
Page 18: Power Electronic Ovc2000
These two components, power electronics and plastic box, are also a replacement part unit (see Ill.) Please refer to Chapter 7 for connection designations and possible measuring points. DGS-TDS-N 05.09 A. B. © Electrolux - 18 - 599 518 252... -
Page 19: Soec Power Board (Power Board)
Heating relay (*) Fast-on high performance SP35 - Heating relay (*) connections BP21 low power load The elements triggered will vary according to the version and the software installed. DGS-TDS-N 05.09 A. B. © Electrolux - 19 - 599 518 252... -
Page 20: Temperature Sensor Pt500
ON/OFF the cooling fan. Fig. Temperature sensor Fig. Electrical resistance of sensor depending on the ambient temperature DGS-TDS-N 05.09 A. B. © Electrolux - 20 - 599 518 252... -
Page 21: Door Locking Systems
The Klixon is arranged at the transverse beam beside the hot air motor (Fig. 2). Fig. 1, Door lock Fig. 2, Arrangement of Klixon Fig. Switching of door lock DGS-TDS-N 05.09 A. B. © Electrolux - 21 - 599 518 252... - Page 22 For unlocking, a voltage of 230 V must be applied to contacts 2 and 3. The bar “A” moves backwards and releases the lock lever. The door can be opened provided that the contact f11 (Klixon) is closed. DGS-TDS-N 05.09 A. B. © Electrolux - 22 - 599 518 252...
-
Page 23: Door Locking System, Motorics With Door-Switch Light
Fig.: Door locking system as complete component Drive motor Double micro switch Above: Lock Below: Oven lighting switch Curve pane Sliding micro switch - Lighting Sliding door locking system DGS-TDS-N 05.09 A. B. © Electrolux - 23 - 599 518 252... -
Page 24: Oven Input Module
40° steps. Each 40° step means a changed resistance level at the printed circuit contacts (see automatic logic diagram). The signals of the input module received by the User Inter- face are communicated to the power board by data transmission. DGS-TDS-N 05.09 A. B. © Electrolux - 24 - 599 518 252... -
Page 25: Temperature / Time Predetermined Level Transducer
When opening the door of the oven, the lighting of the oven is activated over this component after the device has been switched on. The mounting position is at the top and right-hand corner of the front frame of the oven DGS-TDS-N 05.09 A. B. © Electrolux - 25 - 599 518 252... -
Page 26: Light Bar In The Control Panel
The activation of the light bar occurs through a activation electronics that is hafted on the lower surface of the front cover. It provides the light bar with a voltage of 7V/18mA. DGS-TDS-N 05.09 A. B. © Electrolux - 26 -... -
Page 27: Functional Parts - Cooking Setting Control
The power characteristic shows the power controller in cycling mode. The average switching on period for each knob position can be read off in % of the cycled and/or max. power. DGS-TDS-N 05.09 A. B. © Electrolux - 27 - 599 518 252... -
Page 28: Input Electronic Hoc2000 And Input Module
Fig.: input electronic HOC2000 and Input module in installed condition Input electronic HOC2000 LED display description of connection 3d view Attention: The HOC2000 input electronics also consist of ESD-sensitive components. DGS-TDS-N 05.09 A. B. © Electrolux - 28 - 599 518 252... - Page 29 Behind every rotation there is a specific resistance value, which on the other hand stands for a certain cooking level. contacts of conductor plate 10mA/5Vdc contact name of connector 4 3 2 1 3 2 1 Fig.: wiring diagram input module DGS-TDS-N 05.09 A. B. © Electrolux - 29 - 599 518 252...
-
Page 30: Cooking Zone Power Board Hoc2000
Between contact BR19 (neutral) and BR22 (phase) it is possible to measure the mains voltage. Information A 22 phase 19 neutral DGS-TDS-N 05.09 A. B. © Electrolux - 30 - 599 518 252... - Page 31 Note: A built-in cooker must be removed completely from the built-in cavity for disassembling the power board. DGS-TDS-N 05.09 A. B. © Electrolux - 31 - 599 518 252...
-
Page 32: Technical Equipment
Technical equipment Temperature safety device With built-in appliances, there is a temperature fuse on the side of the air channel that switches off the appliance in the event of overheating. The measured temperature value during a cutoff is 90°C. Fig.: Built-in position - Temperature fuse... -
Page 33: Oven Rack Protective Circuit
äußeren Seite der Komponentenplatte. Only with attached oven racks, not with slide-in grids, the microswitch interrupts a switch contact which prevents an activating of the pyrolytic function. Note: for wiring diagram see chapter 7 DGS-TDS-N 05.09 A. B. © Electrolux - 33 - 599 518 252... -
Page 34: Fault Diagnosis/ What To Do If
Heaters are not connected no rise in temperature takes (slow-break switching), heater place within approx. 7 min. defective, sensor not at the Only active below approx. 70 muffle °C DGS-TDS-N 05.09 A. B. © Electrolux - 34 - 599 518 252... -
Page 35: Measuring The Temperature Sensor
Make sure to measure the insulation resistance between the metallic housing and each connection terminal. The resistance should be higher than 2 MOhms. Fig. Measuring the temperature sensor Demo mode Not provided Factory test / door lock test Not provided DGS-TDS-N 05.09 A. B. © Electrolux - 35 - 599 518 252... -
Page 36: Wiring Diagram / Measuring Points
Wiring diagram / measuring points Connection Point Overview DGS-TDS-N 05.09 A. B. © Electrolux - 36 - 599 518 252... -
Page 37: Example Circuit Diagram Ovc 1000
Example circuit diagram OVC 1000 DGS-TDS-N 05.09 A. B. © Electrolux - 37 - 599 518 252... -
Page 38: Example Circuit Diagram Ovc 2000
Example circuit diagram OVC 2000 DGS-TDS-N 05.09 A. B. © Electrolux - 38 - 599 518 252... -
Page 39: Example Circuit Diagram Soec
Example circuit diagram SOEC DGS-TDS-N 05.09 A. B. © Electrolux - 39 - 599 518 252... -
Page 40: Example Circuit Diagram Prisma
Example circuit diagram Prisma DGS-TDS-N 05.09 A. B. © Electrolux - 40 - 599 518 252... -
Page 41: Example Circuit Diagram Hoc 2000
Example circuit diagram HOC 2000 DGS-TDS-N 05.09 A. B. © Electrolux - 41 - 599 518 252... -
Page 42: Operative Equipment Overview
Operative Equipment Overview DGS-TDS-N 05.09 A. B. © Electrolux - 42 - 599 518 252... -
Page 43: Changes
Changes Pages Chapter 6.1 changed DGS-TDS-N 05.09 A. B. © Electrolux - 43 - 599 518 252...
