6: LAT Configuration

The EZWebCon configuration software is the easiest way to configure the EPS. The fol-
lowing sections cover print configuration methods for LAT hosts.
The EPS needs an IP address before you can use EZWebCon. See
Note:
Setting the IP Address on page 4-1 for instructions.
LAT print queues can be created by printing to a port or printing to a service. Printing
directly to a port requires no EPS configuration.
Printing directly to a port is the easiest method for printing to the
Note:
EPS. If you would like instructions for printing to a service, see the
Print Server Reference Manual located on the CD-ROM.

6.1 Printing Directly to a Port

1
Create a LAT application port that references the EPS port.
$ RUN SYS$SYSTEM:LATCP
LATCP> CREATE PORT LTAnnn/APPLICATION
LATCP> SET PORT LTAnnn/NODE=EPS_xxxxxx/PORT=Port_n
LATCP> EXIT
2
Create and start a print queue that uses the LAT application port.
Figure 6-2: Creating and Starting Print Queue
$ INITIALIZE/QUEUE/START/ON=LTAnnn:/PROCESSOR=LATSYM
/RETAIN=ERROR queue_name
3 Add the commands to the SYS$MANAGER:LAT$STARTUP.COM file so the
required LAT devices will be recreated after each host reboot.
LAT terminal device characteristics may have to be changed to cor-
Note:
rectly print certain files. See your VMS documentation for more in-
formation.
4
Print to the queue.
$ PRINT/QUEUE=queue_name filename.txt
Figure 6-1: Creating LAT Application Port
Figure 6-3: Printing to Queue
6-1
