8: Dlc Configuration For Lan Manager; Dlc Configuration; Eps Configuration; Host Configuration - Lantronix EPS1 Installation Manual

8: DLC Configuration for LAN
Manager
The EZWebCon configuration software is the easiest way to configure the EPS. This
chapter explains DLC/Digital Network Port configuration for Windows NT 4.x hosts.
The Server needs an IP address before you can use EZWebCon. See
Note:
Setting the IP Address on page 4-1 for instructions.
Printing using an LPD client is the preferred method for sending print jobs to the EPS.
Windows 95 does not support DLC printing (see Chapter 4 for more information).

8.1 DLC Configuration

8.1.1 EPS Configuration

To use the DLC protocol, you must have one service with the DLC characteristic en-
abled. The DLC characteristic may be associated with only one service on a given EPS.
Local>> DEFINE SERVICE EPS_xxxxxx_P1 DLC ENABLED

8.1.2 Host Configuration

To send print jobs from a Windows NT host to the EPS, add the EPS as a Windows NT
printer.
1
Double-click the Printers icon in the Control Panel.
2
Double-click the Add Printer icon.
3
In the window that appears, select My Computer and click Next.
4
Select the Add Port button.
5
Select Hewlett-Packard Network Port and click New Port.
If Hewlett-Packard port is not one of the available options, you must install DLC
printing from your Windows NT system disks. DLC is not installed by default.
6
Enter the EPS hardware address. It is printed on the EPS bottom label.
Figure 8-1: Enabling DLC
8-1
