ELECTRIC COOKTOP INSTALLATION INSTRUCTIONS
Canada
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
WARNING
flammable vapors and liquids in the vicinity of this or any other appliance.
IMPORTANT INSTALLATION INFORMATION
• All electric cooktops run off a single phase, three-wire
or four-wire cable, 240/208 volt, 60 hertz, AC only
electrical supply with ground.
• Minimum distance between cooktop and overhead
cabinetry is 30" (76.2 cm).
Cooktop Dimensions
30" Min. *
(76.2 cm)
A
D
F
Cooktop Cutout
Dimensions
H
* 30" (76.2 cm) min. for unprotected cabinet
24" (61 cm) min. for protected surface
MODEL A. WIDTH
30'' Ceramic Model 30 ¾ (78.1)
36'' Ceramic Model 36 ¾ (93.3)
MODEL
30'' Ceramic Model
36'' Ceramic Model
All dimensions are in inches (cm).
Printed in Canada
INSTALLATION AND SERVICE MUST BE PERFORMED
BY A QUALIFIED INSTALLER.
FOR YOUR SAFETY: Do not store or use gasoline or other
IMPORTANT: If a plywood is present in the cabinet under
the cooktop, install the deflector supplied under the burner box
B
(see Fig.1-A) as shown in fig. 1-B and make a 4" X 8" (10.2 cm
x 20.3 cm) opening to route armored cable. Note: Remove the
deflector if the cooktop is installed over a wall oven.
C
E
I
PRODUCT DIMENSIONS
B. DEPTH
21 ¾ (55.2)
21 ¾ (55.2)
CUT OUT DIMENSIONS
G. WIDTH
MINIMUM MAXIMUM
29 ¾ (75.6) 30 (76.2)
36 (91.4) 36 ¼ (92.1)
Deflector position when a plywood
Front
Countertop
G
Figure 1
C. HEIGHT D. HEIGHT
3 / (7.9) 6 ½ (16.5)
1
8
3 / (7.9) 6 ½ (16.5)
1
8
H. DEPTH
MINIMUM
20 3/8 (51.8)
20 3/8 (51.8)
English – pages 1-6; Español – pages 7-12; Français - pages 13-18; Notes - 19-20
1
United States
Deflector shipping
position
Figure 1-A
is present in the cabinet
Figure 1-B
3 1/8
(7,9)
6 ½
(16,5)
4 ½
6 7/8
(11,4)
(17,5)
Side view
E. BOX WIDTH F. BOX DepTH
28 ½ (72.4) 19
34 / (87.9) 19
5
8
I. HeIGHT BeLOW
MAXIMUM COOKTOp
20 ½ (52.1) 8 ½ (21.6)
20 ½ (52.1) 8 ½ (21.6)
P/N 318201445 (1102) Rev. H
Rear
Countertop
/ (48.9)
1
16
/ (48.9)
1
16
